  • Page 1 RANGE WITH OVEN ELECTRICAL COOKER 600 SERİ / 600 SERIES : PERFECT 700 SERİ / 700 SERIES : 900 SERİ / 900 SERIES : USER MANUAL KULLANMA KLAVUZU 700 SERİ / 700 SERIES 900 SERİ / 900 SERIES...
  • Page 2: Technical Specifications

    TECHNICAL SPECIFICATIONS...
  • Page 3 600 SERIES ELC COOKER 643 SERIES ELC COOKER 110,16 389,78 663 SERIES ELC COOKER 110,16 389,78 900 SERIES ELC COOKER 945 SERIES ELC COOKER 61,33 106,5 72,5 72,5 71,53 690,46 985 SERIES ELC COOKER 61,33 106,5 72,5 72,5 71,53 690,46...
  • Page 4 700 SERIES ELC COOKER 743 SERIES ELC COOKER 61,33 20,5 20,5 783 SERIES ELC COOKER 61,33 20,5 20,5 745 SERIES ELC COOKER 61,33 106,5 72,5 72,5 69,8 500,4 785 SERIES ELC COOKER 61,33 106,5 72,5 72,5 69,8 500,4...
  • Page 5 700 SERIES RANGE WITH OVEN 785 SERIES RANGE WITH OVEN 61,33 461,2 140,84 72,5 72,5 69,8 500,4 900 SERIES RANGE WITH OVEN 985 SERIES RANGE WITH OVEN 61,33 651,38 140,84 72,5 72,5 71,53 690,46...
  • Page 6 PRESENTATION Dear User, We thank you for having preferred our device and having relied on our company. Our devices are being used in industry kitchens in 75 countries together with you. Our device has been produced in accordance with international standards. We strongly remind you that you read the instruction book, have your user read it to get the highest e ,ciency from the device matching your expectations and to use it for a long term.
  • Page 7 * Tereddüt ettiğiniz ve anlayamadığınız hususlar için size en yakın yetkili servisten telefonla bilgi isteyiniz. * Montaj için çağrılan servis elemanının bekletilmesi halinde masra ar ve her saat için bekleme ücretinin tarafınıza fatura edileceğini hatırlatırız. KAYALAR ÇELİK SAN. TİC. A.Ş...
  • Page 8 SAFETY RELATED DETAILS ☞ The device has by all means be operated under ventilation hood. ☞ In the area, where the device operates, no solid or liquid combustible materials (garments, alcohol and derivatives, petroleum chemicals, wood and plastic materials, curtains etc.) should be given place.
  • Page 9 GÜVENLİK İLE İLGİLİ DETAYLAR Cihaz, kesinlikle davlumbaz altında çalıştırılmalıdır. ☞ Cihazın çalıştığı alanda yanabilen her türlü katı sıvı malzemeler ☞ (Elbise, alkol ve türevleri, petro – kimya ürünleri, ahşap ve plastik malzemeler, perdeler v.s. ) kesinlikle bulundurulmamalıdır. ☞ Basınçlı su ile temizlemeyiniz. Cihazlarımızı...
  • Page 10 TRANSPORTATION AND RELOCATION Relocation; The device, assembled by the Authorized Service, may not be RELOCATED by any person other than the authorized service. ELECTRICITY SUPPLY CABLE MAY NOT BE EXTENDED, REPLACED. ☞ The device has to be located on the pallet in a vertical position using man power.
  • Page 11 TAŞIMA VE YER DEĞİŞTİRME Yer değiştirme ; Yetkili Servis tarafından montajı yapılmış cihazın yetkili servis dışında YERİ DEĞİŞTİRİLEMEZ, ELEKTRİK BESLEME KABLOSU UZATILAMAZ, DEĞİŞTİRİLEMEZ. * Cihaz insan gücüyle dik bir şekilde palet üzerine yerleştirilmelidir. * Forklift ayakları cihaz altına yerleştirilerek cihaz taşınır. * Taşıma mesafesinin uzak olması...
  • Page 12: Use Of The Device

