- Page 1 RK-50SP SPIN-PULL THREADED INSERT TOOL Operating Instructions INCHES/METRIC Read All Safety Rules and Instructions Carefully Save this manual for Future Reference...
-
Page 2: Important Safety Warnings
IMPORTANT SAFETY WARNINGS: THE SAFETY WARNINGS BELOW CANNOT COVER ALL POSSIBLE SITUATIONS THAT MAY OCCUR. THESE BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO PROTECT AGAINST PERSONAL INJURY TO THE OPERATOR OR OTHER PERSONNEL IN THE AREA, AS WELL AS DAMAGE TO THE EQUIPMENT. READ AND UNDERSTAND THESE WARNINGS BEFORE USING EQUIPMENT. - Page 3 IMPORTANT SAFETY WARNINGS: continued Disconnect air hose from tool: -before performing maintenance. -when clearing a jam. -when tool is not in use. -when moving it to another location. -When handing tool to another person. Carry tool by the handle only, not by the air hose. Never use the tool if it is leaking air, the contact safety mechanism is not working, tool has missing or damaged parts, or requires repair.
-
Page 4: Air Supply
DESCRIPTION OF THE PRESSURE REGULATION SYSTEM APPLICATIONS The following can be found at the bottom of your FPC900 Tool: Including but not limited to installing blind rivet nuts/bolts in various materials. -Pressure relief valve (A) acting as safety valve to prevent overloading of the tool. The valve FEATURES opens if the compressed air pressure exceeds 7 bar. -
Page 5: Operation
OPERATION OPERATION THREADED MANDREL, ADAPTER, AND NOSE REPLACEMENT You have the correct mandrel/adapter (A) if its threads correspond to that of the nut/bolt. You have the correct nose piece (B) if it fits tightly around the thread of the mandrel or bolt. Proceed as follows to replace a mandrel with nose piece: Quick change automatic setting sequence 1) Disconnect the tool from the compressed air supply. -
Page 6: Maintenance
Adjusting Air Pressure Mode of Operation Do not exceed 120 PSI. Adjust the air pressure at the recommended operating pressure of Fit the correct threaded mandrel and nose piece to the tool. Set the nose piece. The nose piece is 75 to 100 PSI.
