MyCar AR-3HU Installation & Programming Manual

Telematics communicator
Hide thumbs Also See for AR-3HU:
Table of Contents

Advertisement

Quick Links

Download this manual
COMPLETE INSTALLATION & PROGRAMMING GUIDE
MYCAR Telematics Communicator
This system must be installed by a professional.
NOTICE
The manufacturer will accept no responsability for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the
installed device. This device must be installed by a certified technician. Please review the
Rev Date: 20171109
Installation Guide carefully before beginning any work.
EN-20171109-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AR-3HU and is the answer not in the manual?

Questions and answers

Related Manuals for MyCar AR-3HU

Summary of Contents for MyCar AR-3HU

  • Page 1 COMPLETE INSTALLATION & PROGRAMMING GUIDE MYCAR Telematics Communicator This system must be installed by a professional. NOTICE The manufacturer will accept no responsability for any electrical damage resulting from improper installation of this product, be that either damage to the vehicle itself or to the installed device.

  • Page 2: Table Of Contents

    Before begining the installation and setting the configurations of a MyCar Controls unit, we strongly recommend downloading the Application from the App store and create a user account. a. Go to the App store (Apple) or Play store (Android) and Search for “MYCAR CONTROLS”. Download and install the Free Application.

  • Page 3: Hardware Parts

    HARDWARE PARTS HRN-MCAR-01 AR-3HU HRN-LLRS-01 HRN-DRS-01...

  • Page 4: Ads Idatastart Hcx

    The ADS Weblink (ADS-USB) is required to properly configure the iDatastart HC remote starter to accept the MyCar Controls telematics device. When flashing the iDatastart HC remote starter, please ensure to turn ON the Telematics option from the telematics section and choose “MyCar”.
  • Page 5 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 6: Ads Idatastart Vwx

    The ADS Weblink (ADS-USB) is required to properly configure the iDatastart VW remote starter to accept the MyCar Controls telematics device. When flashing the iDatastart VW remote starter, please ensure to turn ON the Telematics option from the telematics section and choose “MyCar”.
  • Page 7 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 8: Ads Idatastart Bm - Bz

    The ADS Weblink (ADS-USB) is required to properly configure the iDatastart BM or BZ remote starter to ac- cept the MyCar telematics device. When flashing the iDatastart BM or BZ remote starter, please ensure to choose the “Drone” telematics protocol.
  • Page 9 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 10: Akx Autokinetix Or Oem

    STEP 1. CONFIGURE THE REMOTE STARTER The ADS Weblink (ADS-USB) is required to properly configure the AKX or OEM remote starter to accept the MyCar telematics device. When flashing the AKX or OEM remote starter, please ensure to choose the “MyCar” telematics protocol.
  • Page 11 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 12: Crimestopper

    SP402,SP502 STEP 1. CONFIGURE THE REMOTE STARTER The CrimeStopper remote starter must be configured to accept the MyCar telematics device. When pro- gramming the CrimeStopper remote starter, please ensure to select the option indicated “Smart Phone Baud Rate”. This option MUST BE SET TO 9600baud.

  • Page 13: Troubleshooting

    Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 14: Firstech Compustar Cm-7200

    The ADS Weblink (ADS-USB) is required to properly configure the Compustar remote starter to accept the MyCar telematics device. When flashing the Compustar remote starter, please ensure the remote starter firmware and BLADE-AL (64) firmwares are updated to the latest firmware available.
  • Page 15 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 16: Firstech Compustar Cm-6200

    The ADS Weblink (ADS-USB) is required to properly configure the Compustar remote starter to accept the MyCar telematics device. When flashing the Compustar remote starter, please ensure the remote starter firmware and BLADE-AL (64) firmwares are updated to the latest firmware available.
  • Page 17 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 18: Firstech Compustar Ft-Dc2

    The ADS Weblink (ADS-USB) is required to properly configure the Compustar FT-DC2 remote starter to accept the MyCar Controls telematics device. When flashing the Compustar FT-DC2 remote starter, please ensure to turn ON the Telematics option from the telematics section and choose “Drone Mobile”.
  • Page 19 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 20: Firstech Compustar Ft-Dc3

    The ADS Weblink (ADS-USB) is required to properly configure the Compustar FT-DC3 remote starter to accept the MyCar Controls telematics device. When flashing the Compustar FT-DC3 remote starter, please ensure to turn ON the Telematics option from the telematics section and choose “Drone Mobile”.
  • Page 21 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 22: Directed Dball 2

    STEP 1. CONFIGURE THE REMOTE STARTER The Directed XKloader 2 or 3 is required to properly configure the DBALL2 remote starter to accept the MyCar telematics device. When flashing the DBALL2 remote starter, please ensure to choose the “Smartstart” telematics protocol.
  • Page 23 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 24: Directed Db3

    STEP 1. CONFIGURE THE REMOTE STARTER The Directed XKloader 2 or 3 is required to properly configure the DB3 remote starter to accept the MyCar telematics device. When flashing the DB3 remote starter, please ensure to choose the “Smartstart” telem- atics protocol.
  • Page 25 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 26: Directed 4X10, 5X10

    STEP 1. CONFIGURE THE REMOTE STARTER The Directed XKloader 2 or 3 is required to properly configure the 4X10 - 5X10 remote starter to accept the MyCar telematics device. When flashing the 4X10 - 5X10 remote starter, please ensure to choose the “Smartstart” telematics protocol.
  • Page 27 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 28: Directed Ds4, Ds4

    STEP 1. CONFIGURE THE REMOTE STARTER The Directed XKloader 2 or 3 is required to properly configure the DS4 / DS4+ remote starter to accept the MyCar telematics device. When flashing the DS4 / DS4+ remote starter, please ensure to choose the “Smartstart” telematics protocol.
  • Page 29 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 30: Fortin Evo-All

    HRN-LLRS-01 STEP 1. CONFIGURE THE REMOTE STARTER The Fortin Flashlink is required to properly configure the EVO-ALL remote starter to accept the MyCar tele- matics device. When flashing the EVO-ALL remote starter, please ensure to choose the following options: - C1 - OEM Remote starter...
  • Page 31 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 32: Fortin Evo-One

    HRN-LLRS-01 STEP 1. CONFIGURE THE REMOTE STARTER The Fortin Flashlink is required to properly configure the EVO-ONE remote starter to accept the MyCar tele- matics device. When flashing the EVO-ONE remote starter, please ensure to choose the following options: Toggle your Flashlink connection mode to “Remote-Starter”. From the top menu click on “Configura- tion”...
  • Page 33 Device Signal icon located above the Stop button will display the connectivity status of your MyCar device. If the icon is Grayed out, Please wait, Device is still Offline. If icon is Green, Device is Online and Ready to go.

  • Page 34: Led Status Reference Chart

    ON Solid Connection is established Connection is established RESET PROCEDURE 1 - Disconnect the main harness from the MyCar device. 2 - Wait approximately 10 seconds and reconnect the main harness to the MyCar device. 3 - Reset procedure Completed.
  • Page 35 INSTALLATION, WIRING & PROGRAMMING GUIDE...
  • Page 36 400 Wright - St-Laurent, Quebec, H4N1M6 - CANADA © 2017 AutoMobility. All rights reserved.
