Page 1: User Manual
User Manual Industrial Ethernet Switch ROQSTAR Order No. 006-130-100 Order No. 006-130-101 Order No. 006-130-102 User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 1 of 37... - Page 2 © 2016 TRONTEQ Electronic All rights are reserved. The contents of this manual are protected by copyright. Their use is allowed as part of use of TRONTEQ products. Any other use which goes beyond in particular copying, reproduction, translation requires written consent of TRONTEQ Electronic.
-
Page 3: Table Of Contents
Download diagnostic image ....................31 14.5. Firmware-Update ......................... 32 15. Firmware-Update .......................... 32 15.1. Firmware-Update via web interface..................32 16. Diagnosis image ........................... 34 16.1. Download via web interface ....................34 User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 3 of 37... - Page 4 17. Help menu ............................. 34 18. Technical data ..........................35 18.1. Electrical ..........................35 18.2. Mechanical .......................... 36 18.3. Environment ........................36 19. Licenses ............................36 User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 4 of 37...
-
Page 5: Safety Instructions
ATTENTION! Indicates that minor personal injury can result if proper precautions are not taken. CAUTION! Hint for useful tips and recommendations for efficient and trouble-free operation. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 5 of 37... -
Page 6: Qualified Personnel
Intended use Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that TRONTEQ products operate safely and without any problems. The permissible ambient conditions must be complied with. The information in the relevant documentation must be observed. -
Page 7: Device Description
System status and Ethernet LEDs 8x port with 10/100BASE-TX Software Web interface LLDP SNMP DHCP Tag based VLAN Port Mirroring Port Monitor: link status, activity RSTP Firmware-Update Event logging Configuration management User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 7 of 37... -
Page 8: Scope Of Delivery
2.3. Scope of Delivery The package consists of the following articles: TRONTEQ ROQSTAR Switch M12-closing cap Installation guide User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 8 of 37... -
Page 9: Interfaces
Ethernet Port LEDs: LINK, ACT = Activity Ground connection Installation Never perform wiring electrical connections if they are under voltage! Do not perform any assembly work on the device when it is under voltage! WARNING! User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 9 of 37... -
Page 10: Mounting
Reserved for future application USB power supply, minus pole 3.5. Connecting the Ethernet ports Name Description Image Transmit Data + Receive Data + Transmit Data - Receive Data - User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 10 of 37... -
Page 11: First Start-Up
4. Start the web browser and enter the LAN-IP address of the device 5. Perform the desired configuration of the device 6. Connect the switch with your network devices User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 11 of 37... -
Page 12: Replacing A Damaged Device
To get access to the system, the user must authenticate. This will be done using a user name and a password. Subsequently, the web interface will be loaded The default access is configured as follows: user: admin password: password User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 12 of 37... - Page 13 After logging in at first the dashboard appears which shows a detailed overview and already provides initial information on the state of the network port. In addition, this page contains a graph showing the connections of the device. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 13 of 37...
-
Page 14: Settings Of The System
The setting of the Ethernet ports is carried out in the web interface under Configuration > Interfaces. The page contains two tables. The top shows the state of the interfaces. The table below can be used to change the settings. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 14 of 37... - Page 15 With the "Link" button you can activate and deactivate ports. Deactivating of unneeded ports is recommended if a link-down event should be monitored (see section 8.2). User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 15 of 37...
-
Page 16: Change Password
► loading a configuration from the internal memory To apply a configuration, you have to select the configuration and afterwards apply by clicking the "apply configfile" on the device. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 16 of 37... -
Page 17: Switch Settings
"tag-based" mode and are also a member of the VLAN. You can assign any several, but at least one tag to an interface. The interface receives a primary tag, which can be used to tag untagged packets. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 17 of 37... -
Page 18: Vlan Groups
The remaining bandwidth after all frames were sent from queue 3 is divided according to the scheme 4-2-1 between the queues 2-0. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 18 of 37... - Page 19 IP. The COS values are part of the 802.1Q header. They come into play when a port is in tag-based VLAN mode and the trust mode is VLAN. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 19 of 37...
