STM 429J – Scavenger Transmitter Module
STM 429J – Scavenger Transmitter Module
Observe precautions! Electrostatic sensitive devices!
Patent protected:
WO98/36395, DE 100 25 561, DE 101 50 128,
WO 2004/051591, DE 103 01 678 A1, DE 10309334,
WO 04/109236, WO 05/096482, WO 02/095707,
US 6,747,573, US 7,019,241
© 2017 EnOcean | www.enocean.com
STM 429J User Manual | v2.0 | Nov 2017 | Page 1/ 17
Advertisement
Table of Contents
Related Manuals for Dolphin STM 429J
Summary of Contents for Dolphin STM 429J
- Page 1 WO98/36395, DE 100 25 561, DE 101 50 128, WO 2004/051591, DE 103 01 678 A1, DE 10309334, WO 04/109236, WO 05/096482, WO 02/095707, US 6,747,573, US 7,019,241 © 2017 EnOcean | www.enocean.com STM 429J User Manual | v2.0 | Nov 2017 | Page 1/ 17...
-
Page 2: Revision History
Major Changes Initial version Added marking and STM 425J. Editorial corrections. Changed PCB / System Drawings – STM 425J and STM 429J. Added radio certifi- cate. 1.31 Changed helical antenna picture Update of revision with consolidation and small corrections. -
Page 3: Table Of Contents
3.5 PSK Labelling ....................15 3.5.1 Included Information: ................15 3.5.2 QR-Code Specification ................15 AGENCY CERTIFICATIONS ................16 Label Information ..................17 © 2017 EnOcean | www.enocean.com STM 429J User Manual | v2.0 | Nov 2017 | Page 3/ 17... -
Page 4: General Description
In addition a sign of life signal is transmitted every 20-30 minutes. A LRN button and a TX indicator LED are pre-installed on the PCB. On STM 429J they are oriented upwards. When the LRN button is pressed then a special teach-in signal will be sent. -
Page 5: Physical Dimensions
STM 429J – Scavenger Transmitter Module Physical dimensions PCB dimensions 43±0.2 x 16±0.3 x 1±0.1 mm Module height 6 mm Weight 5.2 g PCB drawing STM 429J © 2017 EnOcean | www.enocean.com STM 429J User Manual | v2.0 | Nov 2017 | Page 5/ 17... - Page 6 USER MANUAL STM 429J – Scavenger Transmitter Module System drawing STM 429J © 2017 EnOcean | www.enocean.com STM 429J User Manual | v2.0 | Nov 2017 | Page 6/ 17...
-
Page 7: References
Therefore products have to be taken into operation after 36 months. At least the PAS614L needs to be recharged to 2.1 V. © 2017 EnOcean | www.enocean.com STM 429J User Manual | v2.0 | Nov 2017 | Page 7/ 17... -
Page 8: Functional Description
2.3.1 Switching between modes STM 429J can be switched from normal mode to secure mode and vice versa by long press of the LRN Button (Wake 1). The behaviour of the LRN button is following: ©... -
Page 9: Encrypted Communication - Enhanced Security Mode
Therefore mode change is limited to 50 times. In normal application scenario only very few are required. The factory delivery mode of the STM 429J is standard – not encrypted. This mode is com- mon mode originally available. Secure mode was added in later product upgrades. -
Page 10: Psk Security Teach-In - Optional
3 identical subtelegrams are transmitted within 25 ms. The transmis- sion of a subtelegram lasts approximately 1 ms. The delay between the three transmission bursts is affected at random. © 2017 EnOcean | www.enocean.com STM 429J User Manual | v2.0 | Nov 2017 | Page 10/ 17... -
Page 11: Energy Consumption
These values are calculated, the accuracy is about +/-20%! The performance varies over temperature and may be strongly reduced at extreme temperatures. © 2017 EnOcean | www.enocean.com STM 429J User Manual | v2.0 | Nov 2017 | Page 11/ 17... -
Page 12: Applications Information
USER MANUAL STM 429J – Scavenger Transmitter Module APPLICATIONS INFORMATION Antenna Details Antenna location recommendation 429J without host PCB 429J with host PCB © 2017 EnOcean | www.enocean.com STM 429J User Manual | v2.0 | Nov 2017 | Page 12/ 17... -
Page 13: Transmission Range
In case there is not sufficient light available for operation with solar cell an external 3 V Lithium backup battery can be connected to the module at the soldering pads shown below: © 2017 EnOcean | www.enocean.com STM 429J User Manual | v2.0 | Nov 2017 | Page 13/ 17... -
Page 14: Mounting 429J Into A Housing
Please make sure that the housing covers 0.5 mm at the solar cell edges. Within 0.5 mm off the edge flaking is possible due to the cutting process. © 2017 EnOcean | www.enocean.com STM 429J User Manual | v2.0 | Nov 2017 | Page 14/ 17... -
Page 15: Psk Labelling
Pixel Size: min. 4x4 points per Pixel 600dpi x 600dpi Resolution: 1 Print Point: 0.0423mm x 0.0423mm 1 Pixel: 0.1693mm x 0.1693mm © 2017 EnOcean | www.enocean.com STM 429J User Manual | v2.0 | Nov 2017 | Page 15/ 17... -
Page 16: Agency Certifications
STM 429J – Scavenger Transmitter Module AGENCY CERTIFICATIONS STM 429J have been designed and tested to fulfil the approval requirements for ARIB STD- T108 based on the built-in firmware. When the product is placed on the Japanese market, it must carry the Specified Radio Equipment marking as shown below: ©... -
Page 17: Label Information
3. Date Code “KW/YY”: e.g. 15/13 4. Status „D431-z“: e.g 1 5. DMC 6. ARIB Marking, radius 3mm 7. ARIB Marking with number (003-130160) © 2017 EnOcean | www.enocean.com STM 429J User Manual | v2.0 | Nov 2017 | Page 17/ 17...
