Instruction Manual
5. Trouble Shooting:
Symptom A Cannot be turned on
Figure
Root causes Defective power key
Correction
Replace the power key
Symptom B
Motor operates but no spray is generated
Figure
Root Causes Run out of liquid medication
Correction
Refill the medication cup
6. Recommended Parts List:
Please refer the below parts to the exploded drawing
Medication cup
Mouthpiece
Symptom C Low spray volume
Figure
Defective power wires
Root Cause
Replace the power wires
Correction
Symptom D Machine shuts down suddenly during operation
Figure
Root Cause
Air tube is not connected properly
Re-connect the air tube and
Correction
medication cup properly
Air tube
Filter
Valve is open
Nozzle is clogged
Adjust the valve
Rinse the nozzle with
water
Motor automatically shuts down due to overheat
Wait for the temperature to drop, which takes about 20 minutes
Adult and Child mask
Cover and diverter
Defective filter
Replace the filter
Nozzle
Rossmax Swiss GmbH,
Tramstrasse 16, CH-9442 Berneck, Switzerland
Service Manual
Document No.: SM-11-012 Version: 2
ROSSMAX Model No.
NA100 Nebulizer
www.rossmax.com
