Introduction

This document defines EC20 Mini PCIe module and describes its hardware interfaces which are
connected with your application and air interfaces.
This document can help you to quickly understand the interface specifications, electrical and mechanical
details and related product information of the EC20 Mini PCIe module. To facilitate its application in
different fields, relevant reference design documents are also provided. Associated with application notes
and user guide of EC20 Mini PCIe module, you can use the module to design and set up mobile
applications easily.
