- Page 1 Installation Instructions / Warranty Massaud 18013001 Massaud 18213001...
- Page 2 Massaud Lavatory Faucet 18013001 Massaud Bidet Faucet 18213001 18013001 18213001...
-
Page 3: Product Specification
Product Specification Max. flow rate 2.2 gpm Max. incoming water pressure Recommended water pressure Max. hot water temperature Recommended hot water temp. Hole size in mounting surface valves 1 1/4” spout 1 3/8” Max. thickness of mounting surface 1 3/8” Lavatory faucet 18013001 includes 10 mm supply hoses. - Page 4 Turn the cartridge stems so that they are in the “off” posi- tion. Turn the hot stem clockwise, the cold stem counter- clockwise. Push the red color ring and hot handle firmly over the hot (left) valve (1). Push the blue color ring and handle firmly over the cold (right) valve (2).
- Page 5 Tighten the tensioning screws. 18013001 Place a compression nut and compression ferrule over the end of the connection hose -- the lavatory ferrule should be installed metal side first. 18213001 Attach the connection hose to the valve outlet port. Use two wrenches, as shown, to keep the hose from twisting.
- Page 6 The following steps apply only to lavatory faucet 18013001: Install the hot and cold supply hoses to the valve inlet ports by hand -- do not use a wrench. Be careful not to twist or kink the hoses. Install the filters on the stops. Install the adapters on the filters.
- Page 7 Push the end of the hose into the adapter. While holding the hose steady with an 11 mm wrench, use a 19 mm wrench to tighten the compression nut. If the flow of water from the faucet becomes less over time, remove and clean the filter screens.
-
Page 8: Install The Pop-Up Drain
Install the pop-up drain Remove the plunger assembly. Unscrew the drain outlet flange from the tee. plunger Unscrew the tailpiece from the tee. Wrap the height adjuster threads with plumbers’ thread tape and replace. Install the white, flexible sealing gasket to the flange flange. -
Page 9: Replacement Parts
Replacement Parts spout spray former pull rod hot cartridge valve fixation set connection hose compression ftg color ring 10 handle 11 cold cartridge 12 friction washer 13 supply hose 14 cover 15 ball joint 16 aerator 17 connection hose 18 compression fitting 88513000 19 valve set 98658000 97447000... -
Page 10: Limited Lifetime Consumer Warranty
Cleaning Recommendation for Hansgrohe Products Modern sanitary faucetry and shower fixtures consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain points when cleaning: Cleaning materials for faucets and shower products: Acids are necessary ingredients of cleaning materials for removing lime. - Page 11 (ii) for 5 years, with respect to AXOR products. THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR: Conditions, malfunctions or damage not resulting from defects in material or workmanship. Conditions, malfunctions or damage resulting from (1) normal wear and tear, improper installation, improper maintenance, misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or caustic cleaning agents or “no-rinse”...
- Page 12 Hansgrohe, Inc. • 1490 Bluegrass Lakes Parkway • Alpharetta, GA 30004 Tel. 770 360-9880 • Fax 770 360 9887 www.hansgrohe-USA.com...
