ASSEMBLY AND CARE INSTRUCTIONS
VERSION: 8920100 (Revised 05/15)
SA Sport – Canada and International
135 Forestview Road, PO Box 40
Orillia, Ontario, Canada L3V 6H9
Toll-Free:
Telephone: (705) 325-2274
Fax:
info@spiethanderson.com
JUST FOR KIDS
SALES AND SERVICE
sasportonline.com
(800) 563-6479
(705) 325-1485
355
SA Sport – USA
104 Nu Energy Drive, Suite 1
Aledo, Texas, USA 76008
Toll-Free:
Telephone: (817) 536-3366
Fax:
sales@sasportusa.com
(800) 331-8068
(817) 536-3006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 355 and is the answer not in the manual?

Questions and answers

Related Manuals for SA Sport 355

Summary of Contents for SA Sport 355

  • Page 1 ASSEMBLY AND CARE INSTRUCTIONS JUST FOR KIDS VERSION: 8920100 (Revised 05/15) SALES AND SERVICE sasportonline.com SA Sport – Canada and International SA Sport – USA 135 Forestview Road, PO Box 40 104 Nu Energy Drive, Suite 1 Orillia, Ontario, Canada L3V 6H9...
  • Page 2 At no time should children or other unqualified persons undertake the assembly, set-up, installation or adjustment of this equipment. THE SA SPORT JUST FOR KIDS LINE IS DESIGNED AND INTENDED FOR USE BY BEGINNER LEVEL GYMNASTS UNDER A WEIGHT OF 150 LBS (68 KG).

  • Page 3: Table Of Contents

    1.8. 355-60 - Just for Kids Low Rail Assembly ................6 1.9. 355-105 Just for Kids Ring Frame Adjusting Tubes Assembly ..........6 Set-Up, Assembly and Adjustments ..................8 2.1. Pre-Assembly Instruction for Just for Kids Uprights (#355-05) ..........9 2.2.

  • Page 4: Apparatus Description

    Assembly Instructions 1. Apparatus description 1.1. 360 - Just For Kids Parallel Bars The SA Sport 360 Just for Kids Parallel Bars includes the following items: • Just for Kids Base Assembly (#355-01): 1 Pair o Complete with Tie-Down Hardware •...

  • Page 5: 363 - Just For Kids Ring Frame

    1.6. 355-CS - Just for Kids Complete System The SA Sport 355-CS Just for Kids Complete System includes 1 each of the Apparatus Assemblies 360, 361, 362 and 363 as well as a 4 Station Circuit Base and a 4-piece set of Multi color Circuit Mats.

  • Page 6: 355-55 - Just For Kids High Rail Assembly

    355 JUST FOR KIDS Assembly Instructions 1.7. 355-55 - Just for Kids High Rail Assembly The SA Sport 355-55 Just for Kids High Rail Assembly includes the following items: • Just for Kids High Adjusting Tube (#355-57): 2 Pieces • Just for Kids Veneered Fiberglass Rail (#355-65): 1 Piece o Complete with mounting hardware 1.8.
  • Page 7 355 JUST FOR KIDS Assembly Instructions Page 7 of 25...

  • Page 8: Set-Up, Assembly And Adjustments

    Depending on the layout you chose for your Just for Kids Apparatus, please refer to the following sections: 2.3 Just for Kids Individual Base Tie-Down - 355-01 Page 11 2.4 Just for Kids Complete System Base Tie-Down - 355-CS Page 13 2.5 Just for Kids In-Line Layout Base Tie-Down Page 16 Once bases are set-up properly, please refer to next assembly steps starting on Page 18.

  • Page 9: Pre-Assembly Instruction For Just For Kids Uprights (#355-05)

    355 JUST FOR KIDS Assembly Instructions 2.1. Pre-Assembly Instruction for Just for Kids Uprights (#355-05) This step must be done first, before any further Assembly of your Apparatus! Ensure the screws are tightened securely! Locate the two Just for Kids Uprights (#355-352), one UPRIGHT Just for Kids Cross Tube (#355-360) and the 7/32”...

  • Page 10: Installing Concrete Anchors

    355 JUST FOR KIDS Assembly Instructions Installing Concrete Anchors 2.2. To determine anchor locations, please refer to the section for the specific equipment to be anchored. Anchors & Hardware are supplied with the Just for Kids Base Assembly (#355-01). Tools Required (customer supplied): •...

