- Page 1 COMPLETE INSTALLATION & PROGRAMMING GUIDE MYCAR Telematics Communicator This system must be installed by a professional. NOTICE...
- Page 2 manufacturer will accept no responsability for any electrical damage resulting from improper installation of this product, be that either damage to the vehicle itself or to the installed device. This device must be installed by a certified technician. Please review the Installation Guide carefully before beginning any work.
- Page 3 TABLE OF CONTENTS Hardware Parts................ 3 Fortin Evo-All................4 Fortin Evo-One ..............8 Reset Procedure ............... 11...
- Page 4 HARDWARE PARTS HRN-MCAR-01 AR-3HU HRN-LLRS-01 HRN-DRS-01...
- Page 5 HRN-LLRS-01 STEP 1. CONFIGURE THE REMOTE STARTER The Fortin Flashlink is required to properly configure the EVO-ALL remote starter to accept the MyCar tele- matics device. When flashing the EVO-ALL remote starter, please ensure to choose the following op ons: “C1 - OEM Remote starter”, “D1 - 3x Lock start”, “H2 - For n 2”.
- Page 6 When your configurations are all completed, click “Done” at the top right corner. All Configurations will take effect. e. Now please allow a moment for the MyCar device to update your protocol selection and be available to accept commands from the App. In the vehicle control screen, the Device Signal icon located above the Stop button will display the connectivity status of your MyCar device.
- Page 7 7 - Cycle the ignition to the ON position. 8 - The RED, YELLOW and BLUE LED’s will be ON. 9 - Seconds later the RED and BLUE LED’s will blink once to confirm that the MyCar ID has been learned to the Evo-All.
- Page 8 INSTALLATION, WIRING & PROGRAMMING GUIDE...
- Page 9 HRN-LLRS-01 STEP 1. CONFIGURE THE REMOTE STARTER The Fortin Flashlink is required to properly configure the EVO-ONE remote starter to accept the MyCar tele- matics device. When flashing the EVO-ONE remote starter,please ensure to choose the following op ons: Toggle your Flashlink connec on mode to “Remote-Starter”. From the top menu click on “Configura- on”...
- Page 10 When your configurations are all completed, click “Done” at the top right corner. All Configurations will take effect. e. Now please allow a moment for the MyCar device to update your protocol selection and be available to accept commands from the App. In the vehicle control screen, the Device Signal icon located above the Stop button will display the connectivity status of your MyCar device.
- Page 11 RED Led on the side of the EVO-ONE will blink. 7 - Then Press and Release the Brake pedal. 8 - Seconds later the RED LED on the side of the EVO-ONE will blink once to confirm that the MyCar ID has been learned to the EVO-ONE.
- Page 12 INSTALLATION, WIRING & PROGRAMMING GUIDE RESET PROCEDURE 1 - Disconnect the main harness from the MyCar device. 2 - Wait approximately 10 seconds and reconnect the main harness to the MyCar device. 3 - This will complete the reset procedure.
- Page 13 400 Wright - St-Laurent, Quebec, H4N1M6 - CANADA © 2016 MyCar Controls. All rights reserved.
