RFL 9785 Instruction Manual

Programmable on/off powerline carrier system
Hide thumbs Also See for 9785:
Table of Contents

Advertisement

Quick Links

The information in this manual is proprietary and confidential to RFL Electronics Inc. Any
reproduction or distribution of this manual, in whole or part, is expressly prohibited, unless
written permission is given by RFL Electronics Inc.
This manual has been compiled and checked for accuracy. The information in this manual
does not constitute a warranty of performance. RFL Electronics Inc. reserves the right to
revise this manual and make changes to its contents from time to time. We assume no liability
for losses incurred as a result of out-of-date or incorrect information contained in this manual.
RFL 9785
March 1, 2013
B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
INSTRUCTION MANUAL
RFL 9785
PROGRAMMABLE ON/OFF
POWERLINE CARRIER SYSTEM
NOTICE
RFL Electronics Inc.
353 Powerville Road ● Boonton Twp., NJ 07005-9151 USA
Tel: 973.334.3100 ● Fax: 973.334.3863
Email:
sales@rflelect.com
Publication Number MC9785
Printed in U.S.A.
Revised March 1, 2013
●
www.rflelect.com
i
RFL Electronics Inc.
(973) 334-3100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9785 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RFL 9785

Summary of Contents for RFL 9785

  • Page 1 POWERLINE CARRIER SYSTEM NOTICE The information in this manual is proprietary and confidential to RFL Electronics Inc. Any reproduction or distribution of this manual, in whole or part, is expressly prohibited, unless written permission is given by RFL Electronics Inc.
  • Page 2 The RFL 9785 is warranted against defects in material and workmanship for one year from the date of shipment. During the warranty period, RFL will repair or, at its option, replace components that prove to be defective at no cost to the customer, except the one-way shipping cost of the failed assembly to the RFL Customer Service facility in Boonton, New Jersey.

  • Page 3: Warnings And Safety Summary

    Warning! Do not disconnect under power. Located on rear of 9508 RF Chassis for 100 watt systems RFL 9785 RFL Electronics Inc. March 1, 2013 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 4 WARNING! POWER MUST BE TURNED OFF BEFORE REMOVING OR INSTALLING ANY RFL 9785 MODULES. FAILURE TO DO SO MAY RESULT IN COMPONENT DAMAGE. WARNING! ON INITIAL INSTALLATION, ENSURE THAT ALL MODULES ARE FULLY SEATED INTO CONNECTORS BEFORE POWERING ON UNIT.
  • Page 5 Failure to comply with these precautions, or with specific warnings elsewhere in this manual, violates safety standards of design, manufacture, and intended use of this product. RFL Electronics Inc. assumes no liability for failure to comply with these requirements.
  • Page 6 This page intentionally left blank RFL 9785 RFL Electronics Inc. March 1, 2013 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 7: Table Of Contents

    2.2 PURPOSE OF EQUIPMENT ............................ 2-2 2.3 FEATURES................................2-3 2.4 PHYSICAL DESCRIPTION............................2-4 2.5 SYSTEM SPECIFICATIONS............................ 2-4 2.6 TERMINAL CONFIGURATION..........................2-5 2.7 RFL 9785 SUBASSEMBLIES........................... 2-7 2.8 SYSTEM THEORY OF OPERATION ........................2-10 Section 3. INSTALLATION..............................3-1 3.1 INTRODUCTION..............................3-1 3.2 UNPACKING ................................3-1 3.3 MOUNTING ................................
  • Page 8 13.1 INTRODUCTION..............................13-1 13.2 SEQUENCE OF EVENTS/IRIG-B MODULE ..................... 13-2 13.3 SEQUENCE OF EVENTS/IRIG-B I/O MODULE ..................... 13-11 Section 14. USING THE RS-232 PORTS TO ACCESS THE RFL 9785 SOE MODULE ..........14-1 14.1 INTRODUCTION..............................14-1 14.2 ESTABLISHING COMMUNICATIONS ......................14-1 14.3 VIEWING APRIL COMMANDS .........................
  • Page 9 Section 22. SIMPLIFIED COMMISSIONING PROCEDURE..................22-1 22.1 SIMPLIFIED COMMISSIONING PROCEDURE....................22-1 22.2 COMISSIONING TEST PROCEDURE FOR 50 AND 100 W SYSTEMS USING THE 9508 RF CHASSIS.. 22-4 22.3 RFL 9785 FUNCTIONAL TEST PROCEDURE ....................22-9 Section 23. INDEX ................................23-1 RFL 9785 RFL Electronics Inc.
  • Page 10 Figure 3-2. Rear panel View of Typical RFL 9785 TX/RX Chassis (Dwg. No. D-106577-A).......... 3-9 Figure 4-1. Controls and indicators, RFL 9785 front panel ....................4-2 Figure 4-2. Locations of Circuit Board Modules in a Typical RFL 9785 Chassis (Dwg. No. D-106577-A) ...... 4-5 Figure 4-3. 9785 Fail Conditions ............................4-10 Figure 6-1.
  • Page 11 Figure 10-3. Controls and indicators, RFL 9785 Output Filter Modules (106530-11 to 106530-15) ....... 10-5 Figure 10-4. Schematic, RFL 9785 Output Filters Without RPM, Assy Nos. 106530-1 to -5 (Dwg. No. D-106534-D).. 10-7 Figure 10-5. Schematic, RFL 9785 Output Filters with RPM, Assy Nos. 106530-11 to -15 (Dwg. No. D-106534-1-H) 10-9 Figure 11-1.
  • Page 12 Figure 19-9. Schematic, RFL 9785 Solid State Input/Output I/O (Dwg. No. D-106639-C) Sheet 1 of 2 ..... 19-15 Figure 19-10. Schematic, RFL 9785 SS Logic Level Input/Output I/O (Dwg. No. D-106639-5-C) Sheet 1 of 2 ..19-19 Figure 19-11. Alarm Relay I/O module, rear panel view....................19-23 Figure 19-12.
  • Page 13 Figure 22-3. Controls and Indicators, RFL 9785 Receiver Downshifter Module (106575) - first ........22-2 Figure 22-4. Controls and Indicators, RFL 9785 Receiver Downshifter Module (106575) - second......22-3 Figure 22-5. Controls and Indicators, RFL 9780/85 Transmitter Module (106505)............22-5 Figure 22-6.
  • Page 14 Table 18-2. Controls and indicators, RFL 9785 power supply module ................18-5 Table 18-3. Characteristics of RFL 9785 Power Supply I/O modules................18-13 Table 18-4. Controls and indicators, RFL 9785 Single Power Supply I/O module ............18-14 Table 18-5. Controls and indicators, RFL 9785 Dual Power Supply I/O module ............18-17 Table 18-6.
  • Page 15 LIST OF EFFECTIVE PAGES When revisions are made to the RFL 9785 Instruction Manual, the entire section where revisions were made is replaced. For the edition of this manual dated March 1, 2013 the sections are dated as follows: Front Matter...
  • Page 16 9-17-01 9785-030: Added potentiometer to voice module 9785-044: Rx Detector, changed C66A to C66B 9785-046: Rx Detector, changed R89 to 100Ω 9785-047: Added “modules fully seated” warning to page vi RFL 9785 RFL Electronics Inc. March 1, 2013 (973) 334-3100...
  • Page 17 Section 9) 4-10-03 Revised in accordance with ECO Nos.: 4-10-03 MISC-488 (rev C3, C4, C8,&C9 on P.S. I/O) 9785-030 (Voice Module) 9785-041 (AM Logic and Motherboard) 9785-044 (Rx Detector) 9785-046 (Rx Detector) 9785-052 (RF Line I/O) 9785-053 (Voice Filter) 9785-054 (Checkback)
  • Page 18 Revised in accordance with CAR# C9785-0051. Incorporate errata sheet MC 9780-003-B in accordance with CAR# 9780-0138. 6-16-04 Incorporate errata sheet MC 9785-002 in accordance with ECO# 6-16-04 9780-154. (Section 13) Incorporate errata sheet MC 9785-003 in accordance with CAR# C9780-0052. (Added skewed hybrid I/O to Section 19) Incorporate errata sheet MC 9785-005 in accordance with ECO# 9780-156.
  • Page 19 4-2-07 Section 6. As per ECO 9785-073 7-26-07 Revise Section 16 as per customer input. 7-26-07 3-24-08 Add 9785 Fail Condition Illustration to section 4.7.4 as per sales 3-24-08 request. RFL 9785 RFL Electronics Inc. March 1, 2013 (973) 334-3100...
  • Page 20 ECO9508-129 3-1-13 Minor changes to Section 22 as per Car 9780-0307 3-1-13 RFL 9785 RFL Electronics Inc. March 1, 2013 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 21: Section 1. Product Information

    Section 1. PRODUCT INFORMATION Please see the following page for the Product Information Sheet: 9785 Product Information sheet. RFL 9785 RFL Electronics Inc. September 1, 2006 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 22: Section 8 September

    This page intentionally left blank RFL 9785 RFL Electronics Inc. September 1, 2006 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 23: Section 22 March

    3U chassis. A functional block capabilities (meeting the requirements of ANSI/IEEE C93.5), diagram of a typical RFL 9785 terminal appears in Figure 2. ESD protection (per IEEE PC 37.90.3, 2001), available redundant power supplies, increased flexibility through field- The RFL 9785’s transmit characteristics are set by rotary...

  • Page 24: Section 5 April

    IRIG-B input every ten min- I/O Flexibility utes if IRIG-B is available. The RFL 9785’s I/O module can be set to match the I/O requirements of your equipment. This means you can interface The SOE module also offers the ability to locally or remotely...
  • Page 25 5.7.3, and 6.3.21. The electromechanical block output con- tacts will add an additional 7 ms delay. The 9785 is a programmable 10 W On/Off carrier system which fully complies with ANSI C93.5. The system is packaged in a Optional Sequence of Events single 3U high chassis and includes full-feature transmitter and System status points are checked every millisecond;...
  • Page 26 Note: Logic level (5 volt nominal ) outputs are available. tion of 1 Watt. Figure 1. Typical RFL 9785 Programmable ON/OFF Powerline Carrier System Block Diagram. Specifications subject to change without notice. RFL Electronics Inc.
  • Page 27 Figure 2. Typical Rear View RFL 9785 Programmable ON/OFF Powerline Carrier System. B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 28 """ '""' Figure 4. Typica.l Black IliagraM of' the RFL 9785 Pragrc.MMaklle ON/OFF Pawerline Carrier S:ysteM �� CTI - 49883- A &:.c,.,b::l,.,ft•• •"-:t• U� B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 29 Figure 4. RFL 9785 50 Watt Configuration The RFL 9785 ON/OFF Powerline Carrier can be configured for either 50 or 100 Watt RF power outputs. The RFL Model 9508 RF power amplifier is rated for 50 Watt PEP and is the standard amplifier used for single sideband applications.
  • Page 30 RFL Electronics Inc. 3 5 3 P o w e r v i l l e R o a d Boonton Twp., NJ 07005 P - 9 7 3 . 3 3 4 . 3 1 0 0 RFL Electronics Inc.

  • Page 31: Section 2. General Information

    (TB1-1, SW1-1, IC1-1, etc). The circuit boards in the RFL 9785 use DIN 41612 Type C connectors which contain columns of 32 pins. All modules have pins in columns A and C and provide a total of 64 pins per connector.

  • Page 32: Purpose Of This Manual

    ON/OFF Powerline Carrier System. Included are an overall functional description of its purpose, a physical description, specifications, installation instructions, operating procedures, maintenance procedures, theory of operation, and parts information for all circuit card modules. A typical RFL 9785 terminal is shown in Figure 2-1.

  • Page 33: Features

    The internal amplifier is rated at 10W. External amplifiers may be used to provide 50W or 100W capability. Saves Rack Mounting Space Each RFL 9785 terminal is housed in a single chassis three rack-units high (5.25 inches, or 133mm), including Sequence Of Events, Checkback and Voice options. Station Battery Isolation A dc-dc converter supplies regulated voltage to all RFL 9785 modules.

  • Page 34: Physical Description

    2.4 PHYSICAL DESCRIPTION Each RFL 9785 terminal is a group of circuit board modules housed in a chassis three rack-units high (5.25 inches, or 133 mm). Interconnections between modules are made by a motherboard in the chassis. External equipment is connected to the chassis through I/O modules which plug into the rear panel.

  • Page 35: Terminal Configuration

    Weight: Less than 30 lbs (13.6 kg). 2.6 TERMINAL CONFIGURATION The RFL 9785 is housed in a single 3U high, rack mounted chassis. Table 2-2 shows general information about the available modules for the RFL 9785. Figure 2-2 shows a typical block diagram of an RFL 9785 chassis.

  • Page 36: Table 2-2. Rfl 9785 Modules, General Information

    Motherboard 106545 Checkback Alarm Chassis 106650 Section 21 * The voice filter plugs onto the Receiver Detector module only when the RFL 9785 voice option is used. RFL 9785 RFL Electronics Inc. June 18, 2009 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 37: Rfl 9785 Subassemblies

    Switches SW1-1 through SW1-7 on the 9785 AM Logic Module allows the logic to be set according to the requirements of the specific application. The 9785 AM Logic Module also provides status information for the Sequence of Events Module.

