2014 Quick Reference Guide

Advertisement

Table of Contents
loading

Related Manuals for Subaru Legacy 2014

Summary of Contents for Subaru Legacy 2014

  • Page 1 2014 Quick Reference Guide...

  • Page 2: D R I V E R's A R E A

    D R I V E R’S A R E A 5-speed Automatic Transmission vehicle Tilt/telescopic steering wheel Hazard warning flasher Pull the tilt/telescopic lock lever down. Move To turn on, push button. the steering wheel to the desired level. Pull the Use in emergency conditions.
  • Page 3 LEGACY Headlights/turn signal Headlights To turn on, rotate knob to: : Instrument panel illumination, parking lights, front side marker lights, rear side marker lights, tail lights and license plate lights are on. : Instrument panel illumination, headlights, parking lights, front side marker lights, rear side marker lights, tail lights and license plate lights are on.

  • Page 4: Illumination Brightness Control

    Remote control mirror switch Illumination brightness control To select mirror, turn the knob to L or R. To adjust brightness of the clock display, audio, air To adjust the mirror, move the knob in the conditioner, multi function display, and meter/gauge. direction you want to move the mirror.
  • Page 5 LEGACY Manual transmission 6-speed (if equipped) To move the shift lever to the R position, raise the slider and hold it in that position. Automatic transmission/continuously variable transmission (CVT) (if equipped) P = Park To shift the select lever from the P to any other position, you should depress the brake pedal fully.

  • Page 6: Cruise Control

    Electronic parking brake switch/Hill Holder switch To apply the parking brake, press the parking brake switch firmly. To release, pull the parking brake switch toward you while the ignition switch is in the ON position and the brake pedal (all models) and the clutch pedal (MT models) are depressed.
  • Page 7 LEGACY DOOR LOCKS AND WINDOWS Remote keyless entry To unlock driver’s door, briefly press To unlock all doors and rear gate: Press once, an electronic chirp will sound twice and the hazard warning flashers will flash twice. Press again a second time within 5 seconds. To open the trunk lid, press and hold To lock all doors and rear gate, briefly press Power windows...
  • Page 8 Trunk lid opener To open the trunk lid from the inside, press and hold the trunk lid opener switch for more than 1 second. To lock and unlock the trunk lid opener switch, open the glove box and press the trunk lid opener lock button. Trunk lid opener lock button Fuel filler lid release lever To open the fuel filler lid, pull the lid release lever up.
  • Page 9 LEGACY S E AT, S E AT B E LT Front seat adjustment Power seat (if equipped) Forward and backward adjustment: Move switch forward or backward. Seat cushion angle (driver’s seat only): Pull up or push down the front end of switch. Seatback reclining: Move switch forward or backward.
  • Page 10 Head restraint To raise head restraint, pull it up. To lower, push it down while pressing release button. Seat heater To turn on the seat heater, press the LOW or HIGH position on the switch, as desired, depending on the temperature. Selecting the HIGH position will cause the seat to heat up quicker.
  • Page 11 LEGACY Lower anchorages Lower anchorages (bars) are used for installing child restraint system. See the Owner’s Manual Chapter 1 for details. Top tether anchorages Top tether anchorages are provided for installing child restraint system with top tether. They are located on rear shelf behind the rear seat head restraint. TOP TETHER See the Owner’s Manual Chapter 1 for details.
  • Page 12 M E T E R S/I N D I C ATO R S Speedometer Tachometer Fuel gauge ECO gauge The ECO gauge shows the difference between Temperature gauge the average rate of fuel consumption and the current rate of fuel consumption. Select lever/gear position indicator The position of the shift lever (MT models) or select lever (AT and CVT models) is shown.
  • Page 13 LEGACY MAIN WARNING AND INDICATOR LIGHTS Refer to the Owner’s Manual for countermeasures when each warning light comes on. If necessary, consult your authorized Subaru dealer. Seatbelt warning Front passenger’s seatbelt warning Remind the driver to fasten seatbelt. Remind the front passenger to fasten seatbelt.

  • Page 14: Climate Control

    C L I M AT E C O N T RO L Automatic climate control (if equipped) AUTO button FULL AUTO mode operation: When the AUTO button is pressed, the indicator light FULL AUTO on the display illuminates. In this state, outlet air temperature, fan speed, air flow distribution, air-inlet control, and air conditioner compressor operation are automatically controlled.

  • Page 15: Maintenance

    LEGACY Manual climate control (if equipped) Fan speed control dial Temperature control dial Turn dial to turn on and to select the preferred Turn the temperature control dial over a range from fan speeds. the blue side (cool) to red side (warm) to regulate the temperature of air flow from the air outlets.
  • Page 16 Colours shown may vary due to reproduction variations in the printing process, and some vehicle parts cannot be shown in certain photographs. Subaru Canada, Inc. reserves the right to discontinue or make changes at any time, without notice or incurring obligations, to colours, materials, equipment, accessories, features, specifications and models, or to change their prices.
