Poppstar MS30 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BRIEF INTRODUCTION ......................................................................................... 2
................................................................................................................. 2
........................................................................................................ 3
PRODUCT DETAILS ............................................................................................... 5
.......................................................................................................... 5
............................................................................................................ 5
V
............................................................................................................... 6
V
............................................................................................................. 7
................................................................................................... 8
BASIC OPERATION................................................................................................ 9
................................................................................................... 9
OPERATION OF PRODUCT USAGE ................................................................ 14
.......................................................................................................... 15
.................................................................................................. 20
......................................................................................................... 20
................................................................................................ 24
MAINTENANCE NOTICE ..................................................................................... 25
COMMON FAULTS AND TROUBLE SHOOTING ........................................... 26
OTHERS .................................................................................................................. 27
MS30 USER MANUAL
Content
.............................................................................................. 2
................................................................................ 12
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Poppstar MS30

Summary of Contents for Poppstar MS30

  • Page 1: Table Of Contents

    MS30 USER MANUAL Content BRIEF INTRODUCTION ..................2 ......................... 2 EATURE ....................2 ASIC PERFORMANCE ......................3 PECIFICATION PRODUCT DETAILS ....................5 ......................5 ACKING LIST ......................5 RONT VIEW ....................... 6 ......................7 ....................8 EMOTE CONTROL BASIC OPERATION....................9 ....................

  • Page 2: Brief Introduction

    Brief introduction Feature The product is a new kind of multimedia player product. The product can provide good watching. Meanwhile, it can also store and play many kinds of video files. The product, which facilitated with many port, can show you picture and video with high definition.

  • Page 3: Specification

    Specification USB host Support multiple USB storage Network RJ45 10/100M connect connection Video output Composite video /HDMI Audio output Stereo/digital HDMI/Optical MP3,WMA,WAV,AAC,OGG, Dolby digital AC3 Audio Video decode MPEG 1/2/4, Divx,Xvid, H.264,WMA,VC-1 Video Format: WMV,MKV,MOV,AVI,MP4,MPG,TS/M2TS/TP,ISO,IFO, VOB,DAT Subtitle SSA SMI SRT SUB Picture JPG/BMP/PNG/GIF AC input 100V 240V...
  • Page 4 VC-1 1920 1080P VIDEO 1920 1080P 1920 1080P H.264 1920 1080P 1920 1080P Support Support Support AUDIO Support Support Dolby digital AC3 Support JPG/JPEG Support Support PICTURE Support Support(support a static display only) Note: Up to the improvement, the appearance and specification will be changed accordingly without notice.

  • Page 5: Product Details

    Product details Packing list Check the accessories after receive the product. If there are some missing, please contact immediately with your supplier to insure your consumer’s right. Name Quantity Media player 1 pcs Power Adapter 1 pcs Remote Controller 1 pcs AV cable 1 pcs User Manual...

  • Page 6: Side View

    Button description Remark Button Description A short press on the button Power on/off turns on or turns off power Receives signals from the remote control. Point the tip of the remote control to Infrared receiver the infrared receiver and ensure that the path between the two is unobstructed.

  • Page 7: Back View

    Back View Port definition Instruction Port Port definition DC IN Power port Can input power Audio output Can output digital audio Optical port signal Composite Can output composite video video output port and audio High definition Can output digital signal via HDMI port HDMI port...

  • Page 8: Remote Control

    Remote control BUTTON FUNCTION POWER Turn on and off in the stand by mode MUTE Turn on or shut audio output Press to switch between NTSC, PAL, 480P, 576P, TV SYSTEM 720P 50HZ, 720P 60HZ, 1080I 50HZ and 1080I 60HZ, 1080P 50HZ,1080P 60HZ.

  • Page 9: Basic Operation

    COPY Enter the copy mode SELECT Press to select copy files or folders in the copy mode CONFIRM No role for the time being Press to display time, title, information of chapter when DISPLAY play video and photo SUBTITLE Switch the subtitle if the file supported Press to have slow motion: 1X, 3/4X 1/2X 1/4X 1/8X SLOW 1/16X.Press PLAY to resume regular play mode.
  • Page 10 avoid any problem. Composite output connection(AV) Plug the yellow connector into the AV output of product and AV input of TV, and plug the red and white connector into the audio input of TV or HIFI. Turn on the TV and select AV mode. Turn on the product and TV displays the interface of initiation.
  • Page 11 Optical output Connect the product optical connector with the other one from video or audio device by optical cable. Then enter the product's audio interface, select the Digital Output option "SPDIF LPCM" or "SPDIF RAW". It is available to enjoy 5.1 high quality sounds through a multi channel decoder/amplifier with optical input.