  • Page 38: Section 8. Power Amplifier Module

    RFL 9785 Output Filter modules are used to reduce the harmonic content of the Power Amplifier’s output signal to a level that is at least 55 dB below the carrier level. In order to cover the RFL 9785's entire operating range (30kHz to 535 kHz), there are four different RFL 9785 Output Filters.
  • Page 39 2.7.8 SOE/IRIG-B MODULE AND SOE/IRIG-B I/O MODULE The IRIG-B Module is a status monitor card for the RFL 9785 which monitors input status every 1 ms. Sequence Of Events are recorded when any point changes state or if the CPU gets reset. The Sequence Of Events log is a record of the state of each point, the state of CPU reset, and the date and time the record was saved.

  • Page 40: System Theory Of Operation

    2.7.15 CHECKBACK ALARM CHASSIS The optional RFL 9785 Checkback Alarm Chassis allows a user to determine the status of each of the eight checkback tests by means of a relay contact closure. Additional information on the RFL 9785...
  • Page 41 Line I/O Module, a Downshifter Module, a Receiver Detector Module, and an AM Logic Module. The received signal enters the 9785 chassis through a Line I/O Module. The Line I/O module has two UHF connectors, screw-type terminal connections, impedance matching circuits, and ANSI C.37.90 compliant protection circuits.
  • Page 42 There are two RS-232 connectors on the 9785 to access the SOE Module, one on the rear and one on the front of the unit. The rear connector is intended for permanent connection to monitoring equipment (if available) while the front connector is intended for short-term connection to a PC or terminal for system interrogation.

  • Page 43: Section 3. Installation

    3.2.2 INTERCONNECTED CHASSIS RFL 9785 terminals ordered as part of a larger system may be interconnected with other chassis and mounted in a relay rack or cabinet, or on shipping rails for installation into a rack or cabinet at the customer's site.

  • Page 44: Mounting

    RFL 9785 terminals housed in individual chassis have two mounting ears (one on each side). Hole sizes and spacings conform with EIA standards, so the RFL 9785 can be mounted in any standard 19- inch rack or cabinet. Complete chassis dimensions are shown in Figure 3-1.

  • Page 45: Ventilation

    LEADS. THESE INDUCED CURRENTS CAN RESULT IN FALSE TRIPS. TO REDUCE THIS POSSIBILITY, USE A SHIELDED TWISTED PAIR FOR EACH INPUT LEAD, AND GROUND THE SHIELD AT THE RFL 9785 CHASSIS ONLY. AS AN ADDED PRECAUTION, DO NOT BUNDLE INPUT, OUTPUT, AND...

  • Page 46: Connections

    Electrical connections are made to each RFL 9785 chassis through the terminal blocks and connectors on the chassis rear panel. The rear panel of the RFL 9785 terminal is shown in Figure 3-2. Paragraphs 3.5.1 through 3.5.11 provide basic descriptions of all the connections that must be made. Refer to the "as supplied"...
  • Page 47 All relay contacts are labeled in the de-energized position. 3.5.2 SOLID-STATE INPUT CONNECTIONS Solid-state input connections are made to terminal blocks TB4 and TB5 on the rear of the RFL 9785 chassis. Terminal assignments are shown below. Be sure to observe proper polarity when making these connections.
  • Page 48 Checkback Test is run and passes. 3.5.7 CURRENT LIMIT PANEL CONNECTIONS Current limit panel connections are made to terminal block TB1 on the rear of the RFL 9785 chassis. Refer to Section 19.6 for more information.
  • Page 49 3.5.10 CHASSIS GROUND CONNECTIONS A threaded ground stud at the rear lower right of the RFL 9785 chassis is the main ground for the RFL 9785 terminal. Grounding is accomplished by connecting a wire 6AWG or larger between the ground stud and rack ground.
  • Page 50 A switched station battery output is also available on terminal block TB10, positive at TB10-3, and negative to TB10-4. This output can be used to shut down external equipment in the event that the RFL 9785 is shut down for any reason.

  • Page 51: Figure 3-2. Rear Panel View Of Typical Rfl 9785 Tx/Rx Chassis (Dwg. No. D-106577-A)

    TB9-5 CONNECTED TO TRANSMIT) TB9-6 CHASSIS GROUNDING STUD (#8 LUG) P.S.-B REDUNDANT P.S. Figure 3-2. Rear panel View of Typical RFL 9785 TX/RX Chassis (Dwg. No. D-106577-A) 9785 RFL Electronics Inc. Apri l 25, 2005 3-9 (3-10 Blank) (973) 334-3100...

  • Page 52: Section 4. Operating Instructions

    RFL 9785 into continuous service. 4.2 FRONT PANEL CONTROLS AND INDICATORS The front panel of the RFL 9785 terminal contains controls and indicators which are used to monitor system functions during normal operation. These controls and indicators are shown in Figure 4-1 and are described in Table 4-1.

  • Page 53: Figure 4-1. Controls And Indicators, Rfl 9785 Front Panel

    INITIATE CARRIER RS-232 TX FAIL RFL Electronics Inc. Figure 4-1. Controls and indicators, RFL 9785 front panel RFL 9785 RFL Electronics Inc. March 24, 2008 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 54: Table 4-1. Controls And Indicators, Rfl 9785 Front Panel

    Table 4-1. Controls and indicators, RFL 9785 Front Panel Item Name/Description Function Number POWER ON indicator Lights green when system power is ON STOP INPUT indicator Lights red when CARRIER STOP input is active START INPUT indicator Lights red when CARRIER START input is active...

  • Page 55: Table 4-2. Controls And Indicator Information For Rfl 9785 System Modules

    Table 4-2. Controls and indicator information for RFL 9785 system modules Module Description Controls and Indicators Refer to Information Section: AM Logic module Table 6-1 & Figure 6-3 Transmitter module Table 7-1 & Figure 7-4 Power amplifier module Table 8-1 & Figure 8-2 Output filter modules Table 10-1 &...

  • Page 56: Figure 4-2. Locations Of Circuit Board Modules In A Typical Rfl 9785 Chassis (Dwg. No. D-106577-A)

    BLOCK 12V RET. FAIL RLY2 FAIL RLY1 Figure 4-2. Locations of Circuit Board Modules in a Typical RFL 9785 Chassis (Dwg. No. D-106577-A) 9785 RFL Electronics Inc. arch 24, 2008 4-5 (4-6 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 57: Power Supply Considerations

    4.4 POWER SUPPLY CONSIDERATIONS There are three standard station battery voltages which can be used to power the 9785 chassis: 48 Vdc, 125 Vdc, or 250 Vdc. Both the 48 V and 125 V station battery voltages require the use of a single, wide-range power supply.

  • Page 58: Transmit Functions

    4.6 TRANSMIT FUNCTIONS This section covers the configuration requirements related to the transmit functions of the 9785. The user must select the transmit frequency, the transmit power level, and how to combine the two keying input signals. 4.6.1 TRANSMIT FREQUENCIES The user must know what transmit frequency is required for the system.

  • Page 59: Receiver Functions

    9785. 4.7.1 LINE TERMINATION The 9785 receiver section can be configured to terminate the incoming line or not. Note that the input of the RF Interface Module is a high impedance input. The termination and protection circuits are located on the Line I/O assembly at the rear of the unit.

  • Page 60: Figure 4-3. 9785 Fail Conditions

    4.7.3 EXTERNAL METER TYPE Two types of external carrier level meters are supported by the 9785. The nominal ±10 dB range can be mapped to either a 0 to 100 μA range, or to ±1.0 Vdc. The desired meter type is selected using jumper J3 on the Receiver Detector module.
  • Page 61 The system can be configured for high or low voice levels using switch SW2-2 on the AM Logic module. Systems are normally configured for high voice level. See paragraph 6.3.7 for more information. RFL 9785 RFL Electronics Inc. March 24, 2008...

  • Page 62: Initial Start-Up Procedure

    This section assumes that the equipment has been installed and configured for the required application in accordance with Section 3 and paragraph 4.3. Note that the modules in the 9785 are not hot pluggable. The power to the chassis must be turned off prior to removing in or installing any modules.
  • Page 63 Disconnect the dummy load and restore the line connection. 4.8.2.2 Output Impedance Once the 9785 has been connected to the line the output impedance should be adjusted to match that of the actual line. Impedance mismatches can cause signal reflections and other undesirable effects. The 9785 Power Amplifier provides an output impedance adjustment to accommodate small variations in actual line conditions.

  • Page 64: Table 4-3. Input Attenuator Settings

    Commander or Hyper-terminal. 4.8.3 RECEIVER After the transmitters at each end of the line have been setup, the receive portions of the 9785 must be adjusted for the actual receive signal level. There is a coarse (attenuator) and fine (level) adjustment for the receive level.

  • Page 65: Section 5. Maintenance

    MUST BE REPLACED BEFORE PLACING THE TERMINAL BACK IN SERVICE. 5.1 INTRODUCTION This section provides maintenance instructions for the RFL 9785. Topics discussed include removal and replacement procedures, fuse replacement and corrective maintenance information. Information is also provided on how to arrange for service by RFL personnel.

  • Page 66: Removal And Replacement

    5.2.1 CIRCUIT BOARD MODULES All RFL 9785 front panel circuit board modules are held in place by card guides at the top and bottom of the chassis, and fit into mating connectors in the chassis motherboard. To remove any RFL 9785 front panel module, with the exception of the power supply module, proceed as follows: Lower the front cover of the RFL 9785.
  • Page 67 5.2.2 POWER SUPPLY MODULE The RFL 9785 power supply module is held in place by card guides at the top and bottom of the chassis, and fits into a mating connector in the chassis motherboard. The top guide is made of aluminum and has a locking lever to insure good heat transfer to a heat sink at the top of the chassis.
  • Page 68 5.2.3 I/O MODULES All RFL 9785 I/O modules are mounted at the rear of the chassis. Each I/O module is held in place by screws at the top and bottom of the I/O module, and fit into mating connectors in the chassis motherboard.

  • Page 69: Fuse Replacement

    SUPPLY MODULE ENERGIZED, SINCE COMPONENT DAMAGE MAY RESULT. The input fuse for RFL 9785 power supply I/O module is located on the rear of the power supply I/O module. The fuse can be changed without removing the power supply I/O module from the chassis. To check and/or replace the fuse, proceed as follows: Place the POWER switch on the power supply I/O module to the OFF position.

  • Page 70: Corrective Maintenance

    RFL 9785, or in some other connected equipment. If the problem lies within the RFL 9785, use the schematics at the end of Sections 6 through 21 to try and determine which module is defective. Once this is done, replace the module; this should solve the problem.

  • Page 71: Section 6. Am Logic Module

    Switches SW1 and SW2 on the 9785 AM Logic Module allows the logic to be set according to the requirements of the specific application. The 9785 AM Logic Module also provides status information for the Sequence of Events Module (SOE).

  • Page 72: Specifications

    Figure 6-2 and the schematic diagram shown in Figure 6-4. 6.3.1 INPUT KEYING CONTROL LOGIC The 9785 AM Logic Module receives its input from the rear panel I/O and modules in the RFL 9785 terminal. It generates output for the transmitter and receiver detector modules based on switch settings and input signals.
  • Page 73 The receiver detector monitors the receive carrier signal strength, and generates a logic signal which is applied to edge connector pin A29 (SIG-COMP-IN) of the 9785 AM Logic Module. A logic-high SIG-COMP-IN or a logic-high CARRIER-SWITCH (indicating local carrier is active) will generate a block.
  • Page 74 If an under-voltage condition is detected by the power supply, the POWER-FAIL (A17) and/or POWERFAIL2 (C16) inputs to the 9785 AM Logic Module will be logic-low. Both signals in the logic-low state will generate a logic-low POWER signal to prevent a BLOCK function for the period of the under-voltage condition plus an additional 320ms.

  • Page 75: Figure 6-2. Block Diagram, Am Logic Module

    VOICE-MUTE (A27) LOGIC RX DETECT (DS1) Figure 6-2. Block diagram, AM Logic Module RFL 9785 RFL Electronics Inc. February 7, 2007 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 76: Controls And Indicators

    Table 6-1. LEDs DS1, DS2 and DS4 through DS7 are visible with the module installed in the chassis. All other controls and indicators are only accessible when the module is removed from the chassis or is on a card extender. Table 6-1. Controls and indicators, RFL 9785 AM Logic Module Component Name/...

  • Page 77: Table 6-2. Switch Settings, Dip Switch Sw1

    Normally energized OFF(DOWN) Normally de-energized SW2-5 RFL 9785 RFL Electronics Inc. February 7, 2007 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 78: Table 6-5. Switch Settings - Block Hold Timer, Dip Switch Sw2-6, -7, -8

    Application Notes: • When using the 9785 Checkback feature the Block Hold Timer MUST be set for 0ms. The Checkback data-bits track the Block Output. As such, they are also extended by the same amount as defined by the Block Hold Timer. This will adversely affect the Checkback Communications since the “low”...

