- Page 1 Dolphin PCI Express IXS600 Switch IXS600 8 ports PCI Express x8 switch users guide This guide is only valid for revisions IXS600-HI and newer Version 2.05 Date: 20 April, 2016...
-
Page 2: Table Of Contents
NTB mode port usage ................................8 Cascading switches ................................8 Partitioning – mixed transparent and NTB usage ......................... 8 PCI Express Gen3 Switch - IXS600 .............................. 9 IXS600 high level specification .............................. 9 Cables ....................................10 Transition cable to lower lane width ........................... 10 Management processor .............................. - Page 3 Limitations ................................... 31 DISCLAIMER DOLPHIN INTERCONNECT SOLUTIONS RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE TO ANY OF ITS PRODUCTS TO IMPROVE RELIABILITY, FUNCTION, OR DESIGN. DOLPHIN INTERCONNECT SOLUTIONS DOES NOT ASSUME ANY LIABILITY ARISING OUT OF THE APPLICATION OR USE OF ANY PRODUCT.
- Page 4 ENVIRONMENTAL POLICY Dolphin is minimizing the amount of printed documentation and software CDs in its shipments, please download additional documentation and software from www.dolphinics.com/support/. IXS600 Users Guide – Dolphin Interconnect Solutions Page 3...
-
Page 5: Overview
7 Meter PCIe Gen2 x8 Copper Cable The IXS600 switch can be used to connect to any of the above iPass cable based products or to any compliant existing PCI Express downstream device having a standard PCI Express x8 iPass connector (PCI Express Gen 1 or Gen2 auto detect). -
Page 6: Revision History
Revision history The IXS600 switch has been undergoing a number of changes to adopt to new requirements and improved performance made available through new revisions of the PCIe chipset. Hardware revisions The following table gives a general overview of the hardware capabilities. -
Page 7: Configuration Examples
Configuration examples The IXS600 switch can be used as a standalone switch, for larger transparent PCIe expansion systems or PCIe cluster systems using multiple switches. Some examples can be found below. 8 node PCIe Gen2 and Gen3 NTB Cluster Each node has a Dolphin Express PXH810, IXH610 or IXH620 adapter. -
Page 8: Quick Install Guide
Quick install guide The IXS600 can be mounted in a 19-inch rack or used in a standalone setup. Rack mount ears are included in the package and can be mounted on both sides of the switch depending on user requirements. Rubber feet are included in the package and should be applied beneath the switch to avoid scratches. -
Page 9: Ntb Mode Port Usage
Dolphin for further technical information. Cascading switches The IXS600 (revisions Hx and higher) supports cascading multiple switches into larger PCI Express networks. In combination with the IXH610 adapter, up to 20 nodes can communicate using Dolphins NTB driver. In reflective memory configurations, up to 56 nodes can be interconnected. -
Page 10: Pci Express Gen3 Switch - Ixs600
PCI Express Gen3 Switch - IXS600 The IXS600 is a PCI Express Gen3 x8 switch available from Dolphin providing an easy to use, multi-functional solution. IXS600 high level specification • PCI Express Gen1 2.5 Gbps / Gen2 5.0 Gbps / Gen3 8.0 Gbps per lane signaling – 8 lanes – up to 64 Gbps total signaling pr port. -
Page 11: Cables
Transition cable to lower lane width The IXS600 switch can be connected to other PCIe equipment having a lower lane width (x4, x2, or x1) using a transition cable. The switch will automatically adjust to the lower lane width as well as lower PCIe speed (Gen1, Gen2) to meet the requirement for the connected PCIe device. -
Page 12: Use Cases Summary And Settings
SuperSockets, Dolphin adapter card PCI Express cable TCP/IP, PXImc Mixed Switch is portioned. Behavior depends on configuration data. May combine use case A and B Table 3: Switch use cases IXS600 Users Guide – Dolphin Interconnect Solutions Page 11... -
Page 13: Leds
Dark: Normal operation. Red: Failure. Blinking red: Software upgrade in progress. Table 1 Management Processor LED overview Switch status LEDs The IXS600 front panel has two status LEDs Status LEDs Description Lit green when the switch is configured for stand-alone use (CASCADE_TOP) Lit green when the switch is configured as a leaf-switch (CASCADE_SUB). -
Page 14: Front And Rear Panel Link Leds
Table 2: Link LED overview The NTB link LED is only controlled by firmware. Both LEDs depends on GPIO registers initialized by EEPROM. An incorrect EEPROM can cause dark LEDs. IXS600 Users Guide – Dolphin Interconnect Solutions Page 13... -
Page 15: Installation
Finland: "Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan" Installing the Switch in a rack The IXS600 shipping box includes rack mount ears that can be used to fix the IXS600 into a 19-inch standard rack. Installing and removing the cable The IXS600 supports PCI Express x8 iPass cables. Installing and removing cables should be done with both upstream and downstream device powered off. -
Page 16: Connecting Multiple Switches
17. 3) Install a standard iPass x8 cable between the Top switch port 1 and the Sub switch port 1 Figure 1: 14 node configuration and setup IXS600 Users Guide – Dolphin Interconnect Solutions Page 15... -
Page 17: Connecting Up To 20 Nodes Using Three Switches
Figure 2: 20 node configuration and setup Connecting up to 56 nodes for reflective memory The IXS600 and IXH610/IXH620 cards can be used to build reflective memory systems up to 56 nodes. Please contact Dolphin for configuration details. IXS600 Users Guide – Dolphin Interconnect Solutions... -
Page 18: Web Gui
Web GUI The IXS600-HI and later revisions with firmware 1.3.3 or newer ship with a Web GUI for monitoring and management use. In the shipping-configuration, the network-address is set to 192.168.0.50 with a 255.255.255.0 netmask. Configure a system with a web-browser to a suitable address (e.g. 192.168.0.51), and point your browser to the default switch address: http://192.168.0.50... - Page 19 Switch network information can be retrieved by following the USB flash drive procedure described in section Management processor on page 10. Use this if you are unable to connect to a switch on the expected IP address. IXS600 Users Guide – Dolphin Interconnect Solutions Page 18...
