DMP Electronics 1115 Installation Manual

1115 WIRELESS TEMPERATURE
SENSOR AND FLOOD DETECTOR
Installation Guide
Figure 1: 1115 Wireless Temperature
Sensor and Flood Detector
DESCRIPTION
The 1115 Wireless Temperature
Sensor and Flood Detector is
designed to be used in a variety
of applications that help protect
against temperature fluctuations
and flood conditions. The 1115 has
an internal temperature sensor that
can be set to detect cold, hot, or
warm temperature ranges.
When combined with the
remote T280R temperature
probe, the 1115 can be set to
monitor refrigerated or freezing
temperatures.
The 1115 can also be paired with
the remote 470PB water sensor
and used in situations where flood
detection is necessary.
Depending on a customer's needs,
the 1115 can be programmed with
up to four zones and serve as a
temperature sensor, flood detector,
or both simultaneously.
Compatibility
All DMP 1100 Series Wireless
Receivers and burglary
panels. See the last page for
compatibility details.
What is Included?
ƒ One 1115 PCB mounted in a
two‑part housing
ƒ One 3V lithium CR123A battery
ƒ One 2MΏ EOL resistor
ƒ Mounting screws
1
PROGRAM THE PANEL
The 1115 Wireless Temperature Sensor and Flood Detector
can be programmed with up to four zones. When
programming the 1115 in the panel, refer to the panel
programming guide as needed.
Note: When a wireless receiver is installed, powered down
and powered up, the panel is reset, or programming is
complete, the supervision time is reset. If the receiver has
been powered down for more than one hour, the 1115 may
take up to an additional hour to send a supervision message
unless tripped, tampered, or powered up. This operation
extends battery life. A missing message may display on the
keypad until the supervision message is sent.
1. In ZONE INFORMATION, enter the ZONE number and
press CMD.
Note: Zones must be entered sequentially. For
example, if you begin by programming zone 71, you
would need to program zone 72 as the next contact.
2. Enter the ZONE NAME and press CMD.
3. Select SV (Supervisory) as the Zone Type and press
CMD.
4. At the NEXT ZONE prompt, select NO. If you see the
WIRELESS ZONE prompt, select YES.
5. Enter the eight‑digit SERIAL NUMBER and press CMD.
6. Enter the CONTACT number being used.
Note: Contacts can be entered in any order. Refer to
Table 1 to select the correct contact.
7. Enter the SUPRVSN TIME and press CMD.
8. At the NEXT ZONE prompt, select YES and continue
to program up to three more zones.
Note: For the 1115's tamper feature to be enabled, contact 1
must be programmed as a zone in the control panel.
2
INSTALL THE BATTERIES
After the transmitter has been programmed into the panel,
install the batteries. Use only 3.0V lithium batteries, DMP
Model CR123A, or the equivalent battery from a local retail
outlet. Keep in mind, when setting up a wireless system,
program zones and connect the receiver before installing
batteries in the transmitters.
1. Remove the cover by pushing the button on the end
of the cover and gently pulling upwards.
2. Observing polarity, place the battery in the holder and
press into place.
