R O B O
T X C
Contents
ROBO TX Controller .................................................................................................p. 21
Proper Use .......................................................................................................... p. 21
Safety Instructions ..................................................................................................p. 21
This can be connected to the ROBO TX Controller............................................p. 22
Install software ........................................................................................................p. 24
Setting (menu) ..........................................................................................................p. 25
Menu overview ................................................................................................... p. 25
Menu in detail .................................................................................................... p. 26
Switch on ..................................................................................................................p. 30
Select and start program........................................................................................p. 30
Switch off ..................................................................................................................p. 30
Expansions................................................................................................................p. 30
Bluetooth connections ...........................................................................................p. 31
Faults..........................................................................................................................p. 33
Technical data ..........................................................................................................p. 34
Proper disposal ........................................................................................................p. 35
Warranty ....................................................................................................................p. 35
Liability ......................................................................................................................p. 35
Description for figure on page 3.
1.
USB Connection
2.
Selection button left
3.
9 V
IN , connection rechargeable battery pack
4.
Display
5.
ON/OFF switch
6.
Selection button right
7.
9 V
IN , DC jack socket for power unit
( + = internal)
20
I
O n T R O l l e R
n s T R u C T I O n
M
a n u a l
8.
EXT 2, connection for expansions
9.
Outputs M1-M4 or O1-O8
10. Fast counting inputs C1-C4
11. 9 V
OUT, voltage output
12. Camera connection
13. Universal inputs I1-I8
14. EXT 1, connection for expansions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for fischertechnik ROBO TX Controller
Summary of Contents for fischertechnik ROBO TX Controller
-
Page 1: Table Of Contents
ROBO TX Controller ....................p. 21 Proper Use ......................p. 21 Safety Instructions ....................p. 21 This can be connected to the ROBO TX Controller..........p. 22 What are the jack sockets, connector plugs, push buttons and switches for? p. 23 Install software ......................p. 24 Setting (menu) ......................p. -
Page 2: Robo Tx Controller
ROBO TX Controller Pure high tech is concealed in the compact casing of the ROBO TX Controller. Programs can be loaded into this control and then these programs control motors, lamps and even entire fischertechnik robots, and this is not all: •... -
Page 3: This Can Be Connected To The Robo Tx Controller
T R u C T I O n a n u a l This can be connected to the ROBO TX Controller The following devices can be connected or controlled. In addition, the Controller can be expanded with additional devices. -
Page 4: What Are The Jack Sockets, Connector Plugs, Push Buttons And Switches For
The display menu is controlled with this. More on this in the menu chapter 3 9 V IN, connection rechargeable battery pack This connection allows mobile power supply through the fischertechnik rechargeable bat- tery pack (not included in the scope of delivery) as an alternative to the power unit. 4 Display The display shows the status of the Controller, which programs are loaded and where you are in the menu. -
Page 5: Install Software
In the handbook for the ROBO Pro software, the following, among other things, are described in detail: • The installation of the ROBO Pro software on the PC. • The installation of the USB driver for the ROBO TX Controller for the Windows operating systems. -
Page 6: Setting (Menu)
R O B O T X C O n T R O l l e R n s T R u C T I O n a n u a l Setting (menu) Menu overview ROBO TX -> Local -> No program file loaded ->... -
Page 7: Menu In Detail
R O B O T X C O n T R O l l e R n s T R u C T I O n a n u a l Menu in detail Navigation using selection buttons left selection push button switch, a •... - Page 8 R O B O T X C O n T R O l l e R n s T R u C T I O n a n u a l Line 4: Ext. ƒ It shows, which extensions are connected, for example, 1, 2, ...
- Page 9 R O B O T X C O n T R O l l e R n s T R u C T I O n a n u a l The Settings Settings Role: Master Line 1: Role: Master/Extension ƒ...
- Page 10 If the function is switched on, then other Bluetooth devices can identify the ROBO TX Controller. Line 3: Device connectable ƒ If the function is switched on then the ROBO TX Controller allows other devices to make a Bluetooth connection with the Controller. Line 4: Paired devices: ƒ...
-
Page 11: Switch On
R O B O T X C O n T R O l l e R n s T R u C T I O n a n u a l Switch on When connecting the Controller for the first time to the PC, the driver for the USB interface must be installed in the PC. -
Page 12: Bluetooth Connections
PC and there is a continual exchange of data between the PC and the ROBO TX Controller. Using this blue connection, programs can also be down- loaded to the controller and these programs can then be processed independent of the PC. - Page 13 Bluetooth Connection Between Different ROBO TX Controllers In the download mode, a ROBO TX Controller can exchange data with up to seven other ROBO TX Controllers. When this is done, each device can establish a Bluetooth connection with every other participant and transmit and receive data over this connection.
-
Page 14: Faults
Program file open failure The program file could not be Load the program file onto the opened because it was deleted ROBO TX Controller again. in the flash memory. Program file read failure Program file could not be read Program file must be repro-... -
Page 15: Technical Data
R O B O T X C O n T R O l l e R n s T R u C T I O n a n u a l Technical Data Dimensions and Weight 90 x 90 x15 mm (W x D x H) 90 g Memory and Processor 8 MB RAM, 2 MB flash... -
Page 16: Proper Disposal
The symbol on the product, packaging or the instructions shows this. Warranty The fischertechnik GmbH provides a warranty for the freedom from defects of the Con- troller according to the particular state of the technology. The right is reserved to make changes to the design or model, which neither impair the functioning or the value of the device, and does not entitle the customer to make a complaint.
