PowerShot A310 Specifications
CCD
Size
1/2.7 inch
Effective Number of Pixels
Approx. 3.2 MP
Total Number of Pixels
Approx. 3.3 MP
Filter Array
Primary colour filter (Bayer)
IMAGE PROCESSOR
Processor
DiG!C
LENS
Focal Length (optical)
5mm
35mm Film Equivalent
33mm
Maximum Aperture
F3.6
Construction
5 elements in 5 groups (including 1 aspherical
element)
Digital Zoom
Approx. 5.1x
Focusing Method
5-point AiAF / 1-point AF (Fixed in centre)
FOCUSING RANGE
Normal
Macro
CONTROL/BALANCE
Light Metering Method
Evaluation / Centre-weighted averaging / Spot
(Metering frame when Spot : Centre)
Exposure Control Method
Program AE
Exposure Compensation
+/– 2 EV in 1/3-stop increments
White Balance Control
TTL White Balance
White Balance Modes
Auto + Pre-set (Daylight / Cloudy / Tungsten /
Fluorescent / Fluorescent H) + Custom
Shutter Speed
1 – 1/2,000 sec.
Sensitivity
(Equivalent Film Speed)
Auto / ISO 50 /100 / 200 / 400 equivalent
LCD MONITOR/VIEWFINDER
Viewfinder
Inverted Galilean finder
LCD Monitor
1.5 inch low-temperature polycrystalline silicon TFT
colour LCD
FLASH
Flash Modes
Auto / Red-eye reduction on / flash On / flash Off /
Slow-synchro
Flash Range Normal
[at ISO Auto equiv.]
20cm – 2.0m
SELECTABLE SHOOTING MODES
Shooting Modes
Auto / Manual / Stitch Assist / Movie
Photo Effects Mode
Vivid / Neutral / Low sharpening / Sepia /
Black & White
CONTINUOUS SHOOTING
Normal
Approx. 2.2 shots/sec.
[Large/Fine mode, when LCD monitor is turned off]
IMAGE RECORDING FORMAT
Image File Format
Design rule for camera file system, DPOF Version 1.1
compliant
Still Image
JPEG (Exif 2.2 compliant)
Movie
AVI Image data: Motion JPEG
Sound Annotation/Audio Data
WAVE (monaural)
JPEG Compression Levels
Superfine / Fine / Normal
All data is based on Canon's standard testing methods.
Canon reserves the right to change specifications without notice.
*Compatible printer required for Direct Printing. Compatible Windows computer required for direct download.
20cm – infinity
5 – 20cm
RECORDING PIXELS
Still Images
Large
Medium 1
Medium 2
Small
Movie Images
Large (VGA)
Medium (QVGA) 320 x 240
Small (QQVGA)
Frames per second 15
OTHER OPERATIONS
Playback Operations
Single / Index (9 thumbnail images) / Movie Special
Replay – Next frame, Previous frame, Fast forward,
Rewind, First frame and Last frame / Magnify (2x
– 10x) / Histogram
File Operations
DPOF – Print Order/Image transfer, Movie
– unnecessary scenes can be erased. Sound Memos
– max. record/play time is approx. 60 sec.
Direct Printing
Yes
PictBridge
Yes
Print/Share Button
Yes
ID Photo Print
Yes (with compatible Canon Card Photo printers)
Movie Print
Yes (with compatible Canon Card Photo printers)
Camera Settings
Start-up image/ Start-up sound/ Shutter sound/
Operation sound and Self-timer sound (Creation of
on-camera content)
Menu Languages
12 languages English, German, French, Dutch,
Danish, Finnish, Italian, Norwegian, Swedish,
Spanish, Chinese and Japanese)
Self-timer
Approx. 2 sec. or 10 sec. count-down
INTERFACE
Computer I/F
USB
Memory Storage
CompactFlash™ card (Type1)
Supplied Memory
32MB
SUPPORTED OPERATING SYSTEMS
PC
Windows 98 (including SE)/ME/2000/XP
Mac
OS 9.0 – 9.2, OS X (Version 10.1/10.2)
POWER SOURCE
Battery
Size AA Alkaline battery (x2) or Size AA
rechargeable NiMH battery (x2)
Optional Charger/AC Adaptor
CBK4-200/CBK-100 / AC Adaptor Kit ACK800
(contains CA-PS800)
OPERATING ENVIRONMENT
Temperature
0 – 40°C
Humidity
10 – 90%
Dimensions (W x D x H)
110 x 58 x 36.6mm (ex. protruding parts)
Weight
Approx. 175g (ex. batteries and CF card)
INCLUDED ACCESSORIES AND SOFTWARE
– Wrist Strap WS-200, 2 x AA Alkaline Batteries,
USB Interface Cable IFC-400PCU, 32MB CF Card,
Software Starter Guide, Camera User Guide, Quick
Start Guide, Direct Print User Guide
– Canon Digital Camera Solution Disk
– ArcSoft Camera Suite Disk
™ and ®: All company and/or product names are trademarks and/or registered trademarks of their
respective manufacturers in their markets and/or countries.
2048 x 1536
1600 x 1200
1024 x 768
640 x 480
640 x 480
160 x 120