  • Page 11: Just For Kids Individual Base Tie-Down - 355-01

    2. Install 1 or 2 Just for Kids Upright Assemblies (#355-05 previously assembled) between the 2 (#355-01) Bases (Fig. 4). Tighten the clamp (Fig. 4A) on the lower section of each side of the Just for Kids Upright Assemblies (#355-05) by turning CLOCKWISE. This will assist in maintaining the correct width and alignment.
  • Page 12 Ensure that Bases are parallel to each other and install 1 or 2 Just for Kids Upright (#355-05) on to the 2 Bases (#355-01). This will assist in maintaining the correct width between the bases as well as maintaining them parallel to each other.

  • Page 13: Just For Kids Complete System Base Tie-Down - 355-Cs

    2.4. Just for Kids Complete System Base Tie-Down - 355-CS This part requires (1) Just for Kids 4-Station Circuit Base (#355-154) & (4) Just for Kids Single Bases (#355-01). Since the Just for Kids 4-Station Circuit comes with (1) Just for Kids 4-Station Circuit Base &...
  • Page 14 355 JUST FOR KIDS Assembly Instructions Fig. 6A Fig. 6 Page 14 of 25...
  • Page 15 8. Once the Just for Kids 4-Station Circuit Base is drilled, move on to each of the Just for Kids Single Base (#355-01) and drill the remaining 8 holes for the floor anchors using the anchor holes in the 4 Just for Kids Single Bases as guides (Fig. 6). Drill the holes 5/8” diameter to a depth equal to the length (2 inches) of the floor anchor +1/8”, as per Page 9 Anchor Installation.

  • Page 16: Just For Kids In-Line Layout Base Tie-Down

    This procedure will require at least two (2) qualified persons. Children or other unqualified personnel should at no time undertake any part of this procedure. 1. Position the apparatus in the desired location. Align all Just for Kids Bases (#355-01) as shown in Fig. 8 below.
  • Page 17 Ensure that Bases are parallel to each other and install 1 or 2 Just for Kids Upright (#355-05) on each pair of Bases (#355-01). This will assist in maintaining the correct width between the bases as well as maintaining them parallel to each other.

  • Page 18: Just For Kids Rail To Adjusting Tube Assembly

    355 JUST FOR KIDS Assembly Instructions 2.6. Just for Kids Rail to Adjusting Tube Assembly This procedure will require at least two (2) qualified persons. Children other unqualified personnel should at no time undertake any part of this procedure. The length of the Just for Kids Adjusting Tube you are working with will vary depending on the Just for Kids product that you are assembling.

  • Page 19: Just For Kids Rail & Adjusting Tube Assembly To Uprights Assembly

    355 JUST FOR KIDS Assembly Instructions 2.7. Just for Kids Rail & Adjusting Tube Assembly to Uprights Assembly This procedure will require at least two (2) qualified persons. Children or other unqualified personnel should at no time undertake any part of this procedure.
  • Page 20 355 JUST FOR KIDS Assembly Instructions 5. Prepare to slide the Rail & Adjusting Tube Assembly into the Upright Assembly (See Fig. 12). Lower the Rail & Adjusting Tube Assembly into the Uprights. Pull outward on the Snap Lock Device. Once the Adjusting...

  • Page 21: Just For Kids Ring Frame To Uprights Assembly

    Children or other unqualified personnel should at no time undertake any part of this procedure. 1. Locate one (1) Just for Kids Upright Assembly (#355- 05). See Page 9, Pre-assembly of Just for Kids Uprights, if this step was missed.

  • Page 22: Changing Just For Kids Apparatus Configurations

    Fig. 14 2.9. Changing Just for Kids Apparatus Configurations Simply by changing the combination of Just for Kids Uprights placed between the SA Sport Just for Kids Bases, you can create numerous Apparatus Configurations (See Chart on page 7). This procedure will require at least two (2) qualified persons. Children or other unqualified personnel should at no time undertake any part of this procedure.

  • Page 23: Horizontal Adjustment Of Uprights

    6. With the Snap Locking Devices fully engaged, tighten the Spin Lock Portion securely, by turning the round disc clockwise. 2.11. Horizontal Adjustment of Uprights SA Sport recommends that two (2) qualified persons perform this adjustment. At no time should children or other...

  • Page 24: Spare Parts

    355 JUST FOR KIDS Assembly Instructions 3. Spare parts Description Part Number 1 Piece – Just for Kids Spin-Snap Lock P355-254A (Combination of Locking Handle and Snap Lock) 1 Piece – Just for Kids Clamp P355-248A 1 Piece - Just for Kids Veneered Fiberglass Rail 355-65 1 Piece –...

  • Page 25: Safety

    355 JUST FOR KIDS Assembly Instructions 4. SAFETY WARNING Any activity involving motion or height creates the possibility of serious injury including permanent paralysis and even death from landing or falling on the neck, head or other parts of the body.
