Sonnen Protect2500 Operating Instructions

sonnenProtect 2500/AU – Update – Operating Instructions
This document is to be read in conjunction with KD-336 | Part no. 22009 | EN | X01. Product, instruction
and operational details supersede those printed with the sonnenProtect1300 operating instructions.
Document Number
1.2
Designation in this document
2.1
Safety
3.1
Technical Data
Table 2: Technical data
KD-337 | Part no. 22010 | EN | X00/AU
Complete designation
sonnenBatterie eco 8.2
sonnenProtect 2500
eco 8.2/6, 8.2/8, 8.2/10, 8.2/12,
8.2/14, 8.2/16
Intended use
The sonnenProtect 2500 is an emergency power unit designed to
supplement the sonnenBatterie eco 8.2.
System data
Maximum power (2 sec.)
Nominal power
Output voltage (AC)
Nominal frequency
Network configuration in emergency
operation
Operating concept
Switchover time
Dimension / Weight
Dimensions (H/W/D) in mm
Weight in kg
Safety
Protection class
Degree of protection
Protective functions
S o n n e n A u s t r a l i a P t y L t d
1-5 Railway Street, Chatswood
Designation in this document
Storage system
sonnenProtect
Battery capacity range
sonnenProtect 2500
2,500 W
2,500 W
240 V +/- 10 %
50 Hz
TN-C
Single-phase power supply via
plug outlet and/or wired
connection. The switch to
emergency operation takes place
automatically via storage system.
0 sec
235/150/124
approx. 2 kg
IEC 61009-1; AS/NZ 61009-1
IP21
Protective functions Overcurrent
& Earth Leakage
6 0 4 S o u t h T o w e r
NSW 2067
ACN 611 337 547
0408 802 388