  • Page 12: Operation Of File Sharing

    “OK” to confirm. It is available for both automatic and manual IP setup. Press “setup” key again to exist after setup. Please see " Wired Lan Setup " for more details. Before access the PC through network by the product, the media files must be shared in the network.
  • Page 13 9. Finally, please close the Windows Network Connection Firewall Operation of file sharing under Windows Vista Please make sure that the Vista operation system is installed as Administrator supper user. From the desktop select ”start- setup-control panel-select user account” Open User account and select” open a new account” and name it “Guest” Select the folder need to share and right click the mouse, then select the “sharing”...

  • Page 14: Operation Of Product Usage

    The player supports USB connected external DVD drive. The product can play DVD through connecting to external drive by USB. Meanwhile, content in DVD can also be copied to the hard disk, and then operations like backup information and so on can be done. Connect the USB CD drive to the peripheral port of the product through USB data line, then choose “...

  • Page 15: Main Menu

    Note: While connect the power supply for the first time, the device will power on automatically and appear the below menu: Please read the following instructions carefully to understand the function of each option. Main Menu The main menu allows you browse and play music, photo and movie files stored on external USB devices, Memory cards,Network.
  • Page 16 Press “ ” and “ ” to select the folder containing your photo files. Enter the folder press “ ” and “ ” to select the photo you want to view and press OK the photo is displayed full screen. Note: 1.
  • Page 17 Press “ ” and “ ”to select the folder(s) containing your all files(Beside Music ,Photo and Movie). Enter the folder press “ ” and “ ”to select the file you want to view and press OK to play. NETWORK When data on HDD,USB device is connected the system to Network, you can also browse photos, listen to musics, and watch videos.
  • Page 18 then open the UPNP share function in the software, so that the access speed can be quickened largely. For example, connect the player to the family LAN, and then multimedia documents shared in the Media Player 11 software in the computer in study can be accessed in the living room through UPNP.
  • Page 19 you want among plenty of documents, bringing convenience. All the above are advantages of UPNP. File Edit Menu Press “ ” and “ ”to select the file or folder, press OPTION to display the Edit tab. Return Select to return to the main screen. To rename a file, do the following: 1.

  • Page 20: File Copy Menu

    File Copy Menu The File Copy allows individuals to copy files between USB, Memory cards, NET. Select “File Copy” from the Guide menu or select “COPY” on the remote control .It is very easy to copy files between various devices. Copying operation Step 1: Select Source Device Press “...
  • Page 21 to enter the setup menu. It is possible to configure Photo, Audio, Video, Network and System. Select any option by pressing “ ” and “ ” on the remote controller, and press OK to confirm or press “Return” to exit. Press “Setup” button again on remote control to exit from setup menu.
  • Page 22 Letter Box 4:3, Display a wide picture with two black borders on top and bottom of 4:3 screen when a standard 4:3 TV is connected. 16:9: Compress the image to convert the whole image when a 16:9 TV is connected. Select to set brightness levels.
  • Page 23 Select to set the transition effect of photos. Press “ ” and “ ” to select the transform of photo you require: 1) Cross Fade – fade in and fade out 2) Left to Right- from left to right 3) Top to Bottom- from top to bottom Transition 4) Waterfal l- like a steep descent of water from a height Effect...

  • Page 24: Wired Lan Setup

    You can streaming playback the multimedia files from network and have file copy function through network. Wired Lan Setup Access the player to LAN, and press “Setting” in the remote control to enter the setting interface of the player. Select “Network” and enter “Wired Network Setting”.

  • Page 25: Maintenance Notice

    network share. Input your user name, password and IP address of the appointed document server. User name is GUEST or EVERYONE and the IP address of the appointed document server is the IP address of the computer that has set network share. There can be many sharable computers in the wire network, input the IP address of the computer you want to access.

  • Page 26: Common Faults And Trouble Shooting

    please be sure of aeration under normal working status, do not put the device in bed, sofa, or similar area where cooling effect is no good. please do not teardown personally, but send it back to the pointed service agent, or there will be danger of electronic shock. please pull out the cable and shut the device immediately when cable broken or liquid in, and send to pointed agent for repair.

  • Page 27: Others

    The video cable is not properly inserted. Please properly insert the video cable and make sure it is properly connected to the TV. The output signal of the player does not match the signal source of the TV. Press “Video” on the No image on TV remote control to switch video output until there is image.
