OYEN DIGITAL Mobius User Manual

(7) Sleep Mode
The Mobius 2-Bay does not have an auto-sleep timer. However,
it will follow the sleep settings of the computer. When your computer
enters sleep mode, the drives inside the Mobius will spin down.
(8) RAID 1 Rebuild
If one of the drives fail, the drive's LED will change from BLUE to
RED when connected to a computer. A new HDD can be installed
and will automatically rebuild with data (if con gured for RAID 1).
Note: The replacement drive must be a new, unformatted drive
with the same capacity as the original.
1. Power down the Mobius.
2. Remove the failed drive.
3. Install the new drive and power up the Mobius.
4. The LEDs will blink twice per second, which indicates a
rebuild in progress. This can take several hours.
(9) Troubleshooting and FAQ
1) Does a "Clear" procedure delete data from existing RAID 1 or
JBOD drive(s)?
No, if a Clear procedure is performed on RAID 1 or JBOD drives, the
existing data on the drives will not be deleted.
2) Can I remove a drive from the RAID and install it in another
enclosure for access to the les?
Yes, only if using RAID 1(Mirroring) or JBOD.
3) The Mobius is connected to a Mac Yosemite computer via FW800.
The Mobius appears in Disk Utility, but I am unable to format the
drive(s). Why?
The issue may be caused by the Yosemite FireWire driver. Please
disconnect from FW800 and connect using USB to format the drive(s).
After completion, reconnect via FW800 to access the formatted volume(s).
(10) Warranty Information
This product includes a two (2) year repair/replacement
warranty provided by Oyen Digital. This warranty is non-
transferable and is limited to the original purchaser. Warranty
service may be requested by completing the form at the
following link: www.oyendigital.com/rma-request-form.html
For our complete warranty policy, visit:
www.oyendigital.com/warranty.html
Mobius 2-Bay RAID System
User Guide
Table of Contents
1 Speci cations
2 Detailed View
3 Inserting or Removing Drives
4 Setup
5 RAID Modes
6 Formatting
7 Sleep Mode
8 RAID 1 Rebuild
9 Troubleshooting and FAQ
10 Warranty Information