  • Page 79: Figure 6-3. Controls And Indicators, Rfl 9785 Am Logic Module

    TP12 TP13 TP14 TP15 TP10 - TP15 Figure 6-3. Controls and indicators, RFL 9785 AM Logic Module RFL 9785 RFL Electronics Inc. February 7, 2007 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 80 This page intentionally left blank RFL 9785 RFL Electronics Inc. February 7, 2007 6-10 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 81: Figure 6-4. Schematic, Rfl 9785 Am Logic (Dwg. No. D-106544-C) Sheet 1 Of 2

    NOT INSTALLED STRSW_5 STRSW_7 STRSW_9 NOT INSTALLED Figure 6-4. Schematic, RFL 9785 AM Logic (Dwg. No. D-106544-C) Sheet 1 of 2 RFL 9785 RFL Electronics Inc. September 1, 2006 6-11 (6-10 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 82 .1uF AGND NOT INSTALLED NOT INSTALLED A7,B7, -15V Figure 6-4. Schematic, RFL 9785 AM Logic (Dwg. No. D-106544-C) Sheet 2 of 2 9785 RFL Electronics Inc. Sept ember 1, 2006 6-13 (6-12 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 83: Section 7. Transmitter Module

    Figure 7-1. RFL 9785 Transmitter Module 7.1 DESCRIPTION The RFL 9785 Transmitter Module (Figure 7-1) is a programmable powerline carrier transmitter, utilizing Direct Digital Synthesis (DDS). The basic principle of DDS is to generate a stepped sine wave from a high speed digital-to-analog (D/A) converter by reading a sine look-up table stored in ROM.

  • Page 84: Specifications

    7.2 SPECIFICATIONS As of the date this manual was published, the following specifications apply to all RFL 9785 Transmitter modules. Because all RFL products undergo constant refinement and improvement, these specifications are subject to change without notice. Output Frequency: 30 kHz to 535 kHz, adjustable in 10-Hz increments.

  • Page 85: Theory Of Operation

    7.3 THEORY OF OPERATION The RFL 9785 Transmitter module is a programmable powerline carrier transmitter utilizing a Direct Digital Synthesizer (DDS). The DDS is used to generate a precise sine wave signal by reading a sine look-up table stored in ROM. A block diagram of the transmitter module is shown in Figure 7-2, a block diagram of the DDS is shown in Figure 7-3, and a schematic diagram of the transmitter module is shown in figure 7-4.

  • Page 86: Figure 7-3. Block Diagram Of A Basic Dds

    7.3.2 9785 DIRECT DIGITAL SYNTHESIZER In the RFL 9785, the master clock frequency is a precision 50 MHz signal providing nearly 100 points per cycle at the maximum output frequency. The phase accumulator is a 32 bit register which provides over 4 billion possible phase values.

  • Page 87: Controls And Indicators

    Table 7-1. LEDs DS1 through DS9 are visible with the module installed in the chassis. All other controls are only accessible when the module is removed from the chassis or is on a card extender (RFL Part No. 9547-1870). Table 7-1. Controls and indicators, RFL 9785 Transmitter Module...

  • Page 88: Figure 7-4. Controls And Indicators, Rfl 9785 Transmitter Module

    SW8 - SW9 CR23 CR43 SW10 CRZ1 Figure 7-4. Controls and indicators, RFL 9785 Transmitter Module RFL 9785 RFL Electronics Inc. April 25, 2005 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 89 In systems which use the reserve feature, the reserve level can be fixed at 10% or can be variable between approximately 10% and 35% of the power level. When jumper J2 is in the “VAR” position, R18 is used to adjust the reserve level. RFL 9785 RFL Electronics Inc. April 25, 2005 (973) 334-3100 B e c a u s e R F L ™...
  • Page 90 This page intentionally left blank 9785 RFL Electronics Inc. Apri l 25, 2005 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 91: Figure 7-5. Schematic, Rfl 9785 Transmitter (Drawing No. D-106509-C) Sheet 1 Of 2

    .1uF .1uF 1N5817 RESERVE_PWR DG441 -15V Figure 7-5. Schematic, RFL 9785 Transmitter (Drawing No. D-106509-C) Sheet 1 of 2 RFL 9785 RFL Electronics Inc. April 25, 2005 7-9 (7-10 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 92 1. ALL DIODES ARE 1N914B OR EQUIV. UNLESS OTHERWISE SPECIFIED. CR10 STRSW_0 STRSW_1 STRSW_2 Figure 7-5. Schematic, RFL 9785 Transmitter (Drawing No. D-106509-C) Sheet 2 of 2 9785 RFL Electronics Inc. Apri l 25, 2005 7-11 (7-12 Blank) (973) 334-3100...

  • Page 93: Figure 8-1. Rfl 9785 Power Amplifier Module

    Figure 8-1. RFL 9785 Power Amplifier Module 8.1 DESCRIPTION The RFL Power Amplifier module provides both voltage and current gain to the signal coming from the Transmitter module (Section 7). A monitor circuit detects loss of transmit signal and issues a Transmitter Fail Alarm.

  • Page 94: Specifications

    8.2 SPECIFICATIONS As of the date this manual was published, the following specifications apply to all RFL 9785 Power Amplifier modules, except where indicated. Because all RFL products undergo constant refinement and improvement, these specifications are subject to change without notice.
  • Page 95 Refer to the schematic diagram in Figure 8-3 for the following discussion. The design of the RFL 9785 power amplifier is based on a single hybrid power operational amplifier, U1. The input signal is ac coupled through C1. The voltage gain of the amplifier is determined by the ratio of feedback resistor R4 and input resistors R3 (fixed) and R2 (variable).

  • Page 96: Figure 8-2. Controls And Indicators, Rfl 9785 Power Amplifier Module

    8.4 CONTROLS AND INDICATORS Figure 8-2 shows the location of all controls and indicators on the RFL 9785 Power Amplifier module. These controls and indicators are described in Table 8-1. Potentiometers R2, R10 and R16 are accessible with the RFL 9785 Power Amplifier Module installed in the chassis. Test points TP1, TP2 and TP3 are only accessible when the module is removed from the chassis or is on a card extender.

  • Page 97: Table 8-1. Controls And Indicators, Rfl 9785 Power Amplifier Module

    2. Remove the load from the output of the 9785 and measure the output signal voltage. 3. Connect the (actual) load to the 9785 and adjust potentiometer R16 (IMP ADJ) to obtain one- half of the unloaded output signal level.
  • Page 98 Figure 8-3. Schematic, RFL 9785 Power Amp (Dwg. No. C-106464-D) RFL 9785 RFL Electronics Inc. September 1, 2006 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 99: Section 9. Rfl 9508 Rf Chassis

    Figure 9-1. RFL 9508 RF Chassis Front Views 9.1 INTRODUCTION The RFL 9508 RF Chassis, for use with the 9780/9785, amplifies the rf outputs of the 9780/85 before they are passed to the line coupling equipment. The RFL 9508 RF Chassis shown in Figure 9-1a develops 50 Watts PEP.

  • Page 100: Module Descriptions, Rfl 9508 Rf Chassis

    9.2 MODULE DESCRIPTIONS, RFL 9508 RF CHASSIS The RFL 9508 RF Chassis is located above the RFL 9780/85 as shown in Figure 9-1. The following eight modules are included in the RF section of the RFL 9508 RF chassis. Table 9-1. Modules included in 9508 RF Chassis...

  • Page 101: Figure 9-3. Rfl 9508 Rf Chassis Block Diagram

    SIGNAL OUT 4W IN RX CONNECTION BOARD or RX FILTER SIGNAL OUT SIGNAL OUT INPUT Figure 9-3. RFL 9508 RF Chassis Block Diagram RFL 9785 RFL Electronics Inc. May 16, 2011 9-3 (9-4 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 102: Figure 9-4. Rfl 9508 Power Amplifier

    Figure 9-4. RFL 9508 Power Amplifier 9.2.1.1 DESCRIPTION The Power Amplifier is mounted on the front cover of the RFL 9508 RF Chassis. The function of the Power Amplifier is to amplify the RF outputs of the RFL 9780/85 terminal before these signals are passed to the line coupling equipment.
  • Page 103 9.2.1.2 SPECIFICATIONS As of the date this manual was published, the following specifications apply to all RFL 9508 Power Amps, unless otherwise noted. Because all RFL products undergo constant refinement and improvement, these specifications are subject to change without notice.

  • Page 104: Figure 9-5. Rfl 9508 Power Amplifier, Power Supply

    Figure 9-5. RFL 9508 Power Amplifier, Power Supply 9.2.2.1 DESCRIPTION As it’s name implies, the Power Amplifier, Power Supply supplies power to the RFL 9508 Power Amplifier. There are two different types of Power Amplifier, Power Supplies available as shown in Table 9-2.

  • Page 105: Figure 9-6. 9508 Power Amplifier Power Supply, Block Diagram

    As of the date this manual was published, the following specifications apply to all 9508 Power Amplifier, Power Supply modules, except where indicated. Because all RFL products undergo constant refinement and improvement, these specifications are subject to change without notice.

  • Page 106: Figure 9-7. Tx Filter, Top View

    Figure 9-7. Tx Filter, Top View 9.2.3.1 DESCRIPTION The RFL 9508 Tx Filter is a plug-in module consisting of two PC boards and two air core inductors. It plugs into the left side of the RF chassis as shown in Figure 9-2.

  • Page 107: Figure 9-8. Balance Board

    Figure 9-8. Balance Board 9.2.4.1 DESCRIPTION The RFL 9508 Balance Board is a plug-in module consisting of a PC board, a transformer, two power resistors, two relays, three jumpers (J2, J3 and J4) and various other components. It has an aluminum heat sink covering a portion of the board as shown in Figure 9-8.

  • Page 108: Figure 9-9. Line Board

    Figure 9-9. Line Board 9.2.5.1 DESCRIPTION The RFL 9508 Line Board serves as the connection point between the RFL 9508 RF Chassis and the Line Coupling equipment. Because it contains no active components, the Line Board does not require any dc input voltage.
  • Page 109 A block diagram of the Line Board appears in Figure 9-10. 9.2.5.3.1 HYBRID TRANSFORMERS The RFL 9508 Line Board contains two hybrid transformers, T3 and T4. The primary winding of T3 accepts the transmit input signal, and the primary winding of T4 develops the receive output signal that is passed to the Rx Filter.

  • Page 110: Figure 9-10. Block Diagram, Rfl 9508 Line Board

    Arrestors Receive Receive Output Attenuator Rx Filter Figure 9-10. Block diagram, RFL 9508 Line Board RFL 9785 RFL Electronics Inc. May 16, 2011 9-13 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 111: Figure 9-11. Rfl 9508 Rx Filter Board

    9.2.6.1 DESCRIPTION The function of the Rx Filter is to prevent harmonics and noise from coming into RFL 9508 from the power line that is out of the bandwidth of the filter. The bandwidth of the Rx Filter can be set to either 8kHz or 16kHz using two programmable jumpers on the board.

  • Page 112: Figure 9-12. Rfl 9508 Rx Connection Board

    9.2.7 RX CONNECTION BOARD Figure 9-12. RFL 9508 Rx Connection Board 9.2.7.1 DESCRIPTION The Rx Connection Board is used in place of the Rx Filter in applications that do not require an Rx Filter. RFL 9785 RFL Electronics Inc. May 16, 2011...

  • Page 113: Figure 9-13. Rfl 9508 Attenuator Board

    Figure 9-13. RFL 9508 Attenuator Board 9.2.8.1 DESCRIPTION The RFL 9508 Attenuator Board consists of five 10 watt power resistors, several other smaller resistors, a two- position toggle switch, and two test points. The function of the attenuator board is to provide 40dB of attenuation during loopback testing. Toggle switch SW1 is used to select either Normal or Loopback operation.

  • Page 114: Figure 9-14. Rfl 9508 Rf Motherboard, Rear View

    9.2.9.1 DESCRIPTION The RFL 9508 RF Motherboard is a 4.5 x 8 inch assembly, which is mounted on the rear right side of the 9508 chassis as viewed from the front. It provides interconnections for the five RF modules that plug into it from the front of the chassis, which are the TX Filter, Balance Board, Line Board, Attenuator Board, Rx Filter.

  • Page 115: Table 9-4. Tb1 Terminal Assignments

    If this is not feasible, shorting the wire to TB1-7 (Chassis Ground) is an alternate method. This will cause surge currents to pass through the Mother Board and chassis before exiting to ground. Connecting directly to the sub-station ground bar is preferred. RFL 9785 RFL Electronics Inc. May 16, 2011...

  • Page 116: Module Placement In The Rf Chassis (50W Systems)

    50 Watt systems are housed in a 6U high chassis. The upper part of the chassis is the RF Section, and the lower part of the chassis is the RFL 9780/85. Module placement in the RF Chassis is shown in Table 9-5, and Figures 9-2, and 9-15.
  • Page 117 It has five connectors on the front for plug-in modules, and several connectors and an eight-position terminal strip, which protrude through the rear to allow for connections to other modules in the chassis. RFL 9785 RFL Electronics Inc. May 16, 2011...

  • Page 118: Cabling In The Rf Chassis

    The interior of the 9508 RF chassis will have four cables installed. The cable part numbers and from-to connections are shown in Table 9-6 and are shown pictorially in Figure 9-16. Table 9-6. 9508 RF Chassis Cables RFL cable part From Function...

