Summary of Contents for Residentia DW42CS
- Page 1 User Manual\ 60cm\Freestanding Dishwasher\ DW42CS...
- Page 2 At Residentia Group, we are customer obsessed and our Support Team are there to ensure you get the most out of your appliance. Should you want to learn more about your dishwasher and taking care of it, our Support Team are here to help.
- Page 3 esidentia\User Manual Contents\Page Safety Instructions\04 Quick Operation\07 Operating Instruction\08 Prior using for the First Time\09 Loading the Dishwasher Baskets\12 Starting a Washing Program\10 Maintenance and Cleaning\16 Installation Instruction\18 Troubleshooting Tips\21 Technical Information\23 Warranty\26...
- Page 4 esidentia\04 1.IMPORTANT SAFETY INFORMATION WARNING! When using your dishwasher, follow the precautions listed below: This appliance is intended to be used in household and similar applications such as: -staff kitchen areas in shops, offices and other working environments; -farm houses; -by clients in hotels, motels and other residential type environments;...
-
Page 5: Installation
User Manual\05 Do not abuse, sit on, or stand on the door or dish rack of the dishwasher. Do not operate your dishwasher unless all enclosure panels are properly in place. Open the door very carefully if the dishwasher is operating, there is a risk of water squirting out. - Page 6 esidentia\06...
- Page 7 User Manual\07 2.Quick operation guide 2.Quick operation guide For detailed operating method read the corresponding content on the instruction manual. For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Switch on the appliance Open the door, press the Open the door, press the On/Off button...
-
Page 8: Control Panel
esidentia\08 3.Operation Instruction IMPORTANT To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Control Panel 1. On/Off Button: to switch On/Off the appliance; 2.Alt function Button: Dual zone wash function, press the 10.Child lock indicator;... - Page 9 User Manual\09 Prior using for the first time Before using your dishwasher for the first time: Fill the rinse aid dispenser Fill in detergent A. Rinse Aid Dispenser Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks.
- Page 10 esidentia\10 Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming NOTE: during the next wash. Don't forget to replace the cap before you close dishwasher door. Adjusting Rinse Aid Dispenser The rinse aid dispenser has six or four settings. Always start with the dispenser Adjust lever (Rinse) set on "4".
- Page 11 User Manual\11 Proper Use of Detergent Use only detergent specifically made for the use in dishwashers. Keep your detergent fresh and dry. Don't put powdered detergent into the dispenser until you're ready to wash dishes. Adding detergent to dispenser Fill in Detergent Fill the detergent dispenser with detergent.
-
Page 12: Loading The Dishwasher
esidentia\12 5.Loading the Dishwasher Baskets Recommendation Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further information from the detergent manufacturers. For particular items, select a program with as low a temperature as possible. To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the programme has ended. -
Page 13: Cutlery Basket
User Manual\13 The Method Loading Normal Dishware Loading the Upper Basket Loading the Lower Basket The upper basket is designed to hold more delicate We suggest that you place large items and the most and lighter dishware such as glasses, coffee and difficult to clean items are to be placed into the lower tea cups and saucers, as well as plates, small bowls basket: such as pots, pans, lids, serving dishes and... - Page 14 esidentia\14...
- Page 15 User Manual\15 NOTE: When you press the Start/Pause button to pause during washing, the LED display will stop blinking and the dishwasher will mooing every minute unless you press the Start/Pause button to start. Change the Program Premise: A cycle that is underway can only be modified if it has only been running for a short time. Otherwise, the detergent may have already been released, and the appliance may have already drained the wash water.
-
Page 16: Maintenance And
esidentia\16 7.Maintenance and Cleaning Filtering System The filter prevents larger remnants of food or other objects from getting inside the pump. The residues may block the filter, in this case they must be removed. The filter system consists of a coarse filter,a flat (Main filter) And a microfilter(Fine filter). - Page 17 User Manual\17 Remarks: - Inspect the filters for blocking after every time the dishwasher has been used. - By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and clean the filters under running water. NOTE: The entire filter assembly should be cleaned once a week.
-
Page 18: How To Keep Your Dishwasher In Shape
esidentia\18 How to Keep Your Dishwasher in Shape When not in Use for a LongTime After Every Wash It is recommend that you run a wash cycle with the After every wash, turn off the water supply to the dishwasher empty and then remove the plug from the appliance and leave the door slightly open so that socket, turn off the water supply and leave the door of moisture and odours are not trapped inside. -
Page 19: Water Connection
User Manual\19 Water Connection Cold Water Connection Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the water is clear. - Page 20 esidentia\20 How to Drain Excess Water From Hoses How to Drain Excess Water From Hoses If the sink is 1000 higher from the floor, the excess water in hoses cannot be drained directly If the sink is 1000 higher from the floor, the excess water in hoses cannot be drained directly into the sink.
-
Page 21: Troubleshooting
User Manual\21 9.Troubleshooting Tips 9.Troubleshooting Tips Before Calling for Service Before Calling for Service Review the charts on the following pages may save you from calling for service. Review the charts on the following pages may save you from calling for service. Problem Problem Possible Causes What to Do... - Page 22 esidentia\22 Problem Problem Possible Causes Possible Causes What to Do What to Do The dishes The dishes The dishes were not The dishes were not See notes in " Loading the Dishwasher Baskets ". See notes in " Loading the Dishwasher Baskets ". loaded correctly.
-
Page 23: Technical Information
User Manual\23 Technical Information Height : 845mm Width : 448m m Depth : 600mm (with the door closed) Water pressure: 0.04-1.0MPa Power supply: see rating label Capacity: 10 place settings... - Page 24 esidentia\24...
- Page 25 User Manual\25...
- Page 26 This document sets out the terms and conditions of the in the ACL; product warranties for Residentia Group Appliances. It is ‘ACL’ means Trade Practices Amendment an important document. Please keep it with your proof of (Australian Consumer Law) Act (No.2) 2010;...
- Page 27 Appliance To the extent permitted by law, Residentia Group to and from Residentia Group or its ASR, in all excludes all warranties and liabilities (other than as instances, unless the Appliance is transported...
- Page 28 Model Code\DW42CS...
