- Page 1 ENGLISH AUDIO MICRO SYSTEM User manual MC-100 Please read this User Manual carefully to ensure proper use of this product and keep this manual for further reference.
-
Page 2: Table Of Contents
ENGLISH Warnings ........................1 Precautions ....................... 2 Introduction ....................... 3 Unpacking ............................ 3 Power Sources ..........................3 Front panel and Connections ....................4 Operation ........................5 General operations ....................6 Radio operation......................6 USB/SD operation ........................6 Playback...........................6 General USB/SD notes ......................6 AUX jack ........................7 Maintenance &... -
Page 3: Warnings
ENGLISH Do not use the machine either voltage is not correspond with notified voltage on the rating plate. If voltage is not correct, it is possibility of the unit damage or risk of fire. - 1 -... -
Page 4: Precautions
ENGLISH Fo r Cus tomer Use This "bolt of lighting" indicates Ente r below th e Seri al N o. whi ch is located uninsulated material within your On the botto m of the cabinet. R etain th is In fo rmation fo r future r efere nce. unit which may cause an electrical Mo de No. -
Page 5: Introduction
ENGLISH PREPARATION FOR USE Unpacking and Setup * Carefully remove the unit from the display carton and remove all packing material from the unit itself. * Remove any descriptive labels that may be found on either the front or top cabinet of the unit. Do not remove any labels located on either the back or button cabinet of the unit. -
Page 6: Front Panel And Connections
ENGLISH FRONT PANEL AND CONNECTIONS 1. SD JACK 2.FUNCTION SELECT 3. PLAY/PAUSE/TIME BUTTON 4. USB JACK 5. STANDBY 6. EQ 7. REPEAT/MEMORY 8. LEFT&RIGHT SPEAKER 9. LCD DISPLAY 10.STOP BUTTON 11.NEXT BUTTON 12.BACK BUTTON 18.VOLUME- BUTTON 13. AC SOCKET 19.PRE-DN/-10 BUTTON 14. -
Page 7: Operation
ENGLISH OPERATION Power supply Battery operation Open the battery compartment cover. Insert 6 x 1.5V LR14, UM-2 batteries (not include). Please observe correct battery polarity or the unit will not work. Close the battery compartment cover. When the batteries are exhausted, they should be replaced. Do not recharge or heat the batteries. -
Page 8: Radio Operation
ENGLISH Radio operation Press FUNCTION button to enable the radio mode. Press and hold PLAY/PAUSE/TIME button; the unit will automatically scan the frequency range and save all available stations in the memory (up to 30). When the automatic search will be completed, the unit will start broadcasting the first found station. -
Page 9: Aux Jack
ENGLISH AUX jack You can connect the audio output of an external device to this unit, to listen to the sound of that device through the speakers of this unit. To connect an external audio device, please use a standard audio cable with 3.5-mm- to-3.5mm plugs(not included) to connect the headphone out or audio line-out of the external device to the AUX input socket of this unit. -
Page 10: Trouble Shootings
ENGLISH TROUBLESHOOTING Should the system exhibit a problem, check the following before seeking service. Symptom Possible Cause Solution No Sound / Power Volume not adjusted Adjust the Volume level Power cord not securely Connect the AC power cord connected properly Batteries dead/ incorrectly Insert new batteries correctly inserted... -
Page 11: Technical Specifications
ENGLISH TECHNICAL SPECIFICATIONS Declaration of Conformity This device is manufactured in accordance with applicable European standards on safety (LVD Directive 2014/35/EU), EMC (EMC Directive 2014/30/EU), ErP Directive 2009/125/EU) and WEEE and RoHS Directive ( 2012/19/EU i 2011/65/EU). ENVIRONMENTALLY - FRIENDLY TREATMENT According to the EU Directive No 2012/19/EU concerning the products labeled with a symbol of a crossed trash can, the manufacturer warns that this product cannot be considered a standard domestic waste. - Page 12 www.quadro-electronics.com...
