TEMPERATURE SWITCH WITH LOCAL DISPLAY
CONFIGURATION HANDBOOK
THL101
LOREME 12, rue des Potiers d'Etain Actipole BORNY - B.P. 35014 - 57071 METZ CEDEX 3
Phone 03.87.76.32.51 - Telefax 03.87.76.32.52
Contact : Commercial@Loreme.fr - Technique@Loreme.fr
Download manual at : www.loreme.fr
REV 0.0 - 28/09/09
E 1
Advertisement
Table of Contents
Related Manuals for Loreme THL101
Summary of Contents for Loreme THL101
- Page 1 TEMPERATURE SWITCH WITH LOCAL DISPLAY CONFIGURATION HANDBOOK THL101 LOREME 12, rue des Potiers d'Etain Actipole BORNY - B.P. 35014 - 57071 METZ CEDEX 3 Phone 03.87.76.32.51 - Telefax 03.87.76.32.52 Contact : Commercial@Loreme.fr - Technique@Loreme.fr Download manual at : www.loreme.fr REV 0.0 - 28/09/09...
- Page 2 2) Recommendation of use .......................... p5 2.1) General remarks .......................... p5 2.2) Power Supply ..........................p5 2.3) Inputs / Outputs ........................... p5 WIRINGS ................................p6 LOREME 12, rue des Potiers d'Etain - 57071 Metz 03.87.76.32.51 - Fax 03.87.76.32.52 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...
- Page 3 TABLE OF CONTENTS Device Presentation The THL101 is a outdoor field thermostat with local indicator for a PT100 2 or 3 wires input, mounted in an enclosure resistant to harsh environments (> IP65). It brings together on the same circuit functions of measurement, display, and alarm configuration. It consists of:...
- Page 4 If the waiting time for action on the buttons & exceeds 30 seconds then the device automatically returns to meas- urement mode without saving the new settings. LOREME 12, rue des Potiers d'Etain - 57071 Metz 03.87.76.32.51 - Fax 03.87.76.32.52 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...
- Page 5 1) Introduction To meet its policy concerning EMC, based on the Community directives 2014/30/EU & 2014/35/EU, the LOREME company takes into account the standards relative to this directives from the very start of the con- ception of each product. The set of tests performed on the devices, designed to work in an industrial environment, are made in accor- dance with IEC 61000-6-4 and IEC 61000-6-2 standards in order to establish the EU declaration of confor- mity.
- Page 6 Power supply -: terminal 2. Input PT100: terminals 3, 4, 5. Relay 1: terminals 7, 6 Relay 2: terminals 8, 6 LOREME 12, rue des Potiers d'Etain - 57071 Metz 03.87.76.32.51 - Fax 03.87.76.32.52 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...
