7. Specifications
Input Range mA:
Output Range mA
Source/Simulate:
Read VDC:
Accuracy:
Resolution:
Loop Supply Voltage:
Typical Drive Capability:
Auto % Error Function:
Selectable Decade Adjustment:
Auto Step/Ramp:
Preset Outputs:
Loop Power Measure Capability:
Operating Temperature:
Power Supply:
Rechargeable Battery Option:
AC Adapter:
Size:
Weight:
6
0.000 to 4.000 mA
–5.00% to 15.00%
0.000 to 4.000 mA
–5.00% to 15.00%
0 to 30 VDC
±0.015% of reading ± counts
0.001 mA; 0.001 volts
4 VDC
100 Ω w/o HART™
950 Ω with HART™
Yes
Yes
Yes
5
Yes
–10°C to 55°C
9V Battery
Yes, optional available
Yes, optional available
5.7 x 3.15 x 1.43 in (145 x 80 x 37 mm)
1 oz. (340 g)
