Table of contents
Packing list................................................
1. spec .....................................
1.1
function list..................................
1.2
Parameter..................................
1.3
Install HDD..................................
1.4
Connectors..................................
2. Remote control definition........
3. User guide.....................................
3.1
main menu.....................................
3.2
movie playback.....................................
3.2.1 subtitle .....................................
3.2.2 Time seek.....................................
3.2.3 subtitle info.....................................
3.3
Music playback.....................................
3.4
Photo playback.....................................
3.5
Play tv programe.....................................
3.6
File list.....................................
3.7
Set up.....................................
3.7.1 setup method.....................................
3.7.2 AV setting................................
3.7.3 Parameter setting.....................................
3.7.4 Network setting.....................................
3.7.5 Save and exit.....................................
3.8
Firmware upgrade.....................................
EG-M31H/M33H manual V1.0
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Egreat EG-M33H
Summary of Contents for Egreat EG-M33H
-
Page 1: Table Of Contents
EG-M31H/M33H manual V1.0 Table of contents Packing list..........1. spec ........function list........Parameter........Install HDD........Connectors........2. Remote control definition…….. 3. User guide........main menu........movie playback........3.2.1 subtitle ........3.2.2 Time seek........3.2.3 subtitle info........Music playback........Photo playback........Play tv programe........ -
Page 2: Packing List
EG-M31H M31H unit Remote control power adapter（DC 12V/3A） USB cable USB extension cable HDMI cable AC cable CD-R Screw bag EG-M33H-DVB（DMB） M33H-DVB unit Remote control power adapter（DC 12V/3A） USB cable USB extension cable HDMI cable AC cable CD-R Screw bag... -
Page 3: Spec
EG-M31H/M33H manual V1.0 1. Spec 1.1 Function list Video format: MKV 、 TS 、 TP 、 M2TS 、 AVI 、 MPG、MOV、MP4、ASF、MPEG、VOB、DAT. Video decode: H.264 、 VC1 、 WMV 、 MPEG1/2/4 、 Divx 、 Xvid, resolution is up to 1080P（1920*1080）. Support full HD 1080P output, and support 1080I 、... -
Page 4: Parameter
EG-M31H/M33H manual V1.0 1.2 Parameter Power adapter DC12V/3A Remote Control 50 button remote control Video output AV output YpbPr output HDMI 1.3 output Audio output stereo SPDIF optical output,5.1 channel Files format FAT32, NTFS,EXT2,EXT3 Photo JPG、BMP、GIF、PNG Audio MP3、WMA、OGG、AAC Video MKV、TS、TP、AVI、MPG、M2TS、VOB、 MOV、MP4、ASF、DAT H.264、VC1、WMV、MPEG1/2/4、Divx、... -
Page 5: Install Hdd
EG-M31H/M33H manual V1.0 1.3 Install HDD For M31H 1). Open the case: 2). Plug the SATA HDD into the SATA interface. The hole locations should match with the fixed column on the metal plate. - Page 6 EG-M31H/M33H manual V1.0 3). Pay attention to the fan. It should be connected to the case too. 4). Fix the HDD with 2 screws as shown below. 5). Close the case using the 4 screws, which were included from the factory.
- Page 7 EG-M31H/M33H manual V1.0 For M33H Push button according arrow mark,pull out the bracket. At same time,get 4pcs screws from the screw bag(3.5*7 spec) According the arrow mark,push hdd into the bracket and fix it by screws.Put the hdd with bracket into unit,press the handle for fixup.
-
Page 8: Connectors
EG-M31H/M33H manual V1.0 Pls don’t press forcibly during mounting 1.4 Connectors... - Page 9 EG-M31H/M33H manual V1.0 Notice: defaut output is 720p. If you want to get more high resolution,pls press output button for switching.
-
Page 10: Remote Control Definition
TV MODE hot key for switching output mode （ 480p-720p-1080i- 1080p） 16：9 16:9/4:3 ratio switch Hot key into tv play（for EG-M33H-DVB OR DMB） FILE Hot key into file managemen FUNCTION Copy or delete files SLIDESHOW Slide show... - Page 11 EG-M31H/M33H manual V1.0 Fast backward key PLAY/PAUSE PLAY/PAUSE Fast forward key STOP stop RETURN Return to previous menu navigation alphanumeric buttons Program switch(DMB/DVB model) Recorder instantly(DMB/DVB model) SUBTITLE Turn on/off subtitle AUDIO Switch audio track INFO Check information of video files Book mark save/play;recorder/stop...
-
Page 12: User Guide
EG-M31H/M33H manual V1.0 3.User guide 3.1 main menu... -
Page 13: Movie Playback
EG-M31H/M33H manual V1.0 Press “ ” to select what you need,press “enter” for confirm. Whenever you can enter corresponding page when press”video/music/photo/tv/file” button of the remote control. 3.2 Movie playback Slelect movie icon and press enter to enter movie file list; or press hotkey of “movie”... - Page 14 EG-M31H/M33H manual V1.0 Press “ / ” to select movie,”enter” for playing. Press “ ” to return previous menu. Press”time seek”,use left/right button to select any segment movie.