    USE OF THE DEVICE Grill Plate is used for cooking meaty stu s like sh, chicken, meat balls, hamburger, chopsteak in restaurant, fast food, canteen, hospital kitchens. This device has been designed for cooking the product directly. No additional object like a cooking pot should be used. It would be inconvenient to use it for cooking frozen food stu s (-18 ºC ) since it will lead to damage on the cooktop.
  • Page 13 CİHAZIN KULLANIMI Kuzine, restoranlarda, kantin, hastane gibi yerlerin mutfaklarında, personel yemekhanelerinde, yemek fabrikalarında v.b. yerlerde yemek pişirmek amacıyla kullanılır. Cihaz ilk kullanımdan önce, fritöz gözünden başlayarak komple dış yüzeyi ılık sabunlu suya batırılıp, sıkılmış bez ile temizlenmelidir. NOT : Kullanım amacı dışına çıkmayınız. Makine güvenlik ve teknik şartlarını...
  • Page 14 IN CASE OF A BREAKDOWN OF THE DEVICE, THE INTERVENTION AUTHORITY SHALL SOLELY BE ON THE PART OF KAYALAR AUTHORIZED SERVICES. IF ANY TECHNICAL STAFF MEMBER OR UNQUALIFIED STAFF MEMBER OUT OF THE AUTHORIZED SERVICES INTERVENES IN THE DEVICE, THE DEVICE SHALL BE OUT OF THE SCOPE OF THE WARRANTY.
  • Page 15 USE OF THE DEVICE DİKKAT! : Cihazın montaj ve kullanımında anlatıldığı şekilde kurulup işletilmesine özen gösterilmelidir. Herhangi bir arıza durumu ile karşılaştığınızda size en yakın yetkili servisimize haber veriniz. CİHAZ ARIZALANDIĞINDA MÜDAHALE YETKİSİ SADECE ÖZTİRYAKİLER YETKİLİ SERVİSLERİNİNDİR. YETKİLİ SERVİSLERİN DIŞINDA BİR TEKNİK ELEMAN VEYA EHLİYETSİZ PERSONELİN CİHAZA MÜDAHALESİNDE CİHAZ GARANTİ...
  • Page 16: Cleaning And Maintenance

    CLEANING AND MAINTENANCE 1. CLEANING: The exterior, oil channel, oil pipe and oil container of the device have to be cleaned with a sponge and liquid cleaning material starting from the cooktop plate before and after the rst use and every following use. After use of the device, the waste oil on the surface has to be cleaned.
  • Page 17: Temi̇zli̇k Ve Bakim

    TEMİZLİK VE BAKIM TEMİZLİK: Cihaz ilk kullanımdan ve daha sonraki her kullanımdan önce ve sonra cihaz içine konulan kaplar çıkartılmalı varsa cihaz içindeki su boşaltılmalıdır. Komple cihaz dış yüzeyini ve su haznesini, kapları sünger ve temizlik malzemesi ile temizleyin. Temizlik esnasında tuz ruhu, cif v.b. gibi KİMYASAL TEMİZLİK MALZEMELERİNİ...
  • Page 18: Terms Of Warranty

    Ownership of the parts replaced shall be held by Kayalar 7- Solely the service sta members authorized by Kayalar can intervene in the breakdowns during the term of the scope of the warranty. Intervention of unauthorized people shall make the device out of the scope of the warranty.
  • Page 19 643 - 743 - 745 SERIES COOKERS 380/400 3N 50 60 Hz ENERJI KLEMENSI / TERMINAL BOARD Q1/Q2 SALTER / SELECTOR SWITCH R1/R2 REZISTANS / HEATING ELEMENT H1/H2 SINYAL LAMBASI / SIGNAL LAMP 663 - 783 - 785 SERIES COOKERS 380/400 3N 50 60 Hz ENERJI KLEMENSI / TERMINAL BOARD Q1/Q2/Q3/Q4...
  • Page 20 945 SERIES COOKERS 945 SERIES COOKERS 380/400 3N 50 60 Hz 380/400 3N 50 60 Hz 4 3 1 2 4 3 1 2 4 3 1 2 4 3 1 2 ENERJI KLEMENSI / TERMINAL BOARD ENERJI KLEMENSI / TERMINAL BOARD Q1/Q2 Q1/Q2 SALTER / SELECTOR SWITCH...
