Page 2
This publication is subject to change. bintec elmeg offers no warranty whatsoever for information contained in this manual. bintec elmeg is not liable for any direct, indirect, collateral, consequential or any other damage connected to the de- livery, supply or use of this manual.
• A description of the TBC1-1VDSL2-1 expansion card LEDs and connector pin- outs. 1.5 How is the information organized? This document aims to provide all the information necessary to install the TBC1-1VDSL2-1 expansion card in the bintec RM3000 / RM5000 / RM7000 router family. • TBC1-1VDSL2-1 expansion card characteristics.
1 About This Manual bintec elmeg Email: support@bintec-elmeg.com 1.7 Related Documentation bintec Dm569-I bintec RM3000 Installation. bintec Dm741-I ADSL-VDSL Note The manufacturer reserves the right to make changes and improvements to the appropriate features in both the software and hardware of this product, modifying the specifications of this manual without prior notice.
• It only uses FDM mode, EC mode is not defined (echo cancellation or carrier overlapping). • Allows for a new encapsulation to be used: PTM. • Multiple link diagnostics. For further information on ADSL and VDSL technologies, please see the bintec Dm741-I ADSL-VDSL manual. TBC1-1VDSL2-1 card Fig. 1: 2.1 TBC1-1VDSL2-1 expansion card: Characteristics...
Dual-Latency supported. Dying Gasp: • ITU G.991.2 standard recommendation. 2.2 TBC1-1VDSL2-1 expansion card: Connectors Figure 2 shows the front board of the TBC1-1VDSL2-1 card: Front of the TBC1-1VDSL2-1 card Fig. 2: The front board elements are as follows: Elements table for the front of the TBC1-1VDSL2-1 card...
3.1 Requirements prior to installation To configure the card, you must be able to access the bintec RM3000 / RM5000 / RM7000 router through a console or a Telnet connection. For further information, please see the Connecting for configuration section under the bintec Dm569-I bintec RM3000 Installation manual.
Chapter 4 LEDs and connector pinouts: Description This chapter provides information on the TBC1-1VDSL2-1 expansion card LEDs and connector pinouts. 4.1 TBC1-1VDSL2-1 expansion card: LEDs The TBC1-1VDSL2-1 expansion card for bintec RM3000 / RM5000 / RM7000 routers has three LEDs: STATUS and LINK. TBC1-1VDSL2-1 Fig.
Page 11
4 LEDs and connector pinouts: Description bintec elmeg TBC1-1VDSL2-1 card RJ-11 Connector Pinouts RJ-45 pinouts Signal RING We recommend that you use a 26 AWG cable (at the very least). This may be supplied with the card itself or be de- scribed in the safety instructions.
El símbolo del contenedor con la cruz, que se encuentra en el aparato, significa que cuando el equipo haya llegado al final de su vida útil, deberá ser llevado a los centros de recogida previstos, y que su tratamiento debe estar separado del de los residuos urbanos. TBC1-1VDSL2-1 card...
REACH Candidate List. Information is cur- rentlyprovided to consumers upon request. 5.5 EC Declaration of Conformity English (EN) Hereby, bintec elmeg declares that the radio equipment type TBC1-1VDSL2-1 is in compliance with: Directive 2014/30/EU (EMC) Directive 2014/35/EU (LVD) of the European Parliament and of the Council.
