Diagnostic Mode

The keypad has a manual diagnostic mode built-in to verify proper keypad
function and troubleshooting key issues. This mode will not allow access to
any data or admin function. It can only be used to identify the firmware level
and to test button recognition.
To enter the diagnostic function:
1.
From standby mode, press LOCK + 1, release, then press and continue
to hold the 0 button as the RED
all three LEDs illuminate solidly, release the 0 button.
2.
The BLUE LED will blink a number of times to represent the number of
both the major and minor revisions. The decimal point will be represented
by a single RED LED blink. Upon completion, the
solidly. (Example: VERSION 4.1 would be indicated by four
blinks, one RED LED blink, one
then revert to the BLUE LED glowing solidly.)
3.
To check the keypad's button functionality, press each button and
the number of the button pressed will be expressed by the
blinking. (Example: 1 Button= 1 blink, 2 Button = 2 blinks, 3 Button = 3
blinks...0 Button = 10 blinks, Unlock Button = 11 blinks, Lock Button
= 12 blinks.)
4.
To exit the Diagnostic Mode, wait for the 20 second timeout or hold the
Lock Button for ~7 seconds to return the key to its normal operation.
Self-Diagnostics:
During the initial power up, after the key has been plugged into a USB
port, the key will perform self-diagnostics on the encryption algorithm and
critical hardware components. If the
per second for 15 seconds, returns to standby and will not unlock, unplug
the key from USB port and try again. If the
the manner mentioned above and won't unlock upon USB re-insertion, a
critical component has failed and the key can no longer function.
If the key blinks a triple-RED LED pattern that is repeated every two
seconds when unlocked, a failure has occurred that will not immediately
stop the device from working nor affect the security of the device, but
should be considered as a warning that the device needs to be replaced in
the near future. Additionally, Admin features may be limited in this mode.
If either condition should appear, remove the key from the USB port and
allow the key to go to sleep, and try to unlock the key again. The event of
either diagnostic failure will be very rare, but if the key cannot recover, it
must be replaced.
and BLUE LEDs blink alternately. Once
BLUE LED will glow
BLUE
BLUE LED blink, and one RED LED blink,
RED
RED LED blinks at a rate of one blink
RED LED continues to blink in

Lock-Override Mode

Certain users may encounter a case where they need the key to remain
unlocked during a reboot, passing the key through a virtual machine or other
similar situation which, under normal circumstances, would cause the key to
lock. To help facilitate this use case, "Lock-Override Mode" will allow the key
to remain unlocked through USB port re-enumeration and will not lock again
until USB power is interrupted.
NOTE: When in this mode, the key is vulnerable to being moved from one
computer and connected to another computer provided USB power is
uninterrupted. Due to this vulnerability, we strongly recommend this mode be
used ONLY in circumstances where the key can be physically secured (as in
a locked Server Room) or in a place where it can be visually monitored while
in this mode. Use of a powered hub or a Y-cable increases this security risk.
LED
Always return the key to the default Lock-Override Mode OFF when
returning to normal service.
To set the "Lock-Override" to On:
LED
1.
Enter the Admin Mode (Press and hold UNLOCK + 0 for five seconds
until the
UNLOCK button. The
2.
Press and hold 7 + 1 for three seconds. The
times, then the
3.
When the key is unlocked and attached to a USB port in "Lock-Override
Mode", the
that "Lock-Override" mode is active.
Note: If "Unattended Auto-Lock" mode has been turned on, "Lock-Override"
will not override it; the key will lock itself upon reaching the selected amount
of inactivity. If you need the key to stay unlocked, Enter the Unattended
Auto-Lock Feature and set the lock timer to "0" (0 = OFF) See Page 10.
To turn Lock-Override Mode off and return to normal operation:
4.
Enter the Admin Mode (Press and hold UNLOCK + 0 for five seconds
until the
UNLOCK button. The
5.
Press and hold 7 + 0 for three seconds. The
times then the
6.
To verify, unlock the key in User mode and check that the
no longer blinking.
18
RED LED blinks, then enter the Admin code and press the
BLUE LED will glow solidly.)
BLUE LED will glow solidly.
BLUE LED will blink once every three seconds to alert you
RED
LED blinks. Then enter the Admin code and press the
BLUE
LED will glow solidly.)
BLUE LED will glow solidly.
GREEN LED will blink three
GREEN LED will blink three
BLUE LED is