  • Page 119: Figure 9-16. Cable Connections In The Rf Chassis

    Rear View Of Power Amp Power Supply Rear View of RF Chassis Motherboard Rear View of Power Amplifier Figure 9-16. Cable connections in the RF Chassis RFL 9785 RFL Electronics Inc. May 16, 2011 9-22 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 120: Module Placement In The Rf Chassis (100W Systems)

    50W POWER AMP BOARD (Mounted on front door, not shown for clarity) Figure 9-17. Module placement in auxiliary 3U RF Chassis for 100W Systems (Top View) RFL 9785 RFL Electronics Inc. May 16, 2011 9-23 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 121: Setting Jumpers In The 9508 Rf Chassis

    9.6 SETTING JUMPERS IN THE 9508 RF CHASSIS The Analog Chassis has several modules, which have jumpers or switches that must be set, and adjustments that must be made, to configure the RFL 9508 system for proper operation. These modules are listed in Table 9-7.

  • Page 122: Figure 9-18. Circuit Board Of 50W Power Amp, Locations Of Jumpers, Connectors, Switches And Potentiometers

    If the protective circuits are activated the Power Amplifier will shut down for approximately 2.5 seconds and then come up for 25ms. This pattern will continue until the safety parameters are met and the condition cleared. RFL 9785 RFL Electronics Inc. May 16, 2011...

  • Page 123: Table 9-8. Function Of Jumpers, Connectors And Potentiometers On Power Amp

    RF output power level adjustment. R163* potentiometer For factory use only. * Effective October 2010 RFL 9785 RFL Electronics Inc. May 16, 2011 9-26 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 124: Table 9-9. Function Of Dip Switches Sw1 And Sw2 On Power Amp Board

    Note that the Phase Detector circuit will also shut down the Power Amplifier if the output voltage is above the set threshold and the output current is very low (well below 200ma). RFL 9785 RFL Electronics Inc. May 16, 2011...

  • Page 125: Table 9-10. Tx Filter Setup Jumpers

    NMS software. For example, for a center frequency of 90kHz, the following jumpers should be installed: J3, 5, 6, 8, 10, 11, 18, 20, 23, 24, 34, 35, 37 and 38 RFL 9785 RFL Electronics Inc. May 16, 2011...

  • Page 126: Figure 9-19. Location Of Jumpers On Tx Filter, Pc Board 107828-2

    AIR CORE INDUCTOR AIR CORE INDUCTOR Figure 9-19. Location of jumpers on Tx Filter, PC Board 107828-2 RFL 9785 RFL Electronics Inc. May 16, 2011 9-29 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 127: Figure 9-20. Location Of Jumpers On Tx Filter, Pc Board 107828-1

    Figure 9-20. Location of jumpers on Tx Filter, PC Board 107828-1 RFL 9785 RFL Electronics Inc. May 16, 2011 9-30 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 128: Table 9-11. Setting Jumpers On Balance Board

    Jumper Settings Jumper Settings Jumper Settings One (50W) Two (100W) RFL 9785 RFL Electronics Inc. May 16, 2011 9-31 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 129: Figure 9-21. Location Of Jumpers On Line Board

    Refer to Table 9-11 for information on how to configure these jumpers on the Line Board. J14 J21 J15 J22 J17 J18 Figure 9-21. Location of Jumpers on Line Board RFL 9785 RFL Electronics Inc. May 16, 2011 9-32 (973) 334-3100...

  • Page 130: Table 9-12. Line Board Setup Jumpers And Switch Setting

    UP position. In Loopback operation set to switch to the DOWN position. The switch location is shown in Figure 9-12, and is accessible when the Attenuator Board is plugged into the chassis. RFL 9785 RFL Electronics Inc. May 16, 2011...
  • Page 131 Adjust L1 to get the desired attenuation at +18 kHz >9.5 dBm. Adjust L3 to get the desired attenuation at +18 kHz >9.5 dBm. Check the ripple between +/-8 kHz from the center frequency to be < 0.35 dBm. RFL 9785 RFL Electronics Inc. May 16, 2011...

  • Page 132: Figure 9-22. Location Of Jumpers On Rx Filter Board, Showing Jumper Groupings

    “JL3” GROUP “JE” GROUP “JL1” GROUP “JD” GROUP Figure 9-22. Location of Jumpers on Rx Filter Board, showing jumper groupings. RFL 9785 RFL Electronics Inc. May 16, 2011 9-35 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 133 Tune the TX filter to the proper band (section 9.6.2) Tune the RX filter to the proper band (section 9.6.6) Set the transceiver Transmit and Receive frequencies (RF Setup in NMS) Perform the commissioning procedure. RFL 9785 RFL Electronics Inc. May 16, 2011 9-36 (973) 334-3100 B e c a u s e R F L ™...

  • Page 134: Rear Panel Wiring For 9780/85 For 50W Applications

    EXTERNAL POWER/AMP I/O J1-B J2-B J5-B JP3-B JP4-B Figure 9-23. Rear Panel Wiring Of Typical RFL 9785, 2W System, 50W Chassis RFL 9785 RFL Electronics Inc. May 16, 2011 9-37 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 135: Rear Panel Wiring For 9780/85 For 100W Applications

    J2-B A SEPARATE WIRE TO THE J5-B SUB-STATION GROUND BAR JP3-B JP4-B Figure 9-24. Rear Panel Wiring Of Typical RFL 9785, 2W System, 100W Chassis RFL 9785 RFL Electronics Inc. 16, 2011 9-38 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 136: Figure 9-25. 9508 Line Board (B-103094-E)

    Figure 9-25. 9508 Line Board (B-103094-E) RFL 9785 RFL Electronics Inc. November 1, 2010 9-39(9-40 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 137: Figure 9-26. 9508 Tx Filter (D-107829-D)

    Figure 9-26. 9508 Tx Filter (D-107829-D) RFL 9785 RFL Electronics Inc. November 1, 2010 9-41(9-42 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 138: Figure 9-27. 9508 Rx Filter (Plci- Linrxv1.1.Dsn)

    Figure 9-27. 9508 RX Filter (PLCI- LINRXV1.1.DSN) 9785 RFL Electronics Inc. Novem ber 1, 2010 9-43(9-44 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 139: Figure 9-28. 9508 Attenuator Board (B-107814-B)

    Figure 9-28. 9508 Attenuator Board (B-107814-B) RFL 9785 RFL Electronics Inc. November 1, 2010 9-45 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 140: Figure 9-29. 9508 Balance Board, Plci (B-107819-A)

    Figure 9-29. 9508 Balance Board, PLCI (B-107819-A) RFL 9785 RFL El ectronics Inc. Novem ber 1, 2010 9-46 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 141: Figure 9-30. 9508 Rf Mother Board (B-103099-C)

    Figure 9-30. 9508 RF Mother Board (B-103099-C) 9785 RFL Electronics Inc. Novem ber 1, 2010 9-47(9-48 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 142: Section 10. Output Filter Modules

    RFL 9785 Output Filter Modules are used to reduce the harmonic content of the RFL 9785's output signal to a level that is at least 55 dB below the carrier level. A typical RFL 9785 Output Filter module appears in Figure 10-1.

  • Page 143: Specifications

    10.2 SPECIFICATIONS As of the date this manual was published, the following specifications apply to all RFL 9785 Output Filter modules, except as indicated. Because all RFL products undergo constant refinement and improvement, these specifications are subject to change without notice.

  • Page 144: Theory Of Operation

    Refer to Section 16 for additional information. 10.4 CONTROLS AND INDICATORS The RFL 9785 Output Filter Modules 106530-1, -2, -3, -5, -11, -12, -13, and -15 each contain seven, three position jumpers. The 106530-4 and -14 modules do not have jumpers. The jumpers are used to select the desired passband frequency from within the filters overall span.

  • Page 145: Table 10-1. Controls And Indicators, Rfl 9785 Output Filter Modules

    Table 10-1. Controls and indicators, RFL 9785 Output Filter Modules Component Name/ Function Designator Description Trimmer capacitor Adjusts phase of voltage across one of the transformer secondaries. For factory use only Jumper Jumper Jumper Passband frequency select jumpers. Jumper See Table 10-2, and Figures 10-2 and 10-3...

  • Page 146: Figure 10-2. Controls And Indicators, Rfl 9785 Output Filter Modules (106530-1 To 106530-5)

    TP4- TP1- Figure 10-2. Controls and indicators, RFL 9785 Output Filter modules (106530-1 to 106530-5) TP4-8 TP10 TP1-3 TP12 TP13 TP11 Figure 10-3. Controls and indicators, RFL 9785 Output Filter Modules (106530-11 to 106530-15) RFL 9785 RFL Electronics Inc. June 18, 2009...

  • Page 147: Table 10-2. Rfl 9785 Output Filter Modules, Frequency Ranges

    Table 10-2. RFL 9785 Output Filter Modules, frequency ranges Filter Module Jumper Position Passband Frequency Range Approximate Frequency Of Part No. Greatest Attenuation 106530-1, -11 30 to 41.5 kHz 90 kHz 38 to 52.5 kHz 114 kHz 49 to 67.5 kHz...

  • Page 148: Figure 10-4. Schematic, Rfl 9785 Output Filters Without Rpm, Assy Nos. 106530-1 To -5 (Dwg. No. D-106534-D)

    RFL P/N 99403-3 RFL P/N 99404 RFL P/N 99403-4 1N914B (BLACK) Figure 10-4. Schematic, RFL 9785 Output Filters Without RPM, Assy Nos. 106530-1 to -5 (Dwg. No. D-106534-D) RFL 9785 RFL Electronics Inc. June 18, 2009 10-7 (10-8 Blank) (973) 334-3100...

  • Page 149: Figure 10-5. Schematic, Rfl 9785 Output Filters With Rpm, Assy Nos. 106530-11 To -15 (Dwg. No. D-106534-1-H)

    Figure 10-5. Schematic, RFL 9785 Output Filters with RPM, Assy Nos. 106530-11 to -15 (Dwg. No. D-106534-1-H) 9785 RFL Electronics Inc. June 18, 2009 10-9 (10-10 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 150: Section 11. Receiver Downshifter Module

    Figure 11-1. RFL 9785 Receiver Downshifter Module 11.1 DESCRIPTION The RFL 9785 Receiver Downshifter Module (Figure 11-1) is used to shift the desired set of incoming rf signals down to a lower range, around 24 kHz, to be further processed by the receiver detector module (Section 12).

  • Page 151: Specifications

    11.2 SPECIFICATIONS As of the date this manual was published, the following specifications apply to all RFL 9785 Receiver Downshifter modules. Because all RFL products undergo constant refinement and improvement, these specifications are subject to change without notice. Frequency Range: 30 kHz to 535 kHz, frequency is adjustable in 250 Hz steps.

  • Page 152: Figure 11-2. Block Diagram, Rfl 9785 Receiver Downshifter Module

    -15V * WHEN PRESENT Figure 11-2. Block diagram, RFL 9785 Receiver Downshifter Module Synthesizer. Synthesizer U3 sets the frequency at which the demodulator section will receive inputs. DIP switches SW1 and SW2 program U3 for a frequency 2 kHz below the incoming carrier frequency.
  • Page 153 J2. The gain of amplifier U15 is variable between 0.1 and 5.1, as determined by the setting of GAIN potentiometer R69. Input Low-Pass Filter. The incoming carrier enters the RFL 9785 Receiver Downshifter module through edge connector terminals C15 and C16. It then passes through the input low-pass filter formed from capacitors C2, C3, C95 and C96 and inductors L1, L10 and L11.

  • Page 154: Controls And Indicators

    Test point Reference frequency for phase locked loop TP20 Test point (white) Rx input high RFL 9785 RFL Electronics Inc. June 18, 2009 11-5 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 155: Table 11-2. Receive Frequency Select Switches

    SW2-4 SW2-5 SW2-6 SW2-7 SW2-8 RFL 9785 RFL Electronics Inc. June 18, 2009 11-6 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 156: Figure 11-3. Controls And Indicators, Rfl 9785 Receiver Downshifter Module

    TP18 TP15 C102 C101 50 40 30 20 10 TP10 Figure 11-3. Controls and indicators, RFL 9785 Receiver Downshifter Module RFL 9785 RFL Electronics Inc. June 18, 2009 11-7 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 157 This page intentionally left blank RFL 9785 RFL Electronics Inc. June 18, 2009 11-8 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 158: Figure 11-4. Schematic, Rfl 9785 Rx Downshifter (Dwg. No. D-106579-E) Sheet 1 Of 2

    Figure 11-4. Schematic, RFL 9785 RX Downshifter (Dwg. No. D-106579-E) Sheet 1 of 2 RFL 9785 RFL Electronics Inc. June 18, 2009 11-9(11-12 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 159 Figure 11-4. Schematic, RFL 9785 RX Downshifter (Dwg. No. D-106579-E) Sheet 2 of 2 9785 RFL Electronics Inc. June 18, 2009 11-11(11-12 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 160: Section 12. Receiver Detector Module

    An optional voice filter when the RFL 9785 voice option is used. NOTE The dotted area in Figure 12-1 indicates the location of the Voice Filter when the RFL 9785 voice option is used. The Voice Filter plugs into connectors J1 and J2 within the dotted area of Figure 12-1.

  • Page 161: Specifications

    12.2 SPECIFICATIONS As of the date this manual was published, the following specifications apply to all RFL 9785 Receiver Detector modules, except where indicated. Because all RFL products undergo constant refinement and improvement, these specifications are subject to change without notice.

