G100 GPON Terminal
User Guide
V 1.0
Release Date 2013-08-05
Copyright Statement
is the registered trademark of Shenzhen Tenda Technology Co., Ltd.
All the products and product names mentioned herein are the trademarks or registered
trademarks of their respective holders. Copyright of the whole product as integration,
including its accessories and software, belongs to Shenzhen Tenda Technology Co.,
Ltd. Without prior expressed written permission from Shenzhen Tenda Technology
Co., Ltd, any individual or party is not allowed to copy, plagiarize, reproduce, or
translate it into other languages.
All photos and product specifications mentioned in this manual are for references
only. Upgrades of software and hardware may occur; Tenda reserves the right to
revise this publication and to make changes in the content hereof without obligation to
notify any person or organization of such revisions or changes. If you would like to
know more about our product information, please visit our website at
Advertisement
Table of Contents
Related Manuals for Tenda G100
Summary of Contents for Tenda G100
-
Page 1: Copyright Statement
All photos and product specifications mentioned in this manual are for references only. Upgrades of software and hardware may occur; Tenda reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. -
Page 2: Table Of Contents
User Guide http://www.tendacn.com. Contents Chapter 1 Product Overview ......................4 1.1 Overview ........................... 4 1.2 Package Contents ......................4 1.3 Product Features ....................... 4 Chapter 2 Hardware Description ..................... 5 2.1 Panels ..........................5 2.1.1 Front Panel ......................5 2.1.2 Back Panel ......................5 2.2 Basic Requirement ...................... - Page 3 User Guide 4.4.1 System Log ......................13 4.4.2 Statistics ....................... 14 4.4.3 User Management ....................14 4.4.4 Firmware Update ....................15 4.4.5 Restore to Factory Default ..................15 4.4.6 Reboot ........................16 Appendix A FAQ ..........................17 Appendix B Technical Specifications ....................19 1.
-
Page 4: Chapter 1 Product Overview
Ethernet cable Quick Install Guide If any of the above items is incorrect, missing, or damaged, please contact your Tenda reseller for immediate replacement. 1.3 Product Features Support one PON port; Support WEB firmware update and provide the latest firmware;... -
Page 5: Chapter 2 Hardware Description
User Guide Chapter 2 Hardware Description 2.1 Panels 2.1.1 Front Panel LED: Color Status Description Improper power connection. Gree Solid Proper power connection. No GPON connection is established. Gree Solid Proper GPON connection is established. Blinking GPON connection is being established. No connection is established on this port. -
Page 6: Back Panel
User Guide 2.1.2 Back Panel PON: Port for connecting fiber (Do not look steadily at it in case of eye damage). LAN: RJ-45 port for connecting to a hub, switch or PC (installed with NIC). Reset: Reset button for restoring default factory settings. Press it for 5 ... -
Page 7: Chapter 3 Installation
User Guide device through the ventilation hole. Please cut off power supply immediately, pull out all cables and contact the specified maintenance staff if any fault happens. Disconnect the power supply and pull out all cables, such as the power cord, ... -
Page 8: Configure Pc
User Guide Steps are as follows: Step 1: Connecting PC, set top box, hub or switch to the LAN port on this device with Ethernet cable. Step 2: Connecting to the PON port on this device with fiber (Please select single mode fiber and the PON port and GPON ONU port should be the SC type. - Page 9 User Guide Select Internet Protocol (TCP/IP) and click Properties; Select Use the following IP address, enter 192.168.1.X (X: 2~254) and 255.255.255.0 in corresponding blanks and click OK to save the configurations.
- Page 10 User Guide _______________________________________________________________________________ Note: This device does not support DHCP feature, thus you have to configure your PC manually. As for Windows 98 or earlier version of operation systems, after the above mentioned configuration, you may need to restart your PC. _______________________________________________________________________________ D.
-
Page 11: Login
User Guide 2) If you get a screen as the following, It indicates installation failure still exists. Please verify the following step by step： a. The physical installation is correct. The LAN LED on the device and NIC LED on your PC should be lighted. b. - Page 12 User Guide...
