New Features Harware changes Programable PGM output Technician service keypad connector dual 12volt output terminals seperate non monitored box tamper input seperate non monitored full and parttial arm keyswitch inputs optional plug on Radio receiver (iRX and iRX2) Optional plug on GSM dialler module (iGSM) Default pins 3 x seperate auto resetabble electronics fuses PSTN line fault monitoring...
Page 4
Inputs Inputs 1 to 8 Are 10K monitored inputs, with a response time of over 300 ms. Alarm triggers siren, strobe and dialler (depending on setup). Are armed in the on or partial mode (depending on partial setup). May be programmed to have exit / entry, exit / handover delays or may be programmed for 24 hour operation.
Page 5
Indicators on the PCB This LED indicates that the micro-controller is operating and must always be flickering. Dial This LED, located adjacent to the dial relay, will light when the dialler is in its reporting sequence (line looped) and will extinguish when reporting is completed. This LED indicates when the PGM output is active for an event as per the programming of Function 80 INT, EXT &...
Page 6
Program Readback With the full range of panels there are basically two methods of reading back information that has previously been programmed. The first method allows information that is serial in format to be read sequentially ie. phone numbers, while the second method allows all selections to be seen at once ie.
Page 7
Entering Program Mode There are two codes that will allow access to the product range of panels for programming. The technician code that will allow access to all programmable functions and the master user code which allows access only to user code programming.
Page 8
Control Panel Functions Funct # Function Defaults Master Code 218572 User code 1 1111 02-30 User code 2 to User code 30 Exit time 60 secs Entry time 30 secs Siren time 5 min Partial Mode isolates Keypad Panic audible Disabled Exit and Entry sections Sections 1 + 2...
Page 9
Function 00 - Master Code Default - 218572 ( six digits) Description : Options : (6 digit entry required) The Master code is used to enter and change Any 6 Digits the user codes only (no system setups may be changed). The Master code may be changed by either the Technician or by the holder of the existing Master code.
Page 10
Function 40 - Exit Time Default - 60 seconds Description : Options - (Single digit entry required) This function sets the time that sectors allo- 0 - 0 seconds 5 - 50 seconds cated as entry/exit (Function 49), exit hando- 1 - 10 seconds 6 - 60 seconds ver (Function 50) or partial exit/entry (Function...
Page 11
Function 43 - Partial Mode Default - No sections programmed. Description : Options : (Two digit entry required per sector) Partial mode sets up a preprogrammed Any sector or combination of sectors from 1 to 8 list of sections which are automatically isolated when the unit is turned on using the partial key.
Page 12
Function 50 - Exit and Handover Sections in ON Mode Default - none Description : Options : (Two digit entry required per sector) Display and / or change which sections will Any sector or combination of sectors from 1 to 8 have exit / handover delay.
Page 13
Function 55 - Silent Sections Default - None Description : Options : (Two digit entry required per sector) Display and change which sections will Any sector or combination of sectors from 1 to 8 operate as Silent Sections ie. they will report to the monitoring company but will not activate the sirens.
Page 14
Function 63 - Open/Close reports - Yes / No. Default -Send open /close Description : Options : (Single digit entry required) Open / Close sent Selects whether open / close reports are No Open / Close sent. sent or not. Example : While in programmode (Program LED flashing) Key Sequence Operation...
Page 15
Function 67 - Reporting format Default - Contact I.D. (4) Description : Option : (Single digit entry required) This function determines the format the Ademco high speed dialler will report in. Tape Dial (No handshake to start Tx.) SMS reporting (ph # 1,2,3) (Version 8.02+) Contact I.D.
Page 16
Function 70 - Report Using Checksum Default - Using checksum Description : Options : (Single digit entry required) The dialler defaults to use the single Report using checksum round with checksum. Do not use checksum in reporting If a 0 is programmed the dialler will report in dual round without checksum.
Page 17
Function 73 - Delay till First test report Default - 12 hours Description : Options : (Single digit entry required) 0 to 9 = number of 4 hr periods before the first test This sets the delay from when program is exited till the dialler sends its first test report, in multiples of 4 hours.
Page 18
Function 76 - Multi-Report (Multi-Break) Default - None Description : Options : (Two digit entry required per sector) Display and change which sections will Any sector or combination of sectors from 1 to 8 report input condition changes when armed. Note: This option will not give multi triggering of sirens to a section but will give multi reporting.