  • Page 162: Theory Of Operation

    12.3 THEORY OF OPERATION The RFL 9785 Receiver Detector module contains a narrowband filter, a signal monitoring circuit, a carrier level indicator, and an optional voice filter. A block diagram of the Receiver Detector module appears in Figure 12-2 and its schematic appears in Figure 12-5.
  • Page 163 The signal passed by the narrowband filter is fed to operational amplifier U3B, which serves as a buffer. The output of this buffer is passed through edge connector terminal C16 to the RFL 9785 Limiter Slicer module for further processing. It is also fed to a precision rectifier and averager formed from operational amplifiers U1A and U1B, and their associated components.

  • Page 164: Controls And Indicators

    12.4 CONTROLS AND INDICATORS Figure 12-3 shows the location of all controls and indicators on the RFL 9785 Receiver Detector module. These controls and indicators are described in Table 12-1. Only R26 and R34 are accessible with the RFL 9785 Receiver Detector module installed in the chassis. All others are accessible when the module is removed from the chassis or is on a card extender.

  • Page 165: Figure 12-3. Controls And Indicators, Rfl 9785 Receiver Detector Module

    C61B C58B C58A C57A C57B TP11 Figure 12-3. Controls and indicators, RFL 9785 Receiver Detector module RFL 9785 RFL Electronics Inc. July 7, 2006 12-6 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 166 Connectors J1 and J2 are used when the voice filter is installed. The voice filter plugs into these connectors and is secured to the board with four standoffs and screws. Refer to Section 15 for more information on the Voice Module and the voice filter. RFL 9785 RFL Electronics Inc. July 7, 2006...
  • Page 167 This page intentionally left blank 9785 RFL Electronics Inc. y 7, 2006 12-8 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 168: Figure 12-4. Schematic, Rfl 9785 Rx Detector (Dwg. No. D-106519-F) Sheet 1 Of 2

    Figure 12-4 Schematic, RFL 9785 RX Detector (Dwg. No. D-106519-F) Sheet 1 of 2 RFL 9785 RFL Electronics Inc. July 7, 2006 12-9(12-10 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 169 Figure 12-4 Schematic, RFL 9785 RX Detector (Dwg. No. D-106519-F) Sheet 2 of 2 RFL 9785 RFL Electronics Inc. July 7, 2006 12-11(12-12 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 170: Introduction

    Figure 13-1. Views of Sequence of Events/IRIG-B Module and SOE/IRIG-B I/O Module 13.1 INTRODUCTION The RFL 9785 SOE/IRIG-B module is shown in Figure 13-1a, and the RFL 9785 SOE/IRIG-B I/O module is shown in Figure 13-1b. The SOE/IRIG-B module is used to record the status of data points in a log by storing data in a non-volatile memory.

  • Page 171: Table 13-1. Events Recorded By The Rfl 9785 Sequence Of Events Module

    13.2 SEQUENCE OF EVENTS/IRIG-B MODULE 13.2.1 DESCRIPTION The RFL 9785 SOE/IRIG-B module is a status monitor card for the RFL 9785 which monitors input status every 1 ms. Events are recorded when any point changes state or if the CPU gets reset. The Sequence Of Events log is a record of the state of each point, the state of CPU reset, and the date and time the record was saved.
  • Page 172 80C320. It consists of a shunt regulator, a comparator, switches and an ICM7555. SW1 is an eight position DIP switch which allows the user to set the mode of operation. For the RFL 9785 application, SW1-1, -2 and -3 should be in the ON position, and SW-5 should be in the ON position.

  • Page 173: Figure 13-2. Controls And Indicators For Rfl 9785 Soe/Irig-B Module

    13.2.4 CONTROLS AND INDICATORS Figure 13-2 shows the location of all jumpers, test points and switches on the RFL 9785 SOE/IRIG-B module. The functions of these jumpers, test points and switches are described in Table 13-2. All of these items are accessible only when the module is removed from the chassis or is on a card extender.

  • Page 174: Table 13-2. Controls And Indicators, Rfl 9785 Soe/Irig-B Module

    Table 13-2. Controls and indicators, RFL 9785 SOE/IRIG-B module Component Name/Description Function Designator Jumper (RUN/TEST) RUN position selects Normal operation. TEST position selects Test operation. Jumper (512 or Header and jumper not installed. For factory use only. 128/256) Jumper (1643/1644) 1643 position selects DS1643 RAM.
  • Page 175 This page intentionally left blank 9785 RFL Electronics Inc. Decem ber 7, 2009 13-6 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 176: Figure 13-3. Schematic, Rfl9785 Soe/Irig-B (Dwg. No. D-106484-1-D) Sheet 1 Of 2

    Figure 13-3. Schematic, RFL9785 SOE/IRIG-B (Dwg. No. D-106484-1-D) Sheet 1 of 2 RFL 9785 RFL Electronics Inc. December 7, 2009 13-7(13-8 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 177 Figure 13-3. Schematic, RFL 9785 SOE/IRIG-B With Reflected Power Meter (Dwg. No. D-106484-1-D) Sheet 2 of 2 9785 RFL Electronics Inc. Decem ber 7, 2009 13-9(13-10 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 178: Sequence Of Events/Irig-B I/O Module

    Figure 13-4. Board and panel views of RFL 9785 SOE/IRIG-B I/O module 13.3.1 DESCRIPTION The RFL 9785 SOE/IRIG-B I/O module provides an interface between the IRIG-B receiver and the RFL 9785 SOE/IRIG-B module. It has provisions for modulated (bipolar) or demodulated (TTL) IRIG-B inputs, and provides an RS-232 connector to access the sequence of events log.

  • Page 179: Figure 13-5. Controls And Indicators For The Rfl 9785 Soe/Irig-B I/O Module

    13.3.2 CONTROLS AND INDICATORS Figure 13-6 shows the location of all jumpers, test points and connectors on the RFL 9785 SOE/IRIG- B I/O module. The functions of these jumpers, test points and connectors are described in Table 13-4. All of these items are accessible only when the module is removed from the chassis or is on a card extender.

  • Page 180: Figure 13-6. Schematic, Rfl 9785 Soe/Irig-B I/O (Dwg. No. D-106479-B)

    .01UF .01UF .01UF .01UF .01UF .01UF * COMPONENTS "N/A" FOR 9780, ASS'Y 106475-1. Figure 13-6. Schematic, RFL 9785 SOE/IRIG-B I/O (Dwg. No. D-106479-B) 9785 RFL Electronics Inc. Decem ber 7, 2009 13-13(13-14 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 181: Introduction

    The front port of the 9785 is typically connected directly to a terminal or PC using a standard (straight-through) connector as shown in Figure 14-1. The rear port of the 9785 is intended for connection to a stand-alone modem or multi-port switch (such as the RFL 9660 Digital Switch) using a standard (straight-through) connector as shown in Figure 14-2.

  • Page 182: Viewing April Commands

    14.3 VIEWING APRIL COMMANDS Once you have connected a terminal or PC to the RFL 9785 (either directly or through an RFL 9660 Digital Switch) and pressed the [ENTER] key the RFL 9785 will send the following prompt to your terminal: 9785>...

  • Page 183: Displaying April Help

    9785>H [ENTER] This tells the RFL 9785 to send a list of APRIL commands called the "main menu" to your terminal. The main menu appears in Figure 14-3. RFL Electronics APRIL(t) Remote Communications, Version 2.1 (c)1993,1999 H - Display the main menu...

  • Page 184: Viewing The Values Display

    9785>V [ENTER] The “V” command tells the RFL 9785 to send a copy of the values display to your terminal. This display is for viewing only and cannot be changed by the user. A typical values display is shown in Figure 14-4.
  • Page 185 100 – RxCh1 Level Indicates the Channel 1 receive level (+/-10 dB from nominal). This is the same number that is displayed on the RFL 9785 front panel digital meter. 102 – TxCh1 PWR(50ohm) Indicates the amount of power that would be transmitted into an ideal, balanced 50Ω...

  • Page 186: The Programming Mode

    14.6 THE PROGRAMMING MODE You can use APRIL and your terminal to program the RFL 9785. To use your PC or terminal to program the RFL 9785, use the “P” command. 9785>P [ENTER] The “P” command tells the RFL 9785 to send a list of all programming commands to your terminal.
  • Page 187 The “Q” command tells the RFL 9785 to leave the programming mode and return to the normal “9785>” prompt. If you changed any setting while in the programming mode, be sure to use the “SV” command described above to save the changes before invoking the “Q” command; otherwise, your changes will be lost.

  • Page 188: Figure 14-6. Typical Parameter Settings Display

    To view a list of all current parameter settings, use the “D” command. 9785-P>D [ENTER] When you invoke the “D” command, the RFL 9785 sends a list of all current parameter settings to your terminal. A typical parameter settings display is shown in Figure 14-6.
  • Page 189 Type in the desired frequency (for example: 190000), and then press the [ENTER] key. The Channel 1 frequency will be re-displayed, set to the new value. 053 Freq Ch1 (Hz) 190000 RFL 9785 RFL Electronics Inc. April 25, 2005 14-9 (973) 334-3100 B e c a u s e R F L ™...

  • Page 190: Reading Parameter Settings

    14.7 READING PARAMETER SETTINGS The “D” command tells the RFL 9785 to send a list of all parameter settings to your terminal. This list of settings is called the “read settings” menu. 9785>D [ENTER] A typical read settings menu for the Audio System appears in Figure 14-7. The settings described in paragraph 14.6.4 are shown, but you can’t change the displayed values.

  • Page 191: The Update Mode

    “N/A” indicates that the parameter is not applicable for this configuration system. To exit the update mode, press the [X] key, followed by the [ENTER] key. The screen on your terminal will be cleared, and the “9785>” prompt will re- appear.

  • Page 192: The Sequence-Of-Events Mode

    14.10 THE SEQUENCE-OF-EVENTS MODE The sequence-of-events log is a data file that keeps track of every time one of the RFL 9785 changes state, and the conditions that existed at that time. The sequence-of-events log is battery backed and can store up to 40 records.
  • Page 193 When you invoke the “H” command, the sequence-of-events menu shown in Figure 14-11 will re- appear on your screen. 14.10.2 DUMPING THE SEQUENCE-OF-EVENTS LOG TO A PORT To transfer the event records in the sequence-of-events log from the RFL 9785 to your terminal or PC, use the “D” command: 9785-S>D [ENTER] When you invoke the “D”...

  • Page 194: Figure 14-11. Typical Directory Of Events Display

    To force the SOE Module to record an SOE log entry, use the “F” command: 9785-S>F [ENTER The “F” command tells the RFL 9785 SOE Module to create an entry in the log showing the status of all signals, time-stamped to the present time and date.

  • Page 195: The Window Remote April Mode

    The Window Remote APRIL mode allows the user access an additional module through the same RS- 232 port. This is typically used in a 9785 chassis to communicate with a 9785 Checkback Module also located in the chassis. To enter the Window Remote APRIL mode, use the “W” command 9785>W [ENTER]...

  • Page 196: Password Protection

    When you invoke the “P” command, the following prompt appears: enter password: Enter the password that has been stored in the RFL 9785’s memory. The RFL 9785 gives you three chances to enter the correct password. After the third incorrect password is entered, the RFL 9785 enters a lock-out mode.

  • Page 197: Section 15. Voice Module

    (Figure 15-7), and a handset. When the voice option is used, the voice module is plugged into the appropriate slot in the front of the RFL 9785 chassis. In addition to this the voice filter must be plugged into the Receiver Detector module (see Section 12), and the handset must be plugged into the front of the RFL 9785 front panel or hard wired to the rear of the chassis.

  • Page 198: Specifications

    15.2 SPECIFICATIONS As of the date this manual was published, the following specifications apply to the all RFL 9785 Voice Modules. Because all RFL products undergo constant refinement and improvement, these specifications are subject to change without notice. Dynamic Range: 30 dB.

  • Page 199: Figure 15-3. Block Diagram, Rfl 9785 Voice Module

    ENABLE DETECTOR TO AM LOGIC MODULE TRANSMITTER SECTION (PARA. 14.3.1) Figure 15-3. Block diagram, RFL 9785 Voice Module RFL 9785 RFL Electronics Inc. April 25, 2005 15-3 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 200 The action of LCR1 makes U2 act as an AGC amplifier. The output of the AGC amplifier is routed to J2 and edge connector terminal C13. In most RFL 9785 systems, J2 is strapped for AGC in. The AGC output is the reference signal for the AGC circuit. In some applications, additional control circuits may be added in series with the AGC amplifier output.
  • Page 201 This will hold U6A-2 high, disabling the call tone detection function. NOTE L2 is equivalent to 77.62 mH and is formed by GIC (general impedance converter) circuit U11, R116-119 and C64. RFL 9785 RFL Electronics Inc. April 25, 2005 15-5 (973) 334-3100 B e c a u s e R F L ™...

  • Page 202: Controls And Indicators

    Controls the location of the Alarm Cutoff contacts as follows: internal/external INT: Contacts located in handset plug. EXT: Contacts located at 9785 rear panel terminal block. Jumper, enable /disable Controls Audible alarm as follows: ENABLE: Audible alarm enabled DISABLE: Audible alarm disabled.

