T-3 MODBUS
INTERFACE
B6000 BMS Modbus System Control Interface
The T-3 Modbus Interface provides certified compatibility for data sharing and program access
between the Raypak B6000 Boiler Management System and a host of other Building Manage-
ment Systems. The T-3 utilizes a ProSoft 1500 series communications interface to facilitate low
level translation between the proprietary Raypak RS-485 protocol and other Manufacturers Modbus
protocols. The Raypak B6000 and Modbus systems fuse to provide a level of boiler control and
monitoring capability unparalleled by any other system at any price.
Features
• Certified Modbus Compatibility
• Total B6000 BMS Program Access
• Boiler Activation/Shutdown
• Outdoor Reset Adjustment
• Setback Control
• Lead/Lag Scheduling
• Boiler Fault Annunciation
• Complete Boiler Diagnostics
• Remote Troubleshooting
• All Attribute Read/Write Support
• Diagnostic LED Indicators
• Data Integrity Assurance
• Data Transfer Rate: 9600 Baud
• Single Source Responsibility
DOOR OPEN
DOOR CLOSED
Raypak, Inc. reserves the right to make product changes or improvements at any time without notification.
Catalog No. 5100.16
Effective: 9-01-98
Replaces: NEW
