Huba Control 699 Operating Instructions Manual page 6

Complete configurable version
http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-M
(Adjustability 2)
1
(Adjustability 3 - with display)
1
p://www.sensor-ic.com/ TEL: 0755-83376489 FAX:0755-83376182 E-MA
6
2
7
5
4
2
5
4
3
6
3
Huba Control AG - 699/full - Edition 08/2012 - 114507
1. DIP-Switch (tenfold)
2. Zero point reset
3. Connecting terminals
4. Pressure connectors
P1 and P2
5. Turbo potentiometer
(Signal amplifications potentiometer)
6. LCD
(by adjustability 3 only)
7. LCD receptacle