  • Page 203: Figure 15-4. Controls And Indicators, Rfl 9785 Voice Module

    R108 R110 CR23 CR21 R109 CR22 Figure 15-4. Controls and indicators, RFL 9785 Voice Module RFL 9785 RFL Electronics Inc. April 25, 2005 15-7 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 204 This page intentionally left blank RFL 9785 RFL Electronics Inc. April 25, 2005 15-8 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 205: Figure 15-5. Schematic, Rfl 9785 Voice Module (Dwg. No. D-106569-C)

    .1uF 68.1K TONE R125 R119 CALL TONE FILTER & OSC Figure 15-5. Schematic, RFL 9785 Voice Module (Dwg. No. D-106569-C) 9785 RFL Electronics Inc. Apri l 25, 2005 15-9 (15-10 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 206: Voice Filter

    A14, where it is demodulated and further processed. NOTE The plug-on voice filter is only used on the RFL 9785 when the voice option is used. This filter contains five potentiometers. Only one of these potentiometers (R43) can be adjusted in the field, using the instructions given in Section 4 of this manual.

  • Page 207: Figure 15-7. Controls And Indicators, And Component Locator Drawing, Rfl 9785 Voice Filter

    Test point Buffered input signal 106583 REV B 97 VOICE FILTER 1999 RFL ELECTRONICS INC Figure 15-7. Controls and indicators, and component locator drawing, RFL 9785 Voice Filter RFL 9785 RFL Electronics Inc. April 25, 2005 15-12 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 208: Figure 15-8. Schematic, Rfl 9785 Voice Filter (Dwg. No. D-106584-B)

    2200pF 2.87K 5.36K 2.61K 270pF 1K CW 1K CW Figure 15-8. Schematic, RFL 9785 Voice Filter (Dwg. No. D-106584-B) 9785 RFL Electronics Inc. Apri l 25, 2005 15-13 (15-14 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 209: Section 16. Checkback Module

    RS-232 connector located on the SOE I/O Module (RFL 9785 rear panel). The front panel of the RFL 9785 Checkback Module serves as the local operator interface. It has pushbutton switches which allow the entry of operating parameters and control functions. A 3-digit LED display shows operating parameters, and LED annunciators display pertinent system data.

  • Page 210: Figure 16-2. Two-Terminal Line Testing

    REMOTE 3 REMOTE 1 REMOTE 2 Figure 16-4. Four-terminal line testing Figure 16-4. Four-terminal line testing RFL 9785 RFL Electronics Inc. July 26, 2007 16-2 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 211: Specifications

    16.2 SPECIFICATIONS As of the date this manual was published, the following specifications apply to all RFL 9785 Checkback modules. Because all RFL products undergo constant refinement and improvement, these specifications are subject to change without notice. Codes: Capable of transmitting and receiving 16 asynchronous codes (01 through 16)
  • Page 212 When the HC2 switch is pressed at the Remote, Hard Carrier Request Code 06 is sent at full power. The Master receives this code, and sends a continuous hard carrier back at reduced power. RFL 9785 RFL Electronics Inc. July 26, 2007...

  • Page 213: Theory Of Operation

    16.4.1 CPU AND MEMORY U5 is the central processing unit (CPU) for the RFL 9785 Checkback Module. Its clock source is a 12- MHz oscillator formed from crystal Y2 and capacitors C26 and C27. A 64K EPROM U6, is used to store all program memory used by the CPU.
  • Page 214 Checkback Module is performed through the SOE Module in the 9785 chassis. The connection between the two modules uses raw logic levels, rather than converting to RS-232 and back again. The RS-232 interface device (U4) is not utilized when the Checkback Module is used in a 9785 chassis.

  • Page 215: Figure 16-6. Block Diagram, Rfl 9785 Checkback Module

    TEST OUT CHKBK TO PASS/FAIL ANNUNCIATORS TO LED ANNUNCIATORS Figure 16-6. Block diagram, RFL 9785 Checkback module RFL 9785 RFL Electronics Inc. July 26, 2007 16-7 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 216: Controls And Indicators

    SW1 through SW9 are accessible with the module installed in the chassis. All other controls are accessible when the module is removed from the chassis or is on a card extender. Table 16-1. Controls and indicators, RFL 9785 Checkback Module front panel Symbol...

  • Page 217: Figure 16-7. Controls And Indicators, Rfl 9785 Checkback Module Front Panel

    TEST FAIL DISPLAY SELECT RESET START TEST Figure 16-7. Controls and indicators, RFL 9785 Checkback module front panel RFL 9785 RFL Electronics Inc. July 26, 2007 16-9 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 218: Table 16-2. Controls And Indicators, Rfl 9785 Checkback Module Circuit Board

    Table 16-2. Controls and indicators, RFL 9785 Checkback Module circuit board Symbol Description, Marking Functional Description Connector header XILINX test connector Connector header For factory use only Jumper Selects normal or test modes Jumper Spare jumper Test point Clock out signal...

  • Page 219: Figure 16-8. Controls And Indicators, Rfl 9785 Checkback Module Circuit Board

    TP 9 TP 1 TP 5 TP 3 TP 4 TP 7 Figure 16-8. Controls and indicators, RFL 9785 Checkback module circuit board RFL 9785 RFL Electronics Inc. July 26, 2007 16-11 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 220: Checkback Testing

    All other Checkback Module functions must be accessed using a terminal or PC connected to the RS-232 connector on the RFL 9785’s rear panel. See Section 14 for more information. The functions described below can also be performed through the rear-panel RS-232 connector.
  • Page 221 NOTE The hard carrier request switches must be pressed and held for five seconds before a hard carrier request is sent. This is done to prevent accidental hard carrier requests. RFL 9785 RFL Electronics Inc. July 26, 2007 16-13 (973) 334-3100 B e c a u s e R F L ™...
  • Page 222 16.6.2 ACCESSING THE CHECKBACK MODULE FROM PC OR TERMINAL You can use the RFL 9785’s RS-232 port to access the Checkback Module from a dumb terminal or a personal computer equipped with a terminal emulator. If your RFL 9785 is equipped with an SOE Module, the Checkback Module can be accessed via an APRIL “W”...

  • Page 223: Figure 16-9. April Commands For Use With Checkback Module

    16.6.2.1 VIEWING APRIL COMMANDS Once you have connected a terminal to the RFL 9785’s RS-232 port (either directly or through an RFL 9660), press the [ENTER] key a few times. The Checkback Module will send the following prompt to your terminal: 9785CB>...

  • Page 224: Figure 16-10. Typical Alarm Display

    “I” for “inactive,” or “A” for “active”. Full descriptions for each alarm are as follows: 010 - Tx Fail The RFL 9785 system being tested by the Checkback Module has failed to transmit a block. 011 - Test Fail The last checkback test failed.
  • Page 225 To change these values, you will have to enter the programming mode. See paragraph 16.6.3 for more information. The programming mode is password- protected, so only authorized persons can change the Checkback Module’s parameter settings. RFL 9785 RFL Electronics Inc. July 26, 2007...

  • Page 226: Figure 16-12. Typical Read Settings Menu

    This display tells you how the Checkback Module is configured, and what software version is being used. Format: 9785CB>F [ENTER] A typical configuration and software version display is shown in Figure 16-13. 9785 Checkback Configuration: Version 9785CB> Figure 16-13. Typical configuration and software version display 16.6.2.6 THE UPDATE MODE...

  • Page 227: Figure 16-14. Typical Update Screen

    You are now in the programming mode, as indicated by the “9785CB-P>” prompt on your screen. You may now use the programming commands to re-program the Checkback Module. For more information on each programming command, refer to the paragraph number listed below next to the command. RFL 9785 RFL Electronics Inc. July 26, 2007 16-19 (973) 334-3100 B e c a u s e R F L ™...

  • Page 228: Figure 16-15. Typical Programming Menu

    Enter the new password again, and then press [ENTER]. The following prompt will appear: password modified The new password is now stored in the Checkback Module’s non-volatile RAM memory. RFL 9785 RFL Electronics Inc. July 26, 2007 16-20 (973) 334-3100 B e c a u s e R F L ™...
  • Page 229 Typical parameter setting lists for the two Checkback Module configuration modes available when installed in an RFL 9785 (Master and Remote) are shown in Figures 16-16 and 16-17. The following parameters appear on each parameter setting list: 999 - System Label This is a user-defined identifier that appears on the second line of the APRIL command list.

  • Page 230: Figure 16-16. Typical Programmed Parameter Settings List - Master Mode

    053 Transmit Fail Inactive 055 Test OK Pulse 9785CB-P> Figure 16-16. Typical programmed parameter settings list – Master Mode RFL 9785 RFL Electronics Inc. July 26, 2007 16-22 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 231: Figure 16-17. Typical Programmed Parameter Settings List - Remote Mode

    This parameter indicates the amount of time until the next automatic checkback test. Once it is initially set, this parameter’s value is calculated, based on the setting of Parameter #29 (Hours Between). Its range is from 0 (run test immediately) to the value of Hours Between. RFL 9785 RFL Electronics Inc. July 26, 2007...
  • Page 232 033 - Chassis Type This parameter must be set according to the type of chassis housing the checkback module being programmed. When housed in an RFL 9785 chassis, this parameter must be set to “85P.” 034 - Test One 035 - Test Two...
  • Page 233 “H” command when you are not in the Programming Mode. EXAMPLE: To change the System Label, type in the following: 9785CB-P> 999 [ENTER] The System Label parameter will be displayed, with information about its setting below it. RFL 9785 RFL Electronics Inc. July 26, 2007 16-25 (973) 334-3100...
  • Page 234 “SV” command described in paragraph 16.6.3.3 to save the changes before invoking the “Q” command; otherwise, your changes will be lost. To return to the 9785> prompt, enter three capitol “X’s” as described in paragraph 13.11. Format: 9785>XXX (do not press [ENTER KEY].
  • Page 235 Enter the new password again, and then press [ENTER]. The following prompt will appear: password modified The new password is now stored in the Checkback Module’s non-volatile RAM memory. RFL 9785 RFL Electronics Inc. July 26, 2007 16-27 (973) 334-3100 B e c a u s e R F L ™...

  • Page 236: Figure 16-18. Typical Test Menu

    065 Key Hard Carrier #2 066 Key Hard Carrier #3 067 Key Hard Carrier #4 9785CB-T> Figure 16-19. Typical test routine list RFL 9785 RFL Electronics Inc. July 26, 2007 16-28 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 237 Module’s RS-232 connector. If you accessed the Checkback Module through an RFL 9660 Digital Switch, type in the deselect code (normally “BYE”) to deselect the port, and then enter the “Q” command to terminate the session. (Refer to the RFL 9660 Instruction Manual for more information.) RFL 9785 RFL Electronics Inc.
  • Page 238 This page intentionally left blank 9785 RFL Electronics Inc. y 26, 2007 16-30 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 239: Figure 16-20. Schematic, Rfl 9785 Checkback (Dwg. No. D-106529-C) Sheet 1 Of 3

    .1uF .1uF .1uF RELAY_RET DS1644 CHASSIS Figure 16-20. Schematic, RFL 9785 Checkback (Dwg. No. D-106529-C) Sheet 1 of 3 RFL 9785 RFL Electronics Inc. July 26, 2007 16-31 (16-32 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 240 10pF P6KE16CA P6KE16CA P6KE16CA P6KE16CA P6KE16CA Figure 16-20. Schematic, RFL 9785 Checkback (Dwg. No. D-106529-C) Sheet 2 of 3 RFL 9785 RFL Electronics Inc. July 26, 2007 16-33 (16-34 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 241 P2-37 P2-38 P3-4 P1.3 NOTE: SCHEMATIC SHEET 3 APPLIES TO PANEL PC BOARD 106527 ONLY. Figure 16-20. Schematic, RFL 9785 Checkback (Dwg. No. D-106529-C) Sheet 3 of 3. 9785 RFL Electronics Inc. y 26, 2007 16-35 (16-36 Blank) (973) 334-3100...

  • Page 242: Section 17. Checkback Communications Module

    74ACT02 MAX202E RFL ELECTRONICS INC., BOONTON, NJ, U.S.A. 9785 CHECKBACK COMMUNICATION MODULE ECB NO. 106648 REV B Figure 17-1. RFL 9785 Checkback Communications Module 17.1 INTRODUCTION The Checkback Communications Module is only used in chassis that have a Checkback Module and no SOE Module.
  • Page 243 This page intentionally left blank 9785 RFL Electronics Inc. Sept ember 1, 2006 17-2 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 244: Figure 17-2. Schematic, Rfl 9785 Checkback Communications Module (Dwg. No. C-106649-A)

    1N914B 1000V 1000V 1000V 47uF .1uF .1uF Figure 17-2. Schematic, RFL 9785 Checkback Communications Module (Dwg. No. C-106649-A) 9785 RFL Electronics Inc. Sept ember 1, 2006 17-3 (17-4 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 245: Introduction

    Figure 18-1. RFL 9785 Power Supply Module 18.1 INTRODUCTION A 50-Watt Power Supply Module (Figure 18-1a) is used to supply regulated dc power to the RFL 9785 System. The power supply provides four regulated dc outputs: +5, +15, -15 and +12 volts. All outputs have overvoltage protection and short circuit protection.