-
Page 15: Subtitle
EG-M31H/M33H manual V1.0 Press “ / ” to select items. Press ”info” to display or hide subtitle menu. 3.2.1 Subtitle Subtitle synchronization: If some movie has issue of audio track and subtitle synchronization,users can use this function to adjusting. If subtitle is delayed,then use ahead x.x seconds; If subtitle is ahead, then use delay x.x seconds. -
Page 16: Time Seek
EG-M31H/M33H manual V1.0 Subtitle encoding: Adjust subtitle to suitable one. 3.2.2 Time seek press time seek button,it will display time bar.Left is playing time point,right time is playing time. During time seeking,user can select any movie segment through pressing button“ / ” to locate playing time. -
Page 17: Subtitle Info
EG-M31H/M33H manual V1.0 Notice： 1）Time bar won’t disappear automatically,users can check playing time by this time bar. 2 ） During time seeking,some play function can’t worksuccessfully.Pls press time seek button again.Then it’s 3.2.3 Subtitle info During playing movie,press ”info” to display movie informations. -
Page 18: Music Playback
EG-M31H/M33H manual V1.0 Notice: Press ”info” again hide these informations. 3.3 Music playback Press music icon or press music hotkey of remote control to enter music playback menu. - Page 19 EG-M31H/M33H manual V1.0...
-
Page 20: Photo Playback
EG-M31H/M33H manual V1.0 3.4 Photo playback Press photo icon or press photo hotkey on the remote control to enter photo playback menu. 图 3.4.2 图片文件浏览页面... -
Page 21: Play Tv Programe
EG-M31H/M33H manual V1.0 Press “ ” to next page Press “ ” to previous page; Press “ / ” to select picture or menu. Press ‘’ to previous munu. Press “ ” to play or pause slide show. Press “ ”... - Page 22 EG-M31H/M33H manual V1.0 Tv play main menu: Tv program seek icon Recorder icon EPG icon Exit playing,return to main menu...
- Page 23 EG-M31H/M33H manual V1.0 Tv channel seek： Press this icon,system will seek program automaticall.During seeking,user can stop and save seek result. TV recordering. Press this icon to display recordering status. At same time,check/add/modify recordering task. Use “ / / / ” to select items: sequence number; Program number,year,month,date,hours,minutes,seconds, length of recordering time.Then ajus them by Vol+/-.
- Page 24 EG-M31H/M33H manual V1.0 3.5.7 节目录制项编辑页面 Notice:task of recordering is unique,modify or delete shoule based on the unique sequence number.Up to 8 recorder task. EPG: Display one week EPG informations. Exit tv play,return to main menu.
-
Page 25: File List
3.6 File list Press file icon or press file hotkey on the remote control to enter file menu. icon of file Notice:EG-M33H-DMB and EG-M33H-DVB has nofile icon,need press file button on the remote control to enter. Press“ ” to next page Press“... -
Page 26: File Copy
EG-M31H/M33H manual V1.0 Notice : 1 ） under file browse mode,video files can’t be played,pls note!. 2 ） under file mode. “ ” can’t return to previous catalogue.users need press”upper folder” to return. File copy Select target folder copyed in from right list; select files will be copyed from right list,press “function”... - Page 27 EG-M31H/M33H manual V1.0 Select file and press “function”button and select “delete” to execute.Files can’t be recovery after delete.
-
Page 28: Setup
EG-M31H/M33H manual V1.0 3.6 Setup Press file icon or press file hotkey on the remote control to enter file menu. Setup icon AV parameter setup basic parameter setup network parameter setup exit 3.7.1 setup method press“ / ” to select item； press“... -
Page 29: Av Setting
EG-M31H/M33H manual V1.0 3.7.2 AV setting Audio setting: Analog audio output:Pls keep HD audio pass through off when you want to use analog output.At same time,SPDIF can output PCM too. Digital: pls keep HD audio pass throught on when youuse AMP. Display ratio：... -
Page 30: Parameter Setting
EG-M31H/M33H manual V1.0 If there is no signal output,pls use“ / ” to change to other mode. It will output signal under any mode ,premise is connect with CVBS or HDMI connectors. 3.7.3 Parameter setting Auto play from power on: ON: Auto play first media file from root directory of first partition. -
Page 31: Network Setting
EG-M31H/M33H manual V1.0 Notice ： 1）after factory restore,pls setting all paramete ragain. 2）default setting won’t cover language settings. 3.7.4 Network setting Network type: LAN and wireless Network IP mode including static mode and dynamic IP. Notice : IP address/net mask/gateway/DNS will work based on only static mode. -
Page 32: Save And Exit
EG-M31H/M33H manual V1.0 Press”enter” to active keyboard,select number which you need through “ / / / ” button,press “enter”(on the remote control) for confirm. After finishing input,select “enter” on this keyboard and press “enter” of remote control to hide this keyboard. -
Page 33: Firmware Upgrade
EG-M31H/M33H manual V1.0 Select exit icon,and confirm if you want to save all those new parameter change. 3.8 Firmware upgrade 1.Download new FW from this website: http://www.egreatworld.com/support.asp 2.How to upgrade FW 2.1.1 Copy the new FW into root directory of usb device, then connect with your unit through usb host and reboot it. - Page 34 EG-M31H/M33H manual V1.0 Notice: pls keep power on during upgrading.
- Page 35 EG-M31H/M33H manual V1.0 2.2.3 It will cost 3~5 minutes,there will be a schedule bar for checking. When the FW finished upgrade,system will remind you to reboot player.Then turn on the player and enter system setting page to check and confirm. Ps: if there is no selection for your country,pls refer to below bandwidth,and select matched one.
