- Page 1 SM003423 ~ C00290011 HOTPOINT LUCE WINE CELLARS Models Comm. Covered Code WL24HP 76770 WL36HP 76769 Energy Band A Models WL24AHP 78417 WL36AHP 78416 Service Information Indesit Company UK Ltd © 2012 Reg. Office: Peterborough PE2 9JB Registered in London: 106725...
-
Page 2: Table Of Contents
Indesit Company Health & Safety Information Applicable to Servicing Refrigeration Products Containing R134a General 1. This manual is not intended as a comprehensive repair/maintenance guide to the appliance. 2. It should only be used by suitably qualified persons having technical competence, applicable product knowledge, suitable tools and test equipment. -
Page 3: Wl24Hp
Company SPECIFICATIONS (A Band Models Overleaf) Introduction Dates WL24HP - December 2011 WL36HP - August 2012 Commercial Code WL24HP - 76770 WL36HP - 76769 Colour Grey / Stainless Grey / Stainless Dimensions See the page 5 Country of Origin Italy... -
Page 4: Wl36Ahp
Indesit Company SPECIFICATIONS - A BAND MODELS Introduction Dates WL24AHP - October 2012 WL36AHP - October 2012 Commercial Code WL24AHP - 78417 WL36AHP - 78416 Colour Grey / Stainless Grey / Stainless Dimensions See the following page Country of Origin Italy Italy Weight (kg) -
Page 5: Dimensional Diagrams
Indesit Company DIMENSIONAL DIAGRAMS WL24HP Dimensions of the Dimensions compartment of the cellar Furniture side area Ventilation space: at least 50 mm WL36HP Dimensions min. Dimensions of the cellar of the compartment Furniture 560 min. Ventilation space: side area at least 50 mm Cabinetry Aperture Required WL24 WL36... -
Page 6: Product Description
Indesit Company PRODUCT DESCRIPTION CONTROL DOOR PANEL BOTTLE AGEING SHELVES DATA PLATE COMPARTMENT CONTROL PANEL ON LIGHT DISPLAY REDUCE INCREASE TEMPERATURE TEMPERATURE POWER CURRENT CONNECTION ON/OFF LIGHT TEMPERATURE LIGHT BUTTON Service Manual UK English 6 of 15... -
Page 7: Introduction & Use
Indesit Company INTRODUCTION & USE These products are not specifically for cooling wine. They are as the name implies; Wine Cellars, designed for storing wine in optimal conditions. The temperature is factory set at 15°C, although this is adjustable and can be set according to individual preferences. -
Page 8: Ideal Wine Temperatures
Indesit Company TABLE OF IDEAL WINE TEMPERATURES FOR SERVING This table indicates the approximate temperatures at which wine should be served. Should one of your wines need to be served at a temperature that is greater than the temperature inside your wine cellar, we suggest that you leave it out for the time that is necessary before you serve it. -
Page 9: Stocking The Wine Bottles
Indesit Company STOCKING THE WINE BOTTLES - WL36 illustrated below For WL26 refer to user handbook Standard 36-Bottle Stock Some Stocking Configurations The 36-bottle stock (for standard, mixed and Renana bottles) is recommended for wines PRESENTATION that need to be visible and easily removed. 44 Bottles (100% lying down) STANDARD... -
Page 10: Dismantling Procedure
Indesit Company DISMANTLING PROCEDURE Important Notes for Guidance: Before commencing any work refer to the Safety Notes at the beginning of this manual. A. Remove Wine Cellar from Cabinetry Open the door. Remove 3 screws located in the grey trim at each side, and then close the door. Pull the appliance from the cabinetry a little way, and tape the door closed. - Page 11 Indesit Company G. 12 Volt internal Fan Motor Remove the 2 screws from the evaporator cover plate. Disconnect the fan motor (small male female connector close to the evaporator). Insert the chisel knife between the cover plate and the edge of the fan motor air grille moulding to ease away from the plate and release the fan motor.
-
Page 12: Wiring Diagrams
Indesit Company WIRING DIAGRAM Thermistor 12 volt Fan Motor Black Orange Grey Yellow Relay Relay Switching Relay Switching Control Ballast Board Choke Transformer Starter Blue Brown Mauve White Blue White Not Used Terminal 5407269wd Block WE26 External Compressor Motor Service Manual UK English 12 of 15... - Page 13 Indesit Company WIRING CONNECTION GUIDE Fluorescent light White Control Panel (viewed from rear) 10 Way Ribbon cable to Thermistor the display module. Note: the Black cable in the ribbon must be on the Right Hand Side (at each end) when viewed from the rear of the appliance.
-
Page 14: Wiring Connection Tables
Indesit Company WIRING CONNECTION TABLES PCB Connections Marked Colour Connected to Position Line In Mauve Main Term Block L Line In Blue Main Term Block N 6 Way block Brown Main Term Block L 6 Way block Main Term Block C Unmarked 6 Way block White External Fan Motor... - Page 15 Indesit Company Service Manual UK English 15 of 15...
