  • Page 1 INSTALLATION MANUAL Grand-Format Inkjet Printer PJ-2646NXE Read This Manual Before Using The Rev. PJ2646E-I-00 Product.
  • Page 2: Table Of Contents

    PJ-2646NXE INSTALLATION MANUAL TABLE OF CONTENTS Introduction・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 1.1 Purpose of this manual・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 1.2 Safety instruction Unpacking・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2.1 Unpacking procedure ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2.2 Verification of packaged items 2.2.1 Contents of packaged items・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3 Assembly ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3.1 Removal of protective packaging material ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・...
  • Page 3: Introduction

    The product and the contents of this manual may be changed without prior notification. MUTOH INDUSTRIES LTD. has made the best efforts to keep this publication free from error, but if you find any uncertainties or misprints, please call us or call the shop where you bought this product.
  • Page 4: Unpacking

    PJ-2646NXE INSTALLATION MANUAL 2 Unpacking The unpacking procedure and contents of the package are described below. 2.1 Unpacking procedure Unpack the package according to the following procedure. CAUTION When unpacking or moving this product, always work with 4 people or more.
  • Page 5 PJ-2646NXE INSTALLATION MANUAL 5. Remove the bolts (4) fixing the fixed materials B (left and right) to remove the fixed materials B (left and right). Name Fixed material B (right) Fixed material B (left) Hexagon bolt to fix for fixed material B (left and right) 6.
  • Page 6: Verification Of Packaged Items

    After unpacking the packaging box, inspect to make sure that the unit is not damaged, and that all necessary parts are present. NOTE NOTE If any part is missing or broken, contact either of the following; The shop where you bought your MUTOH printer. Nearest MUTOH local dealer.
  • Page 7: Contents Of Packaged Items

    PJ-2646NXE INSTALLATION MANUAL 2.2.1 Contents of packaged items (1) Packaging box of the main unit Name Q’ty Name Q’ty Main unit, stand, winding unit 1 set Media tube (for winding unit) (2) Accessories packaging box Name Q’ty Name Q’ty Power cable...
  • Page 8: Assembly

    PJ-2646NXE INSTALLATION MANUAL 3 Assembly The assembly of this product is described below. 3.1 Removal of protective packaging material Protective packaging material is attached in the following locations of this product. Remove all protective packaging material according to the following procedure.
  • Page 9 PJ-2646NXE INSTALLATION MANUAL 6. Using the screwdriver attached to the product, remove the following parts that to fixed both side of the cushioning roller. Screw (2) Skirted collar (2) Name Cushioning roller Skirted collar 1 2 3 Screw 7. Using the screwdriver attached to the product, remove the following parts that to fixed both side of the tension roller.
  • Page 10: Installing The Panel Cover

    PJ-2646NXE INSTALLATION MANUAL 3.2 Installing the Panel cover Install the panel cover on the operation panel not to stain with the ink or the jetwash fluid. Install the panel cover according to the following procedure. 1. Install the following parts on the operation panel one over another as shown in the figure.
  • Page 11: Removal The Media Sticking Prevention Screen

    PJ-2646NXE INSTALLATION MANUAL 3.3 Removal the media sticking prevention screen The media sticking prevention screen is attached in the product at the time of product shipment. When not using papers that are easy to stick, such as a tarpaulin, a prevention network with paper tension is removed.
  • Page 12: Installation

    PJ-2646NXE INSTALLATION MANUAL 4 Installation Printer installation is explained below. 4.1 Choosing a place for the printer Install the printer in a proper location referring to the following. WARNING The ink and jet wash fluid used for this printer contains an organic solvent (CYCLOHEXANONE).
  • Page 13: Installation Environment Requirements ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・13

    Places where sudden changes in temperature and humidity are expected, even though the condition is within the range written above Places where direct sunlight or excessive lighting are expected Places where air conditioners blow directly MUTOH recommends that the printer should be installed where air conditioning can be adjusted easily.
  • Page 14: Required Space ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・14

    PJ-2646NXE INSTALLATION MANUAL 4.1.2 Required space Install the printer on a flat surface that fulfills the following conditions. NOTE NOTE See “7.2 Product Specifications” of the PJ-2646Operation Manual for the information of the printer. a=1000mm (39.4in.) b=1000mm (39.4in.) c=1000mm (39.4in.) d=600mm (23.6in.)
  • Page 15: Installing The Printer

    3. Jiggle the printer to make sure that it stable. Name Adjuster Stand Adjuster of the winding unit Adjuster of the feed unit The above concludes the installation procedure. Other work is required before operating the unit. For details see “PJ-2646NXE Operation Manual”.
