- Page 1 INTEGRATED VARI-FOCAL CAMERA PIH-402X/404X Series INSTRUCTION MANUAL...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. GRAPHIC SYMBOL EXPLANATION The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"... - Page 3 CAUTION Do not drop or strike this equipment. Sensitive electronics inside are vulnerable to excessive shock. Do not install the equipment near any naked flames or heat sources. Excessive heat could damage this unit. Do not expose this unit to rain or excessive moisture, avoid smoke and dust.
- Page 4 CONGRATULATIONS Thank you for purchasing this high quality color camera. You now own one of the many fine CCTV products we manufactured. This product has been carefully inspected under rigid quality control and should reach you in perfect condition. With reasonable care, it will provide years of reliable performance.
- Page 5 WARRANTY INFORMATION Please complete the following product purchase information. The factory will requests this information when contacted for technical support, or warranty repair. It is also valuable in case of loss or theft. Purchase Date Serial Number Model Number TABLE OF CONTENTS FEATURES PART DESCRIPTION INSTALLATION...
- Page 6 FEATURES The 1/3" vari-focal color camera has a CCD image sensor and all solid state circuitry, which will provide extremely long life with high reliability. The PIH-402 & 404 series camera offers excellent picture reproducibility with low lag and high burn resistance. It is resistant to distortion from magnetic fields, shock and vibration and will operate reliably in a wide range of temperatures.
- Page 7 AUTO WHITE BALANCE Automatic adjustment of the light source color temperature in order to maintain perfect picture color. APERTURE CORRECTION Refining capture image outlines for a sharper video image. AUDIO OUTPUT Built-in highly sensitive capacitive microphone allows setting up of audio monitoring system.
- Page 8 SIDE VIEW VARI-FOCAL CAMERA IRIS REAR PANEL AUDIO AUDIO VIDEO VIDEO POWER POWER IRIS IRIS LEVEL LEVEL +12V DC 12V AC24V/DC 12V PIH-4022/4042 PIH-4026/4046 Microphone Fixing for mounting base Lens cover VIDEO AUDIO POWER Lens hood Focus adjustment lever Zoom (View angle) IRIS LEVEL adjustment lever...
- Page 9 INSTALLATION FITTING THE CAMERA 1. The mounting base can be attached to either the top or bottom of the camera. 2. Tighten the screw to attach the mounting base. Please refer to the following drawing. C A M E F O C A V A R I - C A M E F O C A...
- Page 10 CONNECTION OF POWER SUPPLY CABLE (AC24V or DC12V) Connect to the power supply. Please refer to the right drawing. NOTE Make sure to use AC24V or DC12V AC24V / DC12V (Non-Polarity input) power supply. AC24V ( 10%) DC12V ( 10%) ADJUSTMENT OF ZOOM (VIEW ANGLE) AND FOCUS Take the lens hood off by turning it counter-clockwise.
- Page 11 DC IRIS LEVEL ADJUSTMENT Adjust DC iris level manually. Please refer to the above drawing. AUDIO POWER IRIS LEVEL ATTENTION Adjust this VR with care so as not to cause damage to the unit.
-
Page 12: Specifications
SPECIFICATIONS VARI-FOCAL COLOR CAMERA Model No. PIH-4022 N/P PIH-4026 N/P PIH-4028 N/P Focal Length 3 ~ 9mm Iris F1.4 Lens 90.2 ~31.8 Angle of View 66.3 ~23.9 115.3 ~39.7 AC24V ( 10%) Power Input Voltage DC12V ( 10%) AC90 ~ 260V... - Page 13 HIGH RESOLUTION VARI-FOCAL COLOR CAMERA Model No. PIH-4042 N/P PIH-4046 N/P PIH-4048 N/P Focal Length 3 ~ 9mm Iris F1.4 Lens 90.2 ~31.8 Angle of View 66.3 ~23.9 115.3 ~39.7 AC24V ( 10%) Power Input Voltage DC12V ( 10%) AC90 ~ 260V DC12V ( 10%) System...
- Page 14 MERIT LILIN ENT. CO., LTD http://www.meritlilin.com 66-402CSE...