  • Page 246: Power Supply Module

    200Vdc to 300Vdc 18.2.1 SPECIFICATIONS As of the date this manual was published, the following specifications apply to all RFL 9785 power supply modules, except where indicated. Because RFL products undergo constant refinement and improvement, these specifications are subject to change without notice.
  • Page 247 Humidity 95% @ 40 Indicators: DS1 – Normal Green RFL 9785 RFL Electronics Inc. June 18, 2009 18-3 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 248 18.2.2 THEORY OF OPERATION The RFL 9785, 50 Watt power supply is a multiple output, forward, dc to dc converter. The 106535-1 power supply operates from a 38 to 150 Vdc input, and the 106535-2 power supply operates from a 200 to 300 Vdc input.

  • Page 249: Table 18-2. Controls And Indicators, Rfl 9785 Power Supply Module

    CR16, CR17, and CR6. 18.2.3 CONTROLS AND INDICATORS Figure 18-2 shows the location of all controls and indicators on the RFL 9785 Power supply module. These controls and indicators are described in Table 18-2. DS1 is visible with the RFL 9785 Power supply module installed in the chassis.

  • Page 250: Figure 18-2. Controls/Indicators/Component Locator Drawing, For 9785 Power Supply Module (Assy No. 106535-1)

    CR12 Figure 18-2. Controls/indicators/component locator drawing, for 9785 power supply module (Assy No. 106535-1) 9785 RFL Electronics Inc. June 18, 2009 18-6 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 251: Figure 18-3. Schematic, Rfl 9785 Power Supply 48/125 Vdc (Dwg. No. D-106539-K)

    Figure 18-3. Schematic, RFL 9785 Power Supply 48/125 VDC (Dwg. No. D-106539-K) 9785 RFL Electronics Inc. June 18, 2009 18-7 (18-8 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 252: Figure 18-4. Controls And Indicators, And Component Locator Dwg, For Rfl 9785 Power Supply Module

    CR12 CR11 Figure 18-4. Controls and indicators, and component locator dwg, for RFL 9785 power supply module (Assy No. 106535-2) RFL 9785 RFL Electronics Inc. June 18, 2009 18-9 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 253 This page intentionally left blank 9785 RFL Electronics Inc. June 18, 2009 18-10 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 254: Figure 18-5. Schematic, Rfl 9785 Power Supply 250 Vdc (Dwg. No. D-106539-2-G)

    Figure 18-5. Schematic, RFL 9785 Power Supply 250 Vdc (Dwg. No. D-106539-2-G) 9785 RFL Electronics Inc. June 18, 2009 18-11(18-12 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 255: Power Supply I/O Modules

    18.3 POWER SUPPLY I/O MODULES The RFL 9785 Power supply I/O module is located at the rear of the 9785 chassis directly behind the power supply module. It provides input power connections to the RFL 9785 chassis, contains a power supply ON/OFF switch and has an input fuse.

  • Page 256: Figure 18-6. Controls And Indicators, Rfl 9785 Single Power Supply I/O Module

    CONTROLS AND INDICATORS FOR 106455-1 & -2 P.S. I/Os Figure 18-6 shows the location of all controls on the RFL 9785 Single Power supply I/O module. Figure 18-6 shows the location of all controls on the RFL 9785 Single Power supply I/O module.

  • Page 257: Figure 18-7. Schematic, Rfl 9785 Power Supply I/O (Dwg. No. B-106459-B)

    106455-1 48/125 VDC V130LC20B 106455-2 250 VDC V275LC40B Figure 18-7. Schematic, RFL 9785 Power Supply I/O (Dwg. No. B-106459-B) 9785 RFL Electronics Inc. June 18, 2009 18-15 (18-16 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 258: Figure 18-8. Controls And Indicators, Rfl 9785 Dual Power Supply I/O Module

    18.3.2 CONTROLS AND INDICATORS FOR 106455-3 & -4 P.S. I/Os Figure 18-8 shows the location of all controls on the RFL 9785 Dual Power supply I/O module. These controls are described in Table 18-5. Table 18-5. Controls and indicators, RFL 9785 Dual Power Supply I/O module...
  • Page 259 This page intentionally left blank 9785 RFL Electronics Inc. June 18, 2009 18-18 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 260: Figure 18-9. Schematic, Rfl 9785 Power Supply I/O Dual (Dwg. No. B-106459-1-B)

    106455-3 48/125 VDC V130LC20B 106455-4 250 VDC V275LC40B Figure 18-9. Schematic, RFL 9785 Power Supply I/O Dual (Dwg. No. B-106459-1-B) 9785 RFL Electronics Inc. June 18, 2009 18-19 (18-20 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 261: Figure 18-10. Controls And Indicators, Rfl 9780/85 External Amp Power Supply I/O

    18.3.3 CONTROLS AND INDICATORS FOR 106455-5 EXTERNAL AMP P.S. I/Os Figure 18-10 shows the location of all controls on the RFL 9780/85 External Amp Power Supply I/O module. The controls are described in Table 18-6. Table 18-6. Controls and indicators, RFL 9780/85 External Amp Power Supply I/O module...

  • Page 262: Section 2 June

    This page intentionally left blank RFL 9785 RFL Electronics Inc. June 18, 2009 18-22 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 263: Section 19. I/O Modules

    Figure 19-1. Panel views of the 7 types of I/O modules used in the RFL 9785 19.1 INTRODUCTION The RFL 9785 I/O modules serve as an interface for input and output signals between the RFL 9785 and the line coupling equipment. There are seven types of I/O modules that can be used with the RFL 9785.

  • Page 264: Table 19-1. Rfl 9785 I/O Modules Application Information

    Table 19-1. RFL 9785 I/O modules Application Information Assembly I/O Module See the following Number paragraphs for more information 106435-3 SS Input I/O (48/125V) 19.2 106435-4 SS Input I/O (250V) 106435-5 SS Input I/O (5V) 106635-1 SS In/Out I/O (48/125V) 19.3...

  • Page 265: Solid State Input I/O Module

    N.O. and N.C. connections at the terminal block. All signals to and from the Solid-State Input I/O module interface directly with the 9785 Logic Module. The 48/125V version requires that jumpers J4 and J5 be configured for the input voltage requirement.

  • Page 266: Table 19-2. Controls And Indicators, Solid State Input I/O Module

    Jumper Selects 48V or 125V operation (not installed for 250V version) Terminal Provides connections to line coupling equipment. block RFL 9785 RFL Electronics Inc. September 1, 2006 19-4 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 267: Figure 19-3. Controls And Indicators, Solid State Input I/O Modules

    25K 5W 25K 5W a. 106435-3 and 106435-4 b. 106435-5 Figure 19-3. Controls and indicators, Solid State Input I/O modules RFL 9785 RFL Electronics Inc. September 1, 2006 19-5 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 268 This page intentionally left blank RFL 9785 RFL Electronics Inc. September 1, 2006 19-6 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 269: Figure 19-4. Schematic, Rfl 9785 Solid-State Input I/O (Dwg. No. D-106439-3-A)

    INDICATES NET NAMES FOR 9785. DATA NOTE: VOLTAGE SELECTORS J4 & J5 ARE NOT REQUIRED FOR 250V OPERATION. RLY_RET Figure 19-4. Schematic, RFL 9785 Solid-State Input I/O (Dwg. No. D-106439-3-A) RFL 9785 RFL Electronics Inc. September 1, 2006 19-7 (19-8 Blank) (973) 334-3100 B e c a u s e R F L ™...

  • Page 270: Figure 19-5. Schematic, Rfl 9785 Solid-State Logic Level Input I/O (Dwg. No. D-106439-5-B)

    GND1 GND2 TGM-310-NA .47uF 1N4148 CHASSIS ISOL Figure 19-5. Schematic, RFL 9785 Solid-State Logic Level Input I/O (Dwg. No. D-106439-5-B) 9785 RFL Electronics Inc. Sept ember 1, 2006 19-9 (9-10 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 271: Solid State Input/Output I/O Module

    They are placed in the 48V or 125V position. The 250V version does not have these jumpers. The Solid-State Input I/O Module is primarily used for 9785 and 9780 TX/RX applications. It can also be used for future expansion and can be mounted in a spare I/O slot, if available, or in an expansion chassis.

  • Page 272: Figure 19-7. Controls/Indicators, Solid State Input/Output I/O Modules (Assy. No. 106635-1 And -2)

    1N4761A CR11 125V 125V TB-1 1N4761A CR10 CR12 .01uF CR14 SS INPUT I/O 106438-1 REV-B 9780/85 SS OUTPUT I/O 106643 REV-B RFL ELECTRONICS INC., BOONTON, NJ, USA 2000 Q103 Q104 L101 C103 L102 C104 TB-2 L103 C105 L104 U104...

  • Page 273: Figure 19-8. Controls/Indicators, Solid State Logic Level Input/Output I/O Modules (Assy. No. 106635-3 And -4)

    TB-1 RFL ELECTRONICS INC., BOONTON, NJ USA 2000 9780/85 SS LL INPUT I/O 106638 REV-B 9780/85 SS OUTPUT I/O 106643 REV-B RFL ELECTRONICS INC., BOONTON, NJ, USA 2000 Q103 Q104 L101 C103 L102 TB-2 C104 L103 C105 L104 U104 P101...

  • Page 274: Table 19-4. Controls And Indicators, Solid State Input/Output I/O Modules (Assembly No. 106635-1, -2, -3, And -4)

    Provides connections to line coupling equipment P101 Checkback auxiliary chassis connector Provides connection to checkback auxiliary chassis 9785 RFL Electronics Inc. Sept ember 1, 2006 19-14 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 275: Figure 19-9. Schematic, Rfl 9785 Solid State Input/Output I/O (Dwg. No. D-106639-C) Sheet 1 Of 2

    250V IRFP460 1.5KE350CA R2OUT R2IN SP232EEN Figure 19-9. Schematic, RFL 9785 Solid State Input/Output I/O (Dwg. No. D-106639-C) Sheet 1 of 2 RFL 9785 RFL Electronics Inc. September 1, 2006 19-15 (19-16 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 276 250V IRFP460 1.5KE350CA R2OUT R2IN SP232EEN Figure 19-9. Schematic, RFL 9785 Solid State Input/Output I/O (Dwg. No. D-106639-C) Sheet 2 of 2 RFL 9785 RFL Electronics Inc. September 1, 2006 19-17 (19-18 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 277: Figure 19-10. Schematic, Rfl 9785 Ss Logic Level Input/Output I/O (Dwg. No. D-106639-5-C) Sheet 1 Of 2

    GND2 TGM-310-NA .47uF 1N4148 CHASSIS ISOL Figure 19-10. Schematic, RFL 9785 SS Logic Level Input/Output I/O (Dwg. No. D-106639-5-C) Sheet 1 of 2 RFL 9785 RFL Electronics Inc. September 1, 2006 19-19 (19-20 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 278 106635-4 250V IRFP460 1.5KE350CA R2OUT R2IN SP232EEN Figure 19-10. Schematic, RFL 9785 Solid State Logic Level Input/Output I/O (Dwg. No. D-106639-5-C) Sheet 2 of 2 9785 RFL Electronics Inc. Sept ember 1, 2006 19-21 (19-22 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 279: Alarm Relay I/O Module

    User configuration is not required for this I/O module. The Alarm Relay I/O module is used in all standard RFL 9785 applications. It can also be used for future expansion and can be mounted in a spare I/O slot, if available, or in an expansion chassis.
  • Page 280 This page intentionally left blank RFL 9785 RFL Electronics Inc. September 1, 2006 19-24 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 281: Figure 19-12. Schematic, Rfl 9785 Alarm Relay I/O (Dwg. No. D-106469-C)

    Figure 19-12. Schematic, RFL 9785 Alarm Relay I/O (Dwg. No. D-106469-C) 9785 RFL Electronics Inc. Sept ember 1, 2006 19-25 (19-26 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 282: Rf Line I/O Module

    19.5 RF LINE I/O MODULE 9785 RF LINE I/O EXT METER Figure 19-13. RFL Line I/O module, rear panel view 19.5.1 DESCRIPTION The RF Line I/O module (Figure 19-13) has two UHF connectors with spark gaps, additional protection circuits and a selectable line termination impedance (50Ω, 75Ω or none). The top port J5, is for TX signals and the bottom port J7, is for RX signals.

  • Page 283: Figure 19-14. Controls And Indicators, Rfl Line I/O Module

    TX/RX RF LINE I/O 106588 REV- TB-1 PO800 Figure 19-14. Controls and indicators, RFL Line I/O module Table 19-6. Controls and Indicators for RF Line I/O module Component Name/ Function Designator Description Jumper Selects line termination impedance of 50Ω, 75Ω or OUT (greater than 30KΩ)

  • Page 284: Figure 19-15. Schematic, Rfl 9785 Rf Line I/O (Dwg. No. C-106599-B)

    Figure 19-15. Schematic, RFL 9785 RF Line I/O (Dwg. No. C-106599-B) RFL 9785 RFL Electronics Inc. September 1, 2006 19-29 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 285: Current Limit I/O Module

    19.6.1 DESCRIPTION The Current Limit I/O module (Figure 19-16) does not plug into the rear of the RFL 9785 chassis, like the other I/O modules in this section. Instead, it is hard mounted to the left inside wall of the chassis as viewed from the rear.

