TDSUSBF Test Fixture

Specifications

Table 5: Specifications
Specification
Input voltage rating
Power consumption, typical
Fuse rating
Operating temperature
10
This section contains the specifications of the TDSUSBF Test Fixture. All
specifications are guaranteed unless noted as typical. Typical specifications are
provided for your convenience, but are not guaranteed.
Description
+5.0 V DC, ±0.25 V
1 W
0.5 A, 60 V, Polyswitch resettable fuse
+15 °C to +35 °C (59 °F to 95 °F)
TDSUSBF USB 2.0 Compliance Test Fixture Instructions
