Topaz SL SERIES Hardware User Manual

Topaz android sl series freestanding
Hide thumbs Also See for SL SERIES:
Table of Contents

Advertisement

Quick Links

Download this manual
Freestanding TOPAZ™
Android SL Display
Hardware User
Design Led
– Solutions Driven
Manual
42"
TOPAZ™ ANDROID SL SERIES
multimedia Full HD
Freestanding
Hardware User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL SERIES and is the answer not in the manual?

Questions and answers

Related Manuals for Topaz SL SERIES

Summary of Contents for Topaz SL SERIES

  • Page 1 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 42” TOPAZ™ ANDROID SL SERIES multimedia Full HD Freestanding Hardware User Manual...
  • Page 2 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Our Full Product Range Full details of all TOPAZ™ products available can be found by visiting our web site 42” www.topazdigital.com multimedia Full HD...

  • Page 3: Safety Instructions

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Safety Instructions 42”  Please keep the display away from any heat sources. Place the display in a multimedia Full HD stable and well-ventilated place.  Please handle with care as product contains glass.

  • Page 4: Table Of Contents

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Contents: Introduction ........................... 5 42” Box Contents ......................5 multimedia Full HD Product Overview ...................... 5 Remote Control ......................6 Replacing the Remote Control Battery ..............7 Home Screen ......................
  • Page 5 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Table of Figures 42” Figure 1 Product Overview ..........................5 Figure 2 Home Screen ............................8 multimedia Full HD Figure 3 Screen inputs ............................31...

  • Page 6: Introduction

    Manual 1. Introduction 42” Thank you for purchasing the TOPAZ Android SL Display. Please read carefully and follow all instructions in the manual before first use. multimedia Full HD The product should not be exposed to liquids dripping or splashing and no objects filled with liquids, such as vases, should be placed on the product.

  • Page 7: Remote Control

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Remote Control 42” multimedia Full HD...

  • Page 8: Replacing The Remote Control Battery

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Replacing the Remote Control Battery 1. Slide the battery cover off, as shown below. 42” 2. Remove the used batteries. multimedia Full HD 4. Insert the two new AAA batteries with their terminals corresponding to the indicators.

  • Page 9: Home Screen

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Home Screen Once your screen has powered up and begins to play content press the “STOP” button on the remote 42” control to go back to the Home Screen (pictured below).

  • Page 10: System Menu Operation

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual System Menu Operation From the Home Screen you can bring up the Main Menu by pressing the “SETUP” button the remote 42” control. The Main Menu includes following sub-menus: System Settings, System Control, Network Settings, Date &...
  • Page 11 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Display Language The On Screen Display supports multiple languages, the default being English. As with all menu operation press “DOWN” to access the sub-menu then use the navigation buttons to select the right 42”...
  • Page 12 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Screen Resolution This menu allows you to set the screen resolution; this should be set to 1920x1080. 42” multimedia Full HD On Screen Clock This option allows you to display a clock while content is playing. There are 5 options as pictured below: ...
  • Page 13 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Play Log When the slider is turned on (blue) the screen will record all media files that are displayed. 42” multimedia Full HD This allows you to enable or disable the USB port. If you want to be able to update the screen please...
  • Page 14 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Sync Settings This feature of synchronisation allows multiple screens to display the same content at the same time. 42” multimedia Full HD Sync Settings - enable or disable the feature of synchronisation.
  • Page 15 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Restore To Factory Settings Highlight “Yes” and press “PLAY” to restore factory settings; this will restore all system settings back to default. 42” multimedia Full HD Auto Start This feature allows your screen to start playing the pre-loaded content as soon as it has finished booting up.

  • Page 16: System Control

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 1.6.2 System Control 42” To exit a sub-menu please press the “LEFT” navigation button the remote control, you can now navigate though the Main Menus sub-menus. The sub-menus within this section are: Work Mode, Content multimedia Full HD Management, Content Storage and Machine Name.
  • Page 17 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Content Storage This should be set to “Internal Memory”. 42” multimedia Full HD Machine Name This feature will tell you what your screen’s name is on the CMS.

  • Page 18: Network Setting

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 1.6.3 Network Setting 42” To exit a sub-menu please press the “LEFT” navigation button the remote control, you can now navigate though the Main Menus sub-menus. To set accurate values first select the top “date” field by pressing multimedia Full HD “PLAY”.
  • Page 19 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Proxy Server Setup In most cases this should be turned off. If your network has a proxy server the slider should be turned on (blue), this will prompt three more options to appear: 42”...
  • Page 20 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual WIFI Setting This feature is only available when the screen is set to “WIFI” mode. It allows you to select your Wi-Fi network and input your password. This information will then be saved so that when the screen reboots 42”...

  • Page 21: Date & Time

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 1.6.4 Date & Time To exit a sub-menu please press the “LEFT” navigation button the remote control, you can now navigate 42” though the Main Menus sub-menus. As the screens are able to retrieve an accurate time from the server using Network Time Protocol you shouldn’t need to input manual values, the settings should be as...
  • Page 22 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Set the time using the same method, saving when complete. 42” multimedia Full HD...

