TVS-2-VX
High Level Hopping Code Scrambler for Vertex Radios
VPU-15-VX
Voice Inversion Scrambler with Kryptic Signaling for Vertex Radios
Manual Revision: 2018-03-23 Rev E
Covers Software Revisions:
TVS-2-VX: 4.96 & Higher
VPU-15-VX: 4.96 & Higher
Covers Hardware Revisions:
E & Higher
This manual & product supports the following Vertex radios:
Portables: VX-350, VX-410, VX-420, VX-450-VX-460, VX-600, VX-800, VX-820, VX-900, VX-920
Mobiles: VX-2100, VX-2200, VX-4000, VX-4100, VX-4200, VX-4500, VX-4600, VX-5500, VX-6000
1
Advertisement
Table of Contents
Related Manuals for Midian TVS-2-VX
Summary of Contents for Midian TVS-2-VX
- Page 1 VPU-15-VX Voice Inversion Scrambler with Kryptic Signaling for Vertex Radios Manual Revision: 2018-03-23 Rev E Covers Software Revisions: TVS-2-VX: 4.96 & Higher VPU-15-VX: 4.96 & Higher Covers Hardware Revisions: E & Higher This manual & product supports the following Vertex radios:...
-
Page 2: Specifications
Spy, and more when using Midian’s Kryptic Signaling format with the CAD-300/DDU-300/TRC-300. For more information on the TVS-2 please read the TVS-2 Technical Reference Manual. Note: The TVS-2-VX by Midian is the same module as the FVP-35 sold by Vertex Standard (Yaesu). VPU-15 Series: The VPU-15 series is an entry level voice inversion scrambler with Midian’s Kryptic Signaling. -
Page 3: Product Programming
PRODUCT PROGRAMMING Midian’s TVS-2-VX and VPU-15-VX are programmed via Midian’s KL-4 programming interface and the MPS software. Go to our website midians.com and under downloads> software download the latest MPS software version. If using the supplied CD-ROM insert it into the PC’s CD-ROM drive. In the browser that will pop-up, install the MPS programming software. -
Page 4: Hardware Installation
HARDWARE INSTALLATION Be certain to follow standard anti-static procedures when handling any of Midian’s products. VX-350: Remove the battery, exposing the option board cover and remove the cover. Plug the scrambler onto the options connector. Replace the option board cover and battery. The scrambler requires this radio have firmware version 1.0 or higher. -
Page 5: Radio Programming
RADIO PROGRAMMING VX-350: For the VX-350 radio programming software CE-86 v1.01 or higher must be used. Read the radio with the option board installed. Select “Common” from the menu and then “Option”. The “Option Unit” should be read as “FVP-35”. Under the “Common”... - Page 6 VX-800: For the VX-800 radio programming software CE-31 v1.20 or higher (DOS) or v1.05 (Windows) must be used. Read the radio with the option board installed. Select “Common” from the menu and then “Miscellaneous”. Set the “Encryption Type” to “Hi Level”. This will also change the “Encryption Device” setting under “Common” > “Option”...
- Page 7 VX-4500 & VX-4600: For the VX-4500 & VX-4600 radio programming software CE-115 v1.01 or higher must be used. Read the radio with the option board installed. Select “Common” from the menu and then “Option”. The “Option Unit” should be read as “FVP-35”. Under the “Common”...
- Page 8 TECHNICAL NOTES Radio Compatibility: Midian has taken the utmost care to ensure the option board integrates into the radio with minimal impact to the features of the radio. However, some features may not be available in the radio when an option board is used.
- Page 9 560p 4.7u AUDIO SWITCH P1:9 P1:1 .0068u P1:39 (SOURCE) U7:4 U7:3 LMV324 LMV324 8.2K .001u DOCUMENT NAME MIDIAN ELECTRONICS, INC. TVS-2-VX/VPU-15-VX 2006-12-01 APPR DATE: DWN BY: SCHEMATIC PROJECT NUMBER SHEET 1 of 1 7321 DESIGN: REV: 2012-11-12 2012 COPYRIGHT ©...
