Swimming Pool Heat Pump
Swimming Pool Heat Pump
INSTALLATION AND USER MANUAL
Thank
Thank
you for choosing our product and trusting our company.
you for choosing our product and trusting our company.
This manual is to provide you with necessary information for optimal use and
This manual is to provide you with necessary information for optimal use and
maintenance, please read it carefully and keep it for subsequent use.
maintenance, please read it carefully and keep it for subsequent use.
Advertisement
Table of Contents
Related Manuals for heatpumps 4pools THP05NP
Summary of Contents for heatpumps 4pools THP05NP
- Page 1 Swimming Pool Heat Pump Swimming Pool Heat Pump INSTALLATION AND USER MANUAL Thank Thank you for choosing our product and trusting our company. you for choosing our product and trusting our company. This manual is to provide you with necessary information for optimal use and This manual is to provide you with necessary information for optimal use and maintenance, please read it carefully and keep it for subsequent use.
-
Page 2: Table Of Contents
Content . Introduction ................. 1 Ⅰ Ⅰ Ⅰ Ⅰ Safety precaution ..................1 Important features of this product .............. 1 Parameters of product range ..............3 . Installation Guide ................ 5 Ⅱ Ⅱ Ⅱ Ⅱ Transport it in proper manner ..............5 Determining Optimum installation position .......... -
Page 3: Introduction
. Introduction Ⅰ Ⅰ Ⅰ Ⅰ Safety precaution Caution: Danger of electric shock Always switch off power supply before working on the heat pump and stop the hydraulic circuit. - The swimming pool heat pump must be installed by a qualified electrician. - Always install a differential protective device with a sensitivity of 30 mA on the distribution unit before the electrical box. - Page 4 High / Low Refrigerant Pressure Switches • The high-pressure switch senses the refrigerant pressure in the sealed refrigeration system and shuts the heat pump down in the event unsafe operating pressures are reached. The heat pump will automatically reset after the system pressure drops back to normal operating pressures.
-
Page 5: Parameters Of Product Range
Parameters of product range Specification Model THP05NP THP08NP THP10NP THP12NP THP14NP THP17NP 14.0 Heating capacity kW 14.0 17.0 (air 26℃ ℃ ℃ ℃ ,water 26℃ ℃ ℃ ℃ ) C.O.P. (air 26℃ ℃ ℃ ℃ ,water26℃ ℃ ℃ ℃ ) 10.0... - Page 6 Dimension: Size(mm) Name Model THP05NP THP08NP THP10NP THP12NP THP14NP THP17NP Above data is subject to modification without notice...
-
Page 7: Installation Guide
. Installation Guide Ⅱ Ⅱ Ⅱ Ⅱ Attention! This swimming pool heat pump must be installed by a skilled team. Transport it in proper manner 1. Transport it in original package. 2. When moving the machine, do not lift the water nozzle since the titanium heat exchanger in side the machine will be damaged. - Page 8 Pay attention to the following points: 1． The heat pump must be installed OUTSIDE in a well ventilated place to avoid air recirculation or in a place with adequate room area both for installation and maintenance. Please refer to the following illustration: A minimum of 500mm of clearance from walls, shrubbery, equipment, etc.
- Page 9 !!Warning: The machine must not be hung onto the wall with soft pipe since the inlet/outlet union on the machine can’t hold weight. The machine must always be connected with hard pipe! 3． The heat pump should be far from any source of combustibles and corrosive material to avoid any damage to this unit.
-
Page 10: Water Pipe Connection
Water pipe connection - The water flow through this machine needs to be driven by an appended water pump (Prepared by the user). The recommended pump specification-flux is shown on the product specification and Max. lift ≥10m; - Pipe length between heat pump and swimming pool should not be longer than 10m. Noted: The drawing is just for demonstration, and layout of the pipes for reference. - Page 11 Attention: The swimming pool heater must be earthed well. Recommendation for protecting devices and cable specification MODEL THP05NP THP08NP THP10NP THP12NP THP14NP THP17NP Rated Current Rated Breaker Residual Action Current Fuse Power Cord (mm 3×1.5 3×2.5 3×2.5 3×2.5 3×2.5 3×4 Signal cable (mm 3×0.5...
-
Page 12: Trial After First Installation
Trial after first installation Attention: Always Start the water pump before turning on this machine Turn off this machine before turning off the water pump. Inspection before connecting power supply - Check the installation of the whole machine and the pipe connections according to the pipe connecting drawing. -
Page 13: Operation Guide
. Operation guide Ⅲ Ⅲ Ⅲ Ⅲ LED controller Water Temp Power On/Off Power on/off HEAT Shows the heat mode has been set Down-ALLOW Set required temperature UP-ALLOW Set required temperature LED screen Display temperature and machine failure code 1． ． ． ． Operation Display The display shows Temperature of the swimming pool water when the machine is on. -
Page 14: Testing
D． When you want to check setting temperature, press see the current setting. Testing １ １ １ １ ． ． ． ． Inspection before use A. Check installation of the whole machine and the pipe connections according to the pipe connecting drawing; Check the electric wiring according to the electric wiring diagram and earthing connection;... -
Page 15: Precautions
Precautions １ １ １ １ . Attention A. Set proper temperature in order to get comfortable water temperature to avoid overheating or overcooling; Please don’t stack substances that can block air flow near inlet or outlet area, or the efficiency of the heater will be reduced or even stopped; Please don’t put hands into outlet of the swimming pool heater, and don’t remove the screen of the fan at any time;... - Page 16 A. Please keep the main power supply switch far away from the children; When a power cut happens during running, and later the power is restored, the heater will start up automatically. So please switch off the power supply when there is a power cut, and reset temp when power is restored; Please switch off the main power supply in lightning and storm weather to prevent from machine damage that caused by lightning;...
-
Page 17: Maintenance
. Maintenance Ⅳ Ⅳ Ⅳ Ⅳ Caution: Danger of electric shock “Cut off” power supply of the heater before cleaning, examination and repairing A． In winter season when you don’t swim: Cut off power supply to prevent any machine damage. Drain water clear of the machine. -
Page 18: Trouble Shooting
. Trouble shooting Ⅴ Ⅴ Ⅴ Ⅴ Common faults Phenomenon Possible reason A. The fan motor stops automatically for defrost. B. There will be sound from the solenoid valve when A.Noticeable White vaporous machine starts or ends to defrost. cold air or water. C. -
Page 19: Failure Code
Failure code Failure Failure description Action code EE 1 High pressure protection Contact your dealer. EE 2 Low pressure protection Contact your dealer. 1. Check if there is no water through machine; make sure the EE 3 Low water pressure protection pump is on.
