Related Manuals for Philips AJ5030
Summary of Contents for Philips AJ5030
- Page 1 Always there to help you Register your product and get support at www.philips.com/welcome AJ5030 Question? Contact Philips User manual...
-
Page 2: Table Of Contents
Contents 8 Troubleshooting 9 Notice 1 Important Disposal of your old product and batteries Risk of swallowing batteries 2 Your clock radio Introduction What's in the box Overview of the main unit 3 Get started Install battery Connect power Plug and set Select time zone Set clock Select DST (daylight saving time) mode... -
Page 3: Important
1 Important Risk of swallowing batteries • The product or remote control may • Read these instructions. contain a button cell battery, which is • Heed all warnings. possible to be swallowed. Keep the battery • Follow all instructions. out of reach of children at all times! If • Do not block any ventilation openings. -
Page 4: Your Clock Radio
2 Your clock radio Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome. Introduction With this unit, you can: • listen to FM radio; • know the time; • wake up to buzzer alarm, radio, or melody;... -
Page 5: Overview Of The Main Unit
Overview of the main unit... - Page 6 12/24 H TIME ZONE FLIP RADIO RADIO BUZZ BUZZ g RADIO a Focus ring • Turn FM radio on or off. • Adjust sharpness of the projected • Turn off the ringing alarm. image. h SLEEP b HR/TUNING +/- • Set sleep timer. • Adjust hour.
-
Page 7: Battery Tray
l 12/24H·DST • Select 12/24 hour format. • Select daylight saving time (DST) option. m TIME ZONE • Set time zone. n FLIP • 0°/180°: reverse the projected image. o AL1/RADIO·BUZZ · • Select alarm source for Alarm 1. p AL2/RADIO·BUZZ · • Select alarm source for Alarm 2. -
Page 8: Get Started
3 Get started Always follow the instructions in this chapter in 12/24 H TIME ZONE FLIP RADIO RADIO sequence. BUZZ BUZZ CLOCK RADIO AJ 5030 Install battery Warning Plug and set • Risk of explosion! Keep batteries away from heat, sunshine or fire. -
Page 9: Set Clock
Set clock In standby mode, you can set clock manually. SET TIME Select DST (daylight saving time) mode For countries with daylight saving time (DST), the clock radio offers you DST option to adjust summer time. In standby mode, press and hold 12/24H·DST for two seconds. -
Page 10: Listen To Fm Radio
4 Listen to FM Store FM radio stations radio manually Tune to an FM radio station. Press PROG. » The preset number begins to blink. Tune to FM radio stations Press PRESET +/- or TUNING +/- repeatedly to select a number. Note Press PROG again to confirm. -
Page 11: Set Alarm Timer
5 Set alarm timer Press AL1/AL2 again to activate or deactivate the alarm timer. » AL1 or AL2 appears if alarm timer is on and disappears if it is off. • To stop alarm, press the corresponding AL1/AL2 (or RADIO). Set alarm time »... -
Page 12: Other Features
6 Other features To reverse the projected image, switch FLIP to left or right. 17° Set sleep timer This clock radio can switch to standby mode automatically after a preset period. 90° Press SLEEP repeatedly to select the sleep timer period (in minutes). »... -
Page 13: Product Information
Search Selectivity FM: <28 dBu Total Harmonic Distortion FM: <3% Signal to Noise Ratio FM: >45 dB General information AC power Model: AS030-060- EB050 (Philips); Input: 100-240 V ~, 50/60 Hz, 0.15 A; Output: 6 V 0.5 A Operation Power <3W Consumption Standby Power <1W... - Page 14 If you encounter problems when using this device, check the following points before requesting service. If the problem remains unsolved, go to the Philips Web page (www. philips.com/support). When you contact the Consumer Care, make sure that the device is nearby and the model number and serial number are available.
- Page 15 WOOX Innovations may void the user’s 2014 © WOOX Innovations Limited. All rights authority to operate the equipment. reserved. Philips and the Philips’ Shield Emblem are registered trademarks of Koninklijke Philips N.V. Note and are used by WOOX Innovations Limited • The type plate is located on the bottom of the under license from Koninklijke Philips N.V.
- Page 16 2014 © WOOX Innovations Limited. All rights reserved. Philips and the Philips’ Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used by WOOX Innovations Limited under license from Koninklijke Philips N.V. AJ5030_93_UM_V2.0...