Page 19
Function 80 - PGM Programmable Output Default - Kiss-off received Options : (Single digit entry required) Description : Output disabled Program the option that will acti- Kiss-off (the output will activate for 750msec on vate the low current output. every kiss of received from the monitoring center) Line Fail (activates the output when the line fails, follows the line fail timer restoral ie.12sec) Remote button 3 (Momentary - activates the...
Page 20
Function 82 - RF Keyfob Programming Default - No remotes learnt Description : Options : (Single digit entry required) This function, will allow programming of key- Enter 0 to initiate Learn mode fobs into the ICON RF Module. Enter Isolate followed by On to delete all remotes To initiates learn press the 0 key, the first available sector will flash (if no fobs are learnt already this will be sector 1) press any button...
Page 21
Function 84 - Chime Sections Default - No Chime Sections Description : Options : (Single digit entry required) This function will allow sections to trigger Any sector or combination of sectors from 1 to 8 the keypad beeper for 1 second when in the disarm state.
Page 22
Function 87 - Miscellaneous options Section LED ON (Flashing) Default - All OFF Disable Tamper Input Tamper enabled Tamper is Silent Tamper is Audible Tamper armed in ON and Part Mode Tamper armed 24hours GSM fail reporting enabled GSM reporting disabled reserved reserved reserved...
Page 23
Function 88 - SMS Phone number options Section LED ON (Flashing) Default SMS to PH 1 ON SMS TO PH 1 OFF SMS to PH 2 ON SMS TO PH 2 OFF SMS to PH 3 ON SMS TO PH 3 OFF SMS CMD from Ph 1 Enabled SMS Cmd from Ph 1 Disabled SMS CMD from Ph 2 Enabled...
Page 24
Function 89 - Single Digit Arming Default - disabled Description : Options : (Single digit entry required) This function, when enabled, will allow the 0 = Single digit arming is disabled panel to be turned on by pressing the 0 key 1 = Single digit arming is enabled and either the 'ON' key for full arming or 'PARTIAL' key for partial arming.
Page 25
Function 92 - Slave Dialler Option Default - Control Dialler Description : Options : (Single digit entry required) If this option is enabled, the panel will, to Control Dialler all intents and purposes act as a slave Slave Dialler dialler. When the Slave Dialler option is selected, inputs are 10k end of line Example : While in program mode (Program LED flashing)
Page 26
Function 95 - Arming Lockout Default - Arming enabled Description : Options : This function may be used to prevent the 0 = Arming can be performed. 1 = Arming is disabled. user from being able to arm the panel Example : While in program mode (Program LED flashing) Key Sequence Operation...
Page 27
Function 98 - Status on power up Default - Do not retain status Description : Options : If this option is enabled, the panel will 0 = Do not retain status. attempt to power up in its previous state 1 = Retain status. when power is restorede.(e.g.Armed).
Page 28
Reporting codes Contact ID Function 67=4 Contact ID Format SSSS 18 E TTT PP NNN Where SSSS = Four Digit Account Number 18 = Unique Format Identifier (Not Displayed or Printed) Event 1 = New Event or Opening 3 = New Restore or Closing TTT = Event Code = Panic Alarm...
Page 29
SMS programming and control SMS Commands [**][UUUU][XXX][##] (available when GSM or SMS formats are enabled Function 67 = 2, 5 or 6 ** = is the header…all commands start with 2 asterisks UUUU is a valid user code that is programmed in the panel is the command can be 1 to 3 characters long is the footer….all commands must end with 2 hashes Status...
Page 30
SMS programming and control System Status Examples [**][UUUU][S][##] System Status Status = **1111S## Firmware version iRIS8 F/W: V7.82 iRIS8 F/W: V7.82 iRIS8 F/W: V7.82 Arm/Disarm Status System Status Disarmed System Status Full Armed System in ALARM, Zones 2 PSTN Status PSTN OK PSTN Failed PSTN Disabled...
Page 31
Other Features - CHIME activates keypad buzzer for one second when a chime zone is unsealed. - KEYBOARD panic Keyboard Panic is achieved by pressing and holding both the OFF and ON keys together and holding for 2 secs. This is a local as well as a back to base.
Page 32
iRIS 8 Enhancement and versions IRIS8 Software Version V7.82 Added Option 4 in Function 87 – Enable GSM Fail Reporting, Single flash of FIRE led equals GSM fail Added Option 8 in Function 80 – Enable GSM Fail Output Added Option 4 in Function 93 – Momentary Arm only for Full & Part Key switches Added Chime On/Off –...