-
Page 20: Switch Ip Configuration
The switch will distribute its configured hostname to the DHCP server. The hostname is usually equal to the serial number for newer switches. It is usually “ixs600” for older switches. On the configuration tab, please enter IP-settings suitable for your network. Ask your systems administrator for the correct configuration on your network. -
Page 21: Configuring The Proper Time Zone
Configuring the proper time zone You must be careful when changing the IXS600 timezone setting to make it work properly. Please note that it only support POSIX style time zones. This means that the offset signs are reversed from the standard ISO 8601 convention. E.g.: •... -
Page 22: Network Configuration Without The Web Interface
7. Review the new files present on the USB stick tsusb script toggling DCHP on/off #!/bin/sh echo "This script toggles DHCP on the IXS600 switch" echo "---------------------------------------------" if [ ! -e /opt/DIS/sbin/ixsctl ]; then echo "ERROR: ixsctl is not present on this device."... - Page 23 #!/bin/sh echo "Sets a static network configuration on the IXS600 switch" echo "--------------------------------------------------------" # Adjust these values accordingly to your network setup ADDR=192.168.0.50 MASK=255.255.255.0 GATEWAY=192.168.0.1 DNS_SERVER=192.168.0.1 DNS_DOMAIN=localdomain if [ ! -e /opt/DIS/sbin/ixsctl ]; then echo "ERROR: ixsctl is not present on this device."...
-
Page 24: Switch Monitoring
NC on yellow. Gen1 speed and x4 or narrower links are reported with an updated red status text. The various information is automatically updated and there should be no need to refresh the page. IXS600 Users Guide – Dolphin Interconnect Solutions Page 23... -
Page 25: Firmware Management & Upgrade
Dolphin’s IXS600 switch is pre-configured during manufacturing and a firmware upgrade is normally not required for default operations. Please contact Dolphin support before trying to upgrade any firmware not included in the switch. This process may render your device useless or inaccessible if the process is interrupted or a corrupted firmware is uploaded to the switch. -
Page 26: Usb Flash Drive
Ethernet configured or connected. The IXS600-switches support firmware-upgrades from a normal USB flash drive (not supplied with the product). Please download the firmware distributable (a .zip –file), and unzip the contents onto the root of the USB device. All USB flash-devices are expected to work, and at least the FAT32 file-system is supported. - Page 27 IXS600 Users Guide – Dolphin Interconnect Solutions Page 26...
-
Page 28: Link Watchdog
Please note that you should only enable the minimum configuration on ports in-between switches, and only on one of the switches. Switches configured as sub-switch will automatically recommend which port you should configure on the watchdog page. The adapters already have an active link watchdog integrated into the driver. IXS600 Users Guide – Dolphin Interconnect Solutions Page 27... -
Page 29: Management Processor Logs
The GUI allows access to the log-information the management processor has collected in the /Logs.shtml. Use the expandable entries to show log contents from the config-log, command-log, installation log, upgrade log and web-server log. IXS600 Users Guide – Dolphin Interconnect Solutions Page 28... -
Page 30: Software Installation
Software installation No special software is required for the switch but Dolphin Express IX adapters need to install DIS 4.2.4 or newer software releases to enable seamless integration with the IXS600 switch. More information on installing Dolphins SuperSockets, SISCI or TCP/IP driver software can be found at http://www.dolphinics.com/support/installation-ix.html... -
Page 31: Compliance
Compliance EMC compliance The Dolphin PCI Express IXS600 switch has been tested and found to comply with the following relevant test standards for PCI Express equipment, Telecommunication and Industry equipment: • EN 55022 (2010) • EN 55024 (1998) + A1 (2001) + A2 (2003) •... -
Page 32: Limited Warranty
Dolphin Interconnect Solutions warrants this Product to be free from manufacturing defects under the following terms: Warranty period Dolphin warrants the Product for one (1) year from the date of purchase. Extended warranty may be purchased with the equipment. Coverage To the extent permitted by applicable law, this warranty does not apply to: •...
