- Page 1 Model 2300JL Installation Guide POWER ACCESS CORPORATION 4 HERSHEY DRIVE, DOCK 4 ANSONIA, CT 06401 800-344-0088 WEBSITE: www.power-access.com EMAIL: salesinfo@power-access.com U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©...
-
Page 2: Standard Parts
WITH SLIP FRICTION CLUTCH ARM, ADJUSTABLE FOREARM AND SHOE, 9 FOOT 115VAC POWER CORD, AND 300MHz RADIO RECEIVER WARNING: DO NOT HANDLE MODEL 2300JL BY POWER CORD DONUT MAGNET (PART NUMBER 2440) SEE PAGE 7, ITEM 4.1.6 AND PAGE 14 (6) #10 1-1/2”... -
Page 3: Optional Accessories
MODEL 4440TK – WALL MOUNTED MODEL 4440D – TWO CHANNEL WIRELESS PROGRAMMABLE 4.5” SQUARE PUSH PLATE SINGLE CHANNEL; MODEL 4440DD – FOUR CHANNEL KEYLESS ENTRY SYSTEM MODEL 4440TKD – TWO CHANNEL U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©... - Page 4 (PAGE 20) TO VERIFY YOU HAVE THE CORRECT UNIT. IF NOT, SEE CHANGING HAND DIRECTION (PAGE 15, 9.1). 1.1.3 THE DOOR THAT THE MODEL 2300JL IS TO BE MOUNTED ABOVE SHOULD BE PLUMB, SQUARE, AND NOT WARPED. THE DOOR SHOULD NOT STICK TO THE JAMB.
- Page 5 A HARD DOOR STOP MUST BE USED TO PREVENT THE DOOR FROM TRAVELING PAST 90 DEGREES WHEN OPENING. A HINGE MOUNTED STANDARD DUTY DOOR STOP IS INCLUDED IN THE MODEL 2300JL PACKAGE. TO INSTALL THIS DOOR STOP REMOVE THE HINGE PIN FROM THE TOP DOOR HINGE. REINSERT THE PIN WITH THE DOOR STOP IN PLACE.
- Page 6 THE SHOE 1-3/4 INCHES BELOW THE BOTTOM OF THE NARROW EDGE OF THE MOTOR MOUNT PLATE AND 15-1/2 INCHES FROM THE HINGE SIDE EDGE OF THE DOOR, SECURE THE SHOE TO THE DOOR WITH 2 SUPPLIED WOOD SCREWS. U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©...
- Page 7 ADJUSTMENT ARM VELCROED SENSOR 1/8” FROM THE CLUTCH ARM HUB, CENTERED ON THE ARM. THIS TRIGGERS THE MOTOR TO SHUT OFF WHEN IN OPERATION. VELCROED SENSOR CLUTCH ARM HUB DONUT MAGNET U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©...
- Page 8 5. ELECTRIC STRIKE INSTALLATION 5.1 STRIKE INSTALLATION THE POWER ACCESS MODEL 2300JL DOOR OPENER IS DESIGNED SO THAT THE DOOR CAN STILL BE MANUALLY OPENED WITHOUT ACTIVATING THE UNIT. THEREFORE, IT IS NECESSARY TO HAVE ANOTHER MECHANICAL FEATURE TO HOLD THE DOOR SHUT WHEN NOT IN OPERATION.
- Page 9 WHAT COMES IN CONTACT WITH THE DOOR LATCH. ADDITIONAL SHIMS PROVIDED WITH THE STRIKE CAN BE USED IF THERE IS STILL TOO MUCH WIGGLE ROOM BETWEEN THE DOOR LATCH AND THE STRIKE LATCHING SURFACE. U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©...
- Page 10 5. ELECTRIC STRIKE INSTALLATION 5.3 CONNECTING ELECTRIC STRIKE TO MODEL 2300JL ONCE INSTALLED AND POSITIONED, USE THE TWO TWISTED 12 FOOT LOW VOLTAGE WIRES TO CONNECT TO THE “SUPPLEMENTAL MODEL 4560S ELECTRIC STRIKE TERMINALS OF THE ELECTRIC STRIKE. CAREFULLY FOLLOW INSTALLATION GUIDE”...