-
Page 20: Link Aggregation
The settings for port mirroring are set in the web interface at Configuration > Port Mirroring. In the left table, the port mirroring is activated or deactivated (default: disabled). Also, the observation port (destination port, destination port) can be set. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 20 of 37... -
Page 21: Time
Description Server ROQSTAR acts as an NTP server for the participants. It gets no time from an NTP server. The system time must be configured. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 21 of 37... -
Page 22: Snmp
Configuration > System. They can be changed with SNMP Set commands. The interface and RMON MIB represents all the values read-only available. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 22 of 37... -
Page 23: Snmp Mibs
„ifOperStatus“. The last digit corresponds to the interface instances. In the MIB ifTable the instance is the same as the Ethernet ports of the device. Therefore the Ethernet ports 1, 3, 6, 8, 10 are up, the others are down. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 23 of 37... - Page 24 User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 24 of 37...
-
Page 25: Snmp Traps
"enable" the ROQSTAR is processing incoming LLDP frames. In a 30-second interval it sends LLDP frames that include the following information: system name system description interface name interface description MAC address User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 25 of 37... -
Page 26: Rstp
As soon as two ports of the Switch are directly or indirectly (over different switches) connected, the RSTP will block one of the two ports on a logical level. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 26 of 37... -
Page 27: Dhcp
IP addresses that are assigned via DHCP Option 82, remain bound to the device when it is connected within the lease time to a port without DHCP option 82. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 27 of 37... -
Page 28: Device Information
Color Activity Operational State none no network connection, Link-Down Link green lights up network connection, Link-Up none no data transfer yellow flashes data transfer with 10/100 MBit / s User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 28 of 37... -
Page 29: Fault Contact
The electrical characteristics of the fault contact are described in section 18.1, the connection in chapter 3.3. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 29 of 37... -
Page 30: Log Files
2015-10-02T15:11:15Z INFO switch interface 9 down 2015-10-02T15:11:15Z INFO switch interface 8 down 2015-10-02T15:11:15Z INFO switch interface 6 down 2015-10-02T15:11:15Z INFO network interface 1 up 2015-10-02T15:11:15Z INFO system system startup User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 30 of 37... -
Page 31: Usb-Functions
A diagnostic image contains information about the system that are helpful for the technical support. After plugging in the USB flash drive it takes 20 seconds to generate the data and place it on the USB User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 31 of 37... -
Page 32: Firmware-Update
In the Info column the current step will be described. ROQSTAR does not start automatically upon completion of the update. You can also restart by clicking "reset" initiate manually. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 32 of 37... - Page 33 ► decompressing the firmware update file ► flashing the update ► preparing to boot the new version ► firmware update succeeded To complete the firmware update, a reboot of the system is necessary. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 33 of 37...
-
Page 34: Diagnosis Image
Click on „Open as site and info as pop-up“ and you will get to the web site of the actual term. The help information text will appear in a pop-up window. User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 34 of 37... -
Page 35: Technical Data
Frame size 64 – 1518 Byte Throughput multicast packets Full wire speed Frame size 64 – 1518 Byte Frame size without VLAN Tag 1518 Byte with VLAN Tag 1522 Byte User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 35 of 37... -
Page 36: Mechanical
Open Sources projects and the associated licenses. Software / Project Version Licenses Linux Kernel 3.18 Linux GPL v2 U-Boot 2014.07 GPLv2 AT91Bootstrap 3.7.1 Atmel Apache 2.4.9 Apache License v2.0 ModPHP 5.5.10 PHP License User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 36 of 37... - Page 37 5.20.0 GPLv1, Artistic libtinfo5 libuuid1 2.24.1 GPLv2, LGPLv2.1, BSD libz1 1.2.8 Zlib netbase GPLv2 packagegroup-core-boot shadow 4.1.4.3 BSD, Artistic sysvinit 2.88dsf GPLv2 udev GPLv2 update-rc.d GPLv2 update-alternatives-opkg 0.1.8 GPLv2 User Manual ROQSTAR Support: www.tronteq.de/support Release 11/2016 Page 37 of 37...
