- Page 1 Instruction Manual RK-280-NP12...
-
Page 2: Table Of Contents
ONTENTS Safety Page 3 Specifications Page 3 Preparing the tool for service Page 4 Air supply Page 4 Maintenance Daily Page 5 Weekly Page 6 Monthly Page 7 Trigger Service Page 8 Assembly Drawings Schematic Addendum A Parts List Addendum B MSDS Page 10 Troubleshooting... -
Page 3: Safety
AFETY RECOMMENDED BY O NOT USE OUTSIDE DEISNG INTENT OR WITH EQUIPMENT THAT IS NOT THE MANUFACTURER LWAYS DISCONNECT THE AIR SUPPLY BEFORE ATTEMPTING ANY MAINTENANCE OR ADJUSTMENT FITTING OF NOSE EQUIPMENT O NOT OPERATE A TOOL THAT IS DIRECTED TOWARDS ANY PERSON OR WITH THE NOSE PIECES OFF THE TOOL ... -
Page 4: Preparing The Tool For Service
REPARING THE TOOL FOR SERVICE . . Inspect for damage . . Connect the tool to the air supply . . Insure the Rivet Nut you wish to install is within the capacity of the rivet tool . . Choose and securely install the applicable nose piece for the rivet nuts you wish to apply. . -
Page 5: Maintenance
AINTENANCE In order to maintain the tool in a safe working order it is important to carry out regular maintenance as prescribed by the manufacturer. A thorough inspection replacement of all seals within the tool should be carried out after 500,000 placings or annually, whichever is the sooner. Item numbers in parentheses refer to assembly drawing part numbers Daily Maintenance ... -
Page 6: Weekly
Weekly Maintenance Carry out procedures as per daily maintenance instructions above Clean and inspect the following using the below procedure.. Remove the 4 black screw plugs (2 in the front and 2 in the rear of the tool), exposing the brass pilot valve stem (see Fig 1). -
Page 7: Monthly
Monthly Maintenance Carry out procedures as per daily & monthly maintenance instructions above Grease the engine/gear reducer with a red synthetic grease... -
Page 8: Trigger Service
Trigger Service Inspect trigger pin valve by insuring 56 has not come loose. The proper depth should be just under the valve stem. If adjustment is necessarym using a fork wrench or tire valve tool, screw the trigger pin 56 into the valve stem. -
Page 9: 1/4" Npt/Pt
RK-280-NP12 AIR RIVET NUT TOOL RK-280-NP12 AIR RIVET NUT TOOL TECHNICAL Capacity: ½-13, rivet nut in all materials DATA Free Speed 280RPM Avg. Air Consumption 9.9cfm(280 1/min) Operating Air Pressure 90 PSI (6.2 Bar) Length 233 mm Net Weight 1.4 kgs Air Inlet 1/4”... -
Page 10: Schematic
SCHEMATIC Please see the attached document for the parts drawing & parts list. PARTS LIST Please see the attached document for the parts drawing & parts list. Oil Details The recommended oil for priming is Hyspin VG32 available in 0.51 or one gallon containers, or, you can use 30W hydraulic oil. -
Page 11: Troubleshooting
ROUBLESHOOTING Item numbers in parentheses refer to assembly drawing part numbers on page 9. Problem Possible Cause Remedy Threads will not engage the Wrong Mandrel Size Measure rivetnut thread & pitch rivet nut and select appropriate mandrel Worn or Broken Mandrel Replace Mandrel ... -
Page 12: Warranty
Warranty Statement: Industrial Rivet & Fastener Co. Inc. and Zipp Tools (hereinafter “IRF”), hereby warrants to the initial retail customer and original distributor (“Warrantee”) only that its products will be free from defects in material and workmanship for a period of 1 year from the purchase date, provided that the products are used in accordance with “IRF’s”...
