MANHATTAN LCD
HD8400
X)
Quick Guide
Contents
Page x ---------- Contents
Page 1 ---------- Features & Specifications
Page 2 ---------- Monitor Schematic
Page 3 ---------- Remote Control
Page 4 ---------- Quick Set Up
Page 5-9 ------- On-Screen Display Functions
Page 10 ---------Input Connections
Page 12 ---------Warranty
© 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved
Section: HD8400 - Table of Contents
Advertisement
Table of Contents
Related Manuals for Manhattan HD8400
Summary of Contents for Manhattan HD8400
- Page 1 Page 2 ---------- Monitor Schematic Page 3 ---------- Remote Control Page 4 ---------- Quick Set Up Page 5-9 ------- On-Screen Display Functions Page 10 ---------Input Connections Page 12 ---------Warranty © 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved...
-
Page 2: Features & Specifications
Power – 12-24v DC – Built Power Regulator – 4 Pin XLR Power <40 Watts Tekkeon MP3450I Rechargeable Battery – 2 Hour Run Time (Optional) Battery Plates – Sony, Panasonic, Cannon (optional) © 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved... -
Page 3: Monitor Schematic
1/4-20 Mounting Y (G) Pb (B) Pr (R) HD - SDI HD - SDI Ventilation Slits 12V DC 12V DC DVI / HDMI S-VIDEO VIDEO Bottom (connectors) © 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved... -
Page 4: Remote Control
MANHATTAN LCD Quick Guide Section:Remote Control HD8400 The remote control unit is compatible with all Manhattan LCD 1000 series monitors. It is provided with universal control buttons that enable the control of OSD functions. Specifications IR LED Power on/off Operating voltage- DC 3V... -
Page 5: Quick Set Up
When session is complete, turn power OFF, disconnect power cable and then all video input cables. Energy Saver: Use Auto Power OFF and OSD Timeout settings to conserve energy and increase screen longevity (See detailed OSD Functions ) © 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved... -
Page 6: Picture Mode
- 1 : 1 : Display the exact image resolution on the screen without image expansion. - Custom Sizing #### - Overscan - Normal - Custom > H Size V Size H Pan V Pan CONTINUED>>> © 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved... - Page 7 4 possible input groups that can be mixed for PIP : a) VGA/HD-component b) DVI c) HD-SDI d) Composite/S-Video/SD-component It can not allow to select signal source from the same group for PIP. CONTINUED>>> © 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved...
-
Page 8: Quick Guide
Fine tune the data sampling position (adjust image quality) Auto Source Seek : - Auto : : OFF / ON ON – Auto source select always enable OFF – Disable auto source select functionComposite 1 © 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved... - Page 9 : Pan the image horizontally Vertical pan : : Pan the image vertically Default : Restore to default values Note : Freeze state will be cleared when you using zoom function. © 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved...
- Page 10 Reset to Factory Defaults * : DISPLAY IN VIDEO MODE ONLY # : DISPLAY IN ARGB MODE ONLY ## : DISPLAY IN ARGB / HD COMPONENT MODE ONLY © 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved...
-
Page 11: Input Connections
Video sources such as VCR/ from computer or camera via Wall adapter or 12V DC Battery VTR or SD Camera. HDMI to DVI adpater cable or comparable adapter/cable combinations. © 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved... -
Page 12: Warranty
RMA’s may be requested directly from the manufacturer or authorized distributors. Manhattan LCD reserves the right to refuse to repair or replace any monitor that it deems is in need of repair due to customer negligence or damage was caused by use other than the normal intended purpose of the product.