  • Page 286: Figure 19-17. Schematic Digram, Current Limit I/O Module

    RLY - RLY - Current Limit I/O 48VDC Current Limit I/O 125VDC Figure 19-17. Schematic digram, Current Limit I/O Module RFL 9785 RFL Electronics Inc. September 1, 2006 19-31 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 287: External Power Amp I/O Module

    Figure 19-18. External Power Amp I/O module, rear panel view 19.7.1 DESCRIPTION The external power amp I/O provides an interface when an external high power amplifier is used with the 9785. This module replaces the standard 10W power amplifier for this application. Two panel mounted BNC connectors provide the TX and RX signal interface for the external amplifier and receiver connection.

  • Page 288: Table 19-7. Logic Straps

    JP101 for 50 ohm, 75 ohm or high impedance. E101 is a 90 volt high- energy spark gap and along with R105 and CR101 provide maximum surge protection for the 9785 receiver. In addition, connections are provided for an external power meter.

  • Page 289: Figure 19-19. Controls And Indicators, External Power Amp I/O Module (Assembly No. 106675-1)

    R105 Figure 19-19. Controls and Indicators, External Power Amp I/O module (Assembly No. 106675-1) RFL 9785 RFL Electronics Inc. September 1, 2006 19-34 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 290: Figure 19-20. Schematic, Rfl 9785 External Power Amp I/O (Dwg. No. D-106679-1-B)

    Figure 19-20. Schematic, RFL 9785 External Power Amp I/O (Dwg. No. D-106679-1-B) RFL 9785 RFL Electronics Inc. September 1, 2006 19-35 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 291: Skewed Hybrid I/O

    75 Ohms 19.8.1 SPECIFICATIONS As of the date this manual was published, the following specifications apply to all RFL 9785 Skewed Hybrid Modules, except where indicated. Because all RFL products undergo constant refinement and improvement, these specifications are subject to change without notice.
  • Page 292 For this discussion, refer to the schematic diagram in Figure 19-21. The RFL 9785 Skewed Hybrid Module uses two hybrid transformers to couple signals between a transmitter, a receiver, and a line tuning unit. It provides impedance matching and signal separation, and prevents mutual loading and interference.

  • Page 293: Figure 19-21. Controls And Indicators, Rfl 9785 Skewed Hybrid I/O

    Hybrid Module installed in the chassis. All others are accessible only when the module is removed from the chassis. Figure 19-21. Controls and indicators, RFL 9785 Skewed Hybrid I/O Table 19-9. Controls and Indicators, RFL 9785 Skewed Hybrid I/O. Component...

  • Page 294: Figure 19-22. Schematic, Rfl 9785 Skewed Hybrid (Dwg. No. D-106629-A)

    Figure 19-22. Schematic, RFL 9785 Skewed Hybrid (Dwg. No. D-106629-A) RFL 9785 RFL Electronics Inc. September 1, 2006 19-39 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 295 This page intentionally left blank RFL Electronics Inc. RFL 9785 September 1, 2006 19-40 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 296: Section 20. Chassis Assembly

    RX DETECT CHECKBACK Figure 20-1. RFL 9785 Chassis Assembly, front view with cover removed 20.1 INTRODUCTION The front view of the RFL 9785 chassis is shown in Figure 20-1. It uses the RFL 9785 Tx/Rx Motherboard. RFL 9785 RFL Electronics Inc.
  • Page 297 This page intentionally left blank RFL 9785 RFL Electronics Inc. April 1, 2006 20-2 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 298: Figure 20-2. Schematic, Rfl 9785 Tx/Rx Motherboard (Dwg. No. D-106549-2-A)

    AGND +12V_RELAY 470uF 470uF 470uF -15V -15V Figure 20-2. Schematic, RFL 9785 Tx/Rx Motherboard (Dwg. No. D-106549-2-A) 9785 RFL Electronics Inc. Sept ember 1, 2006 20-3 (20-4 Blank) (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 299: Introduction

    Checkback Tests. The Checkback Alarm Chassis is a 1U high chassis, and houses the RFL 9785 Checkback Alarm Board shown in Figure 21-2. When the Checkback Alarm Chassis is used, a cable supplied with the chassis must be connected between the J1 connector, and a mating connector on the 106635-X I/O module as shown in Section 19.
  • Page 300 This page intentionally left blank 9785 RFL Electronics Inc. Apri l 25, 2005 21-2 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 301: Figure 21-2. Schematic, Rfl 9785 Checkback Alarm (Dwg. No. D-106659-A)

    1. INDUCTORS ARE 10UH UNLESS OTHERWISE SPECIFIED. RLY_RET 2. CAPACITORS ARE .01UF,3KV UNLESS OTHERWISE SPECIFIED. 3. DIODES ARE 1N4003 UNLESS OTHERWISE SPECIFIED. Figure 21-2. Schematic, RFL 9785 Checkback Alarm (Dwg. No. D-106659-A) 9785 RFL Electronics Inc. Apri l 25, 2005...

  • Page 302: March 1, 2013

    (Brown – “COM”) and TP3 (White – “IN”), check for the following level: 2) 10W applications measure 22.36 Vrms (40dbm) TP3/IN White TP1/COM Brown Figure 22-1. Controls and Indicators, 9785 Output Filter Modules (106530-1 to -5 WITHOUT RPM Option) Note: Only for step Error! Reference source not found. of Transmitter...

  • Page 303: Figure 22-3. Controls And Indicators, Rfl 9785 Receiver Downshifter Module (106575) - First

    9785 RX DOWNSHIFTER ECB NO 1999 ELECTRONICS INC., Figure 22-3. Controls and Indicators, RFL 9785 Receiver Downshifter Module (106575) - first 4) Set the attenuator and gain jumpers on the Rx Downshifter module as per Table 4.3. Table 22-1 Input Attenuator Settings Measured...

  • Page 304: Figure 22-4. Controls And Indicators, Rfl 9785 Receiver Downshifter Module (106575) - Second

    1999 ELECTRONICS INC., Figure 22-4. Controls and Indicators, RFL 9785 Receiver Downshifter Module (106575) - second Alternate method: • Connect FSVM to Downshifter module yellow TP13 (+) and TP1 black (GND). • Adjust R69 on the Downshifter for 200 mVrms while transmitting 10 Watts remotely (from the far end).

  • Page 305: Comissioning Test Procedure For 50 And 100 W Systems Using The 9508 Rf Chassis

    SW3 through SW 7** (middle row). The frequency shift up switches can be set via SW8-SW9* while the frequency shift down switches can be set via SW1-SW2*. Table 22-2 (partial) Controls and Indicators, RFL 9780/85 Transmitter Module Component Name/...

  • Page 306: Figure 22-6. Location Of 50W Power Amplifier

    2. Check the Transmitter module output level by placing the module on an Extender Card (RFL P/N 9547-1870). Low power is keyed either with the reserve keying input or by setting the AM Logic Board Switches SW1-3 and SW1-4 to OFF, and placing the toggle switch on the AM Logic Board to the UP position.

  • Page 307: Figure 22-7. Location Of 50W Power Amplifier Circuit Board

    13. Disconnect the line coupling from the 2W I/O connector on the rear of the 9508 RF chassis and connect a 50 ohm dummy load. 14. Reinstall the connector at J5. RFL 9785 RFL Electronics Inc. March 1, 2013 22-6 (973) 334-3100 B e c a u s e R F L ™...

  • Page 308: Figure 22-8. Rear Of 50W Rf Chassis

    4. Adjust the Line Tuning Units for minimum reflected power according to the manufacturer’s recommendations. A Reflected Power reading of <4% or 14dB (forward & reverse) should be achieved for optimum performance. RFL 9785 RFL Electronics Inc. March 1, 2013 22-7 (973) 334-3100 B e c a u s e R F L ™...
  • Page 309 A level of at least 30dB less than transmit level out should be achieved. The lower the level achieved the better. 22.2.2 RECIVER FUNCTIONAL TEST Follow Section 22.3 RFL 9785 RFL Electronics Inc. March 1, 2013 22-8 (973) 334-3100...

  • Page 310: Rfl 9785 Functional Test Procedure

    1) The transmitter frequency was factory-set according to strapping charts on the equipment drawings. If necessary, the center frequency can be set via SW3 through SW 7** (middle row). The 9785 On-Off carrier set does not utilize frequency shifts. Therefore, the frequency shift switches are set to zero (SW1-SW*2 and SW8-SW9*).

  • Page 311: Table 22-4 Rfl 9785 Output Filter Modules, Frequency Range

    2) Check the Transmitter module output level by placing the module on an Extender Card (RFL P/N 9547-1870). a) Connect an oscilloscope to TP4 (+) and TP2 (-). b) Observe 6V p-p undistorted waveform while transmitting 10 watts. If necessary, adjust R23 to attain proper level.

  • Page 312: Figure 22-10. Potentiometer Locations

    Module TP1 (Brown – “COM”) and TP3 (White – “IN”). a) Note the position (A, B, or C) of Jumper J1 on the Output Filter module and remove the jumper. See Step (Section 22. of Simplified Commissioning Procedure for 9785 Output Filter Module diagram.

  • Page 313: Figure 22-11. Location Of "Reserve" Keying Inputs

    10) Adjust Line Tuning Units for minimum reflected power according to the manufacturer’s recommendations. a) A Reflected Power reading of =<4% or 14dB (forward & reverse) should be achieved for optimum performance. RFL 9785 RFL Electronics Inc. March 1, 2013 22-12 (973) 334-3100 B e c a u s e R F L ™...

  • Page 314: Table 22-6 Receive Frequency Select Switches

    9785 RX DOWNSHIFTER ECB NO 1999 ELECTRONICS INC., Attenuation Gain Figure 22-12. Controls and Indicators, RFL 9785 Receiver Downshifter Module (106575) RFL 9785 RFL Electronics Inc. March 1, 2013 22-13 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 315: Table 22-7 Input Attenuator Setting

    Connect a multimeter to TP12 (+) and TP1 (Black – “-“) on the Rx Detector module. d) Adjust R26 to obtain a reading of 0.56Vdc. Note: R26 sets the low level alarm to –15dB down from normal level. RFL 9785 RFL Electronics Inc. March 1, 2013...

  • Page 316: Figure 22-13. Controls And Indicators, Rfl 9785 Receiver Detector Module (106515-X)

    Black (Null) TP12 (Level) Figure 22-13. Controls and Indicators, RFL 9785 Receiver Detector Module (106515-X) This completes the Receiver Functional Test. Visually observe all Front Panel LEDs and test all inputs and outputs to verify full system operation. RFL 9785 RFL Electronics Inc.
  • Page 317 TB7-5 Part of TX Fail TX/Power Fail TX Fail AM Logic Output TB7-6 TX Out Part of 9785 SS I/O 106465 TB4-1 9785 RF Line I/O Start TB4-2 Input Start Input TB4-3 TB9-1 TX Out Stop TB4-4 Stop Input Input...
  • Page 318 1 W Use. External 106435-1 106525 Resistors when Receiver Power is Greater than 1W FSVM Set To: Carrier Freq. Part of 9785 Wht (TP-20) + SS I/O Blk (TP-1) - Measure Level, set J1 and J2 per Table 4-3 in this Manual To/From...
  • Page 319 This page intentionally left blank RFL 9785 RFL Electronics Inc. March 1, 2013 22-18 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

  • Page 320: Section 23. Index

    TB1 ASSIGNMENTS · 9-18 BLOCK DIAGRAM RF MOTHER BOARD · 9-17 9508 LINE BOARD · 9-13 RX CONNECTION BOARD · 9-15 9785 CHASSIS · 2-7 RX FILTER · 9-14 AM LOGIC MODULE · 6-5 TX FILTER · 9-9 CHECKBACK MODULE · 16-7 9508 RF CHASSIS ·...
  • Page 321 EXTENDER CARD · 5-6 PC SERIAL COMMS · 14-2 EXTERNAL AMP I/O MODULE CONNECTIONS RECEIVER LINE INTERFACE/PROVISION FOR 9785 FRONT TO PC · 14-1 EXTERNAL METER · 19-33 9785 REAR TO PC · 14-2 EXTERNAL METER · 4-10 ALARM OUTPUTS · 3-6 EXTERNAL POWER AMP I/O CHASSIS GROUND ·...
  • Page 322 INTERCONNECTED CHASSIS REMOVE AND REPLACE · 5-2 ON SHIPPING RAILS · 3-3 1/O MODULES · 5-4 CIRCUIT BOARD MODULES · 5-2 RFL 9785 RFL Electronics Inc. November 1, 2010 23-3 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 323 EVENTS RECORDED · 13-2 INPUT/OUTPUT · 4-7 SOE/IRIG-B AND IRIG-B I/O MODULE · 2-9 SOE/IRIG-B AND SOE IRIG-B I/OMODULE · 13-1 SOE/IRIG-B I/O MODULE · 13-11 RFL 9785 RFL Electronics Inc. November 1, 2010 23-4 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 324 WARNINGS · iii WARRANTY · ii RFL Electronics Inc. RFL 9785 November 1, 2010 23-5 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 325 This page intentionally left blank RFL 9785 RFL Electronics Inc. November 1, 2010 23-6 (973) 334-3100 B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

Table of Contents

Save PDF