-
Page 11: Programming The Receiver
MOUNT RECEIVER NEED TO MATCH SWITCHES 1-10 ON THE TRANSMITTER. NOTE: OPEN = OFF SOME DIP SWITCHES ARE LABELED ON-OFF AND SOME ARE LABELED OPEN-CLOSE. OPEN = OFF & CLOSED = ON U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©... -
Page 12: Operation
MOTION OF THE LEVER ARM. THIS HELPS TO VERIFY THE MOUNTING LOCATIONS OF THE MOTOR UNIT AND SHOE. 7.1 OPERATION 7.1.1 PLUG THE MODEL 2300JL INTO 115V AC OUTLET. 7.1.2 ACTIVATE THE DOOR OPENER WITH A WIRELESS REMOTE TRANSMITTER. THE DOOR SHOULD OPEN SMOOTHLY TO 90 DEGREES, PAUSE, THEN CLOSE. - Page 13 OBSTACLE IS ENCOUNTERED, THE MOTOR OF A TURN WILL NOT BURN ITSELF OUT. THE CLUTCH TENSION CANNOT BE ADJUSTED. ROTATE CW TO ROTATE CW FOR INCREASE DWELL INCREASED MOTOR TIME ACTIVATION TIME U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©...
- Page 14 THE MOTOR SHUTS OFF WHEN THE DOOR IS 75-80 DEGREES OPEN AND THE DOOR WILL COAST TO A SOFT STOP AT ABOUT 90 DEGREES. CAUTION: A DOOR STOP MUST BE USED TO PREVENT THE DOOR FROM TRAVELING BEYOND 90 DEGREES. U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©...
- Page 15 DOOR MOUNT FOREARM - CALL 800-344-0088 TO ORDER. ONCE THE LEAD WIRES ARE CONFIRMED IN THE CORRECT POSITION, FOLLOW THE PROPER MAIN CIRCUIT BOARD INSTALLATION GUIDE TO MOUNT THE OPENER. U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©...
-
Page 16: Main Circuit Board
AUTO CLOSE L/I – Lock/Inhibit MOCT SB – Single Button Input MAGNETIC SWITCH OL2 DIP SWITCH 2 C – Close Input CTOFF O – Open & Hold COM - Common U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©... - Page 17 THE TIMER WILL BEGIN TIMING WHEN CONTACT IS RELEASED. THIS COULD BE USED WITH A SAFETY MAT APPLICATION WHERE THE ONLY CONCERN IS ON THE CLOSING CYCLE AS IT DOES NOT PREVENT AN OPENING. U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©...
- Page 18 INDICATES LED IS OFF WHEN NO POWER IS GOING TO THE UNIT. INDICATOR POWER ATTACHED LED REMAINS ON UNTIL THE MAGNETIC SWITCH IS ACTIVATED. POSITION INDICATES INDICATOR LOCATION OF DOOR U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©...
-
Page 19: Troubleshooting
TRANSMITTER SWITCHES DO SEE PROGRAMMING THE RECEIVER TRANSMITTER BUTTON IS PRESSED NOT MATCH RECEIVER (PAGE 11) CONTROLLER BATTERY DEAD REPLACE BATTERY IN TRANSMITTER BLOWN FUSE REPLACE FUSE (1 AMP 250V) U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©... -
Page 20: Right Hand Door
UNIT MOUNTED TO JAMB ON PUSH SIDE OF DOOR • PROVIDED WITH EXTENDED FOREARM • MOTOR SHAFT FACING DOWNWARD • POWER CORD EXITS TOWARD HINGE SIDE OF UNIT JAMB MOUNT (2300JL) JAMB MOUNT (2300JR) U.S. Patent 7,418,800 B1 Power Access 2300JL REV 08-05-17 ©...