  • Page 23: Power On/Off

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 1.6.5 Power On/Off 42” Using the CMS you can set up your screens on/off timer, should you want it to power on and off automatically at designated times. If you do not wish to manually set on/off times for your screen please multimedia Full HD set the “Control Mode”...

  • Page 24: Timer Strategy

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 1.6.6 Timer Strategy 42” This feature allows you to schedule your screen to play at different volumes at different times of the day multimedia Full HD and switch to different AV inputs at different times of the day. This can be achieved remotely using the CMS however if you wish to input these values manually you can do so.
  • Page 25 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Navigate to a timer field and press “PLAY” on your remote control. Activate the timer, set a volume level and also a start and end time. Finally navigate to and select “SAVE”.
  • Page 26 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Navigate to a timer field and press “PLAY” on your remote control. Activate the timer then set a start and end time and an AV input. Finally navigate to and select “SAVE”.

  • Page 27: File Management

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 1.6.7 File Management 42” Here, you can check storage information such as memory capacity, used space and free space. You can also format the disk. You should be extremely careful here as formatting the disk will result in a multimedia Full HD total loss of data.

  • Page 28: Display Settings

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Display Settings 42” As well as having a main system menu that can be accessed through your home screen, the unit also has a display setting menu for changing which input source is being displays as well as altering values such as brightness, contrast and saturation.
  • Page 29 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual System Setting 42” Here you can set the OSD Language to either English or Chinese using the “LEFT” and “RIGHT” buttons on your remote control. We recommend that you do not change any of the other settings in multimedia Full HD this menu.
  • Page 30 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 42” multimedia Full HD Exit To exit from this Display Settings menu, navigate to Exit and press “PLAY”. If inactive for more than 10 seconds, you will automatically exit this menu.

  • Page 31: System Operation

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 2. System Operation 42” multimedia Full HD Supported Media Files Media Type Supported File Type Image Video MPG, AVI, MP4 Audio 1. This unit does NOT support WMV or FLV video file types.

  • Page 32: Inputs

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Inputs 42” LAN – Local Area Network Input HDMI – High Definition Multimedia Interface Signal Input (for HD Video & Audio signal) multimedia Full HD VGA – Video Graphics Array Signal Input (for Video signal) 3.5mm Audio Input...

  • Page 33: F.a.qs And Troubleshooting Guide

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 3. F.A.Qs and Troubleshooting Guide 42” Why is my screen displaying "Error (Screen Mode Mismatch)"? multimedia Full HD If you have published a playlist and your screen is now displaying "Playlist: Error (Screen Mode Mismatch)"...

  • Page 34: How Do I Update My Screen If It Is Not Connected To The Internet? (Plug And Play Method)

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual of the screen. That is to say that if you have a Landscape screen then you should use a Horizontal template and if your screen is installed in Portrait orientation you should use a Vertical template.
  • Page 35 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Right-click on the screen you have sent the playlist to and select “Program Package”. 42” multimedia Full HD The “Program Package” window will then appear, click the “Pack Program” button.
  • Page 36 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual The “Program Package Type” window will then appear. Tick the “Select All” checkbox to send all timer, download, display and current weather data to the screen as well. Then click “OK”.
  • Page 37 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Once the download is complete your web browser will inform you and normally help direct you to your files. If you are using Google Chrome, select the option “Show in folder”.

  • Page 38: How Do I Play Powerpoint Presentations On My Display

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual How do I play PowerPoint presentations on my display? 42” You can save the PowerPoint presentation as a JPEG File Interchange Format (JPEG). Microsoft PowerPoint software allows the user to do this. Once you have done this, you can upload your JPEG images and send them to the screen using the CMS.
  • Page 39 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 2. Once you have finished downloading Format Factory, launch the software. 42” multimedia Full HD 3. Next, access the “Video” section of the Top Menu then click on “All to MP4”.
  • Page 40 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 4. Now click “Add File” 42” multimedia Full HD 5. Next, locate and select the video files you wish to convert and click “Open”.
  • Page 41 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual Now click “Output Setting”. 42” multimedia Full HD 6. Set your “Video Settings” to the following values, then click “OK”:...
  • Page 42 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 7. Click “OK”. 42” multimedia Full HD 8. Click “Start”.
  • Page 43 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 9. Your video will now be converted. You can track it’s progress with the “Convert State” bar. 42” multimedia Full HD 10. Now click “Output Folder” to access your converted video(s).
  • Page 44 Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 11. You will now be redirected to your converted videos. Please copy them to a location more convenient for uploading later. 42” multimedia Full HD...

  • Page 45: Hd Video Converter Deluxe (High Definition)

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual 3.4.2 HD Video Converter Deluxe (High Definition) 42” This is only really useful for High Definition videos. Download link: http://www.winxdvd.com/hd-video-converter-deluxe/ multimedia Full HD This software is not free.

  • Page 46: My Media File Does Not Fit Properly On The Screen

    Freestanding TOPAZ™ Android SL Display Hardware User Design Led – Solutions Driven Manual My media file does not fit properly on the screen This has happened because the file does not have a 16:9 aspect ratio (1920x1080). Please resize file to 42”...
