17-08-13
Micro Smart
Dimmer 2E
manual
The following instructions have been designed to assist in the
installation of the Aeotec by Aeon Labs
Dimmer. Please note that the instructions are for the 2nd
Edition of the Micro Smart Dimmer.
In-Wall Electrical
Installation Instructions:
IMPORTANT
The electricity to the circuit must be shut off during installation
for safety and to ensure that wires are not short circuited
during installation which will cause damage to the Micro
Module.
aeotec.com/z-wave-in-wall-switches/877-micro-sei-2e-manual-instructions.html
Micro Smart Dimmer 2E manual - Aeotec
Z-Wave in wall Smart
1/10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Aeotec 2E
Summary of Contents for Aeotec 2E
- Page 1 17-08-13 Micro Smart Dimmer 2E manual - Aeotec Micro Smart Dimmer 2E manual The following instructions have been designed to assist in the installation of the Aeotec by Aeon Labs Z-Wave in wall Smart Dimmer. Please note that the instructions are for the 2nd Edition of the Micro Smart Dimmer.
- Page 2 17-08-13 Micro Smart Dimmer 2E manual - Aeotec Dismounting In Wall Box. Remove the two screws securing the cover plate. Remove the wall switch cover plate. Remove the two screws securing the wall switch to the wall box. Disconnect both wires from the wall switch.
- Page 3 17-08-13 Micro Smart Dimmer 2E manual - Aeotec Preparing and Connecting Wires The Aeotec Micro Smart Energy Illuminator G2 must first be powered by a 3-wire system in order to operate. The wiring diagram is as follows: Note The “3V Out” terminal should be used only with the Aeon Micro Touch.
- Page 4 17-08-13 Micro Smart Dimmer 2E manual - Aeotec Signal connection – Using two 18 AWG copper wires, connect the terminals of the wall switch to Micro Smart Energy Illuminator G2 as shown. Make sure that the ends of the wires from the wall box are straight (cut if neccessary).
- Page 5 Z-Wave Network Instructions: The Aeotec Micro Smart Energy Illuminator G2 must be paired (included) into a Z-Wave network before it can receive Z-Wave commands to turn on/off/dim and report its energy usage. The Micro Smart Energy Illuminator G2 can only communicate to devices within it’s own Z-Wave network.
- Page 6 Z-Wave network. Adding/Including/Pairing the Micro Smart Energy Illuminator G2 into a Z-Wave Network Press the button labeled “Include” on the Aeotec Minimote to begin the Z-Wave inclusion process. Note To include the Aeotec Micro Smart Energy Illuminator G2...
-
Page 7: Troubleshooting
17-08-13 Micro Smart Dimmer 2E manual - Aeotec Troubleshooting If the Aeotec Micro Smart Energy Illuminator G2 was not successfully included into any Z-Wave network, the LED will be blinking slowly continually. If the Aeotec Micro Smart Energy Illuminator G2 was successfully included to a Z-Wave network, the Status Indication LED will either be solid on or off (depending on if the switch is on or off). - Page 8 If the Aeotec Micro Smart Energy Illuminator G2 was removed from the Z-Wave network, the Status Indication LED will be blinking. If the Aeotec Micro Smart Energy Illuminator G2 was not successfully removed from the Z-Wave network, the Status Indication LED will either be solid on or off (depending on if the switch is on or off).
- Page 9 Change Mode on the External Switch/Button Control The Aeotec Micro Smart Energy Illuminator G2 is set to be controlled via 2-state(flip/flop) external wall switch by default. Pushing and holding the button 6 seconds on the...
- Page 10 17-08-13 Micro Smart Dimmer 2E manual - Aeotec Class. Automatic reports are sent to association group 1, which is setup via the Association Command Class.) Please consult the operation manual for these gateways/controllers for specific instructions on monitoring the Micro Smart Energy lluminator G2.