-
Page 13: Chapter 4 Advanced Settings
User Guide Chapter 4 Advanced Settings 4.1 Status This section allows you to view this device’s current system status, LAN info, UNI info, PON info and optical info. 4.1.1 System Status This page displays the system info, including model NO., device ID, hardware version, software version and uptime. -
Page 14: Uni Info
User Guide 4.1.3 UNI Info This page displays current UNI info, including connection status, mode and speed of the LAN port. Click Refresh to refresh current info. 4.1.4 PON Info This page displays the WAN info, including WAN connection status, enable upstream FEC, enable downstream FEC. -
Page 15: Optical Info
User Guide 4.1.5 Optical Info This page displays current optical info, including optical module temperature, optical module power feed volt, optical module bias current, optical module TX power and optical module RX power. Click Refresh to refresh current info. 4.2 Network This section allows you to configure LAN and PON settings. -
Page 16: Pon Setting
User Guide IP Address: Device's LAN IP address. The default is 192.168.1.1. You can change it according to your need. Subnet Mask: Device’s LAN subnet mask, 255.255.255.0 by default. For normal network connection, do not change it unless necessary. After the configuration, click Apply/Save to save your settings. _______________________________________________________________________________ Note: 1. -
Page 17: Safety
User Guide Current Password: Device’s current password. No password by default. New Password: Enter the new password provided by your ISP. After the configuration, click Apply/Save to save your settings and the new password will be displayed in the Current Password blank. Current SN: Device’s current certificated SN. -
Page 18: Mac Filter
User Guide 4.3.1 MAC Filter Enable: Select it to enable MAC filtering setup. Policy: Select FORWARD or BLOCKED. FORWARD: Entries allowed to access. BLOCKED: Entries forbidden to access. Change: Select it to switch the policy. Change Policy: Click to confirm the policy switch. Add/Remove: Click the Add button or the Remove button to configure the MAC filtering rules list. - Page 19 User Guide Click View System Log to view the current system logs. Click Configure System Log to configure current log level. Log: Enable it to record logs or Disable it not to record logs.
-
Page 20: Statistics
User Guide Log Level: Select the log level, including emergency, alert, critical, error, warning, notice, informational and debugging. Display Level: Select log’s display level, including emergency, alert, critical, error, warning, notice, informational and debugging. _______________________________________________________________________________ Note: If you select Disable, all system logs will be lost. _______________________________________________________________________________ 4.4.2 Statistics Here you can view the send packets and receive packets of the PON, OMCI and UNI... -
Page 21: Firmware Update
User Guide _______________________________________________________________________________ Note: 1. For safety, you’d better change the password. If you forgot the password, please press the reset button to restore default factory settings. 2. If the user name and password error occurs three times continuously, the system will be locked, but unlocked automatically one minute later. -
Page 22: Restore To Factory Default
User Guide Browse: Click to locate and select the firmware. Update Software: Click to update firmware. Device will restart automatically when update completes. _______________________________________________________________________________ Note: 1. Before you upgrade the firmware, make sure you are having a correct firmware. A wrong firmware may damage the device. 2. -
Page 23: Reboot
User Guide Subnet mask: 255.255.255.0. User name and password: admin/admin or user/user. 4.4.6 Reboot Click the Reboot button to restart the device. -
Page 24: Appendix A Faq
User Guide Appendix A FAQ Q1: What should I do if I forget the login user name and password (How to reset this device)? Press the RESET button on the back panel for 5 minutes to restore default factory settings. _______________________________________________________________________________ Note: 1. -
Page 25: Appendix B Technical Specifications
Ensure your PC is functioning properly; If the above-mentioned problems do not exist, please contact your ISP. Appendix B Technical Specifications 1. Specifications Item G100 Size (length×width×height) 116*90.5*24mm Weight ( including the power adapter) 196g Power Supply Specification 12V1A... - Page 26 User Guide...
-
Page 27: Appendix C Abbreviations
User Guide Appendix C Abbreviations DHCP: Dynamic Host Configuration Protocol GPON: Gigabit-capable Passive Optical Network G FTTH: Fiber To The Home ISP: Internet Service Provider LAN: Local Area Network ONU: Optical Network Unit OLT: Optical Line Terminal PON: Passive Optical Network PPPoE: Point to Point Protocol over Ethernet QoS: Quality of Service VLAN: Virtual Local Area Network... - Page 28 User Guide interference, in which case the user may be required to take adequate measures. This device complies with EU 1999/5/EC. NOTE:(1)The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment.(2) To avoid unnecessary radiation interference, it is recommended to use a shielded RJ45 cable.
- Page 29 User Guide antenna or transmitter. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator &...
