User Manual for your
4 burner gas hob
5 burner gas hob
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
CL64SS/W
CL66SS
CL75SS
CL90SS
GS 21/12/10
1
Advertisement
Table of Contents
Related Manuals for Applico CL64SS
Summary of Contents for Applico CL64SS
- Page 1 User Manual for your CL64SS/W CL66SS 4 burner gas hob CL75SS CL90SS 5 burner gas hob NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 2: Table Of Contents
Contents Enviro nmental note Important safety information 4 – 6 Specifications 7 – 12 CL64SS/W CL66SS CL75SS CL90SS Electrical details Gas details Gas hob surface layouts 11 - 12 Using the gas hob 13 - 15 Before first use Switching the hob on... -
Page 3: Environmental Note
Environmental note o The packaging materials that we use are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 4: Important Safety Information
Important safety information Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact... - Page 5 Repairs may only be carried out by an Authorised Service Agent. Log onto www.applico.co.nz to locate a Service Agent nearest to you. Child Safety o We strongly recomm end that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time.
- Page 6 Cleaning o Cleaning of the hob should be carried out on a reg ular basis. o IMPORTANT: Before attempting to clean the appliance, it should be disconnected from the m ains and cool. o Great care should be taken whilst using this appliance and when following the cleaning procedure.
-
Page 7: Specifications
CL64SS/W Product dimensions: Aperture dimensions: Depth: 510 mm Depth: 480 mm Width: 595 mm Width: 550 mm Height: 30 mm Product specifications: o 1 x 3.30 kW rapid burne o 2 x 1.75 kW semi-rapid burner o 1 x 1.00 kW auxiliary b... -
Page 8: Cl66Ss
CL66SS Product dimensions: Aperture dimensions: Depth: 510 mm Depth: 480 mm idth: 595 mm Width: 550 mm Height: 30 mm Product specifications: o 1 x 3.60 kW rapid burner 2 x 1.75 kW semi-rapid burner o 1 x 1.00 kW auxiliary bu rner o Front control operation o Automatic ignition... -
Page 9: Cl75Ss
CL75SS Product dimensions: Aperture dimensions: Depth: 500 mm Depth: 480 mm idth: 740 mm Width: 550 mm Height: 30 mm Product specifications: o 1 x 4.20 kW triple crown wok bu rner o 1 x 3.30 rapid burner 2 x 1.75 kW semi-rapid burner o 1 x 1.00 kW auxiliary bu rner o Front control operation... -
Page 10: Cl90Ss
CL90SS Product dimensions: Aperture dimensions: Depth: 510 mm Depth: 480 mm idth: 860 mm Width: 830 mm Height: 40 mm Product specifications: o 1 x 4.20 kW triple crown wok bu rner o 1 x 3.30 rapid burner 2 x 1.75 kW semi-rapid burner o 1 x 1.00 kW auxiliary bu rner o Front control operation... -
Page 11: Electrical Details
Model Number ………………………………. Serial Number ………………………………. ate of Purchase ………………………………. Gas hob sur face layout CL64SS/W A) 3.30 kW rapid burne B) 1.75 kW semi-rapi burner C) 1.00 kW auxiliary burner D) Control... - Page 12 L66SS A) 3.60 kW triple crown wok burner B) 1.75 kW semi- rapid burner C) 1.00 kW auxiliary burner D) Control panel L75S S / CL90SS A) 4.20 kW triple crown wok burner B) 3.30 kW rapid burner C) 1.75 kW semi-rapid burner D) 1.00 kW auxiliary burner E) Control panel...
-
Page 13: Using The Gas Hob
The symbol on the control panel, next to the control knob will indicate which gas burner it operates. Automatic ignition (CL64SS/W) To ignite a burner: Press in the control knob of the burner that you wish to light a turn it anti-clockwise to the maximum position. -
Page 14: Automatic Ignition With Flame Failure Safety Device
o In case of power failure, the burners can be lit by carefully using a match. utomatic ignition with flame failure safety device (CL66SS / CL75SS / CL90SS) The appliance is fitted with a flame failure safety device on each burner, which is designed to stop the flow of gas to th e burner head in e event of the flame going out. -
Page 15: Cleaning
o The burner flame must never extend beyond the diametre of the pan. o Use flat bottomed pans only o When possible, keep a lid on the pan whilst cooking. o Cook vegetables with as little water as possible, to reduce cooking times. -
Page 16: Cleaning The Hob Burners
o We would recommend that an appropriate neutral and non- flammable detergent is used to clean the glass surface of the hob. Cleaning the hob burners The hob burners should be cleaned once a week or more frequently if they get soiled. o IMPORTANT: Make sure that the hob surface, pan stands and hob burners have cooled before you attempt to touch them. -
Page 17: Installation
Installation installation must carried Authorised Service Agent, in accordance with the current version of the following. o AS/NZS 3000:2007 Wiring Regulations o 2010 Electricity Safety Regulations Positioning The adjacent furniture must be able to withstand a minimum temperature rise of 85°C above the ambient temperature of the room it is located in, during periods of use. -
Page 18: Installing The Appliance
Clamps ealing strip LPG conversion jets Self-adhesive label for amending the gas category on the appliance’s rating plate (required if the LPG conversion jets are used). Installing the appliance CL64SS/W CL66SS... - Page 19 CL75SS L90SS o Cut a ho le in the worktop that corresponds with the illustration above. o IMPORTANT: You must have a gap of at least 25 mm between the underneath of the appliance and any surface that is below it.
- Page 20 o Carefully turn the hob upside down and place it on a cushioned mat. o Apply the sealing strip (A) provided around the edge of the appliance. o The protective covering must be removed from both sides. o Do not leave a gap in the sealing agent or overlap the thickness. o IMPORTANT: Do not use a silicon sealant to seal the appliance against the aperture.
-
Page 21: Gas Connection
o On the underneath of the hob, adjust the clamps into a position that is suitable for your worktop. Then fully tighten the screws (C) to secure the hob into position. Gas connection This appliance must be installed by a competent person in accordance with the current versions of the followi o AS / NZS 3000:2007 Wiring Regulations... -
Page 22: Gas Safety (Installation And Use) Regulations
o If there are any other fuel burning appliances in the same room the current edition of BS 5440: Part 2: should be consulted to determine air vent requirements. o Ensure that the room containing the hob is well ventilated, keep natural ventilation holes or install a mechanical ventilation device (mechanical cooker hood). -
Page 23: Gas Adjustment (Conversion To Lpg)
o Put the gas seal into the elbow. o Fully tighten the elbow and seal onto the gas rail. o The elbow MUST be pointing in a downwards direction. o Gas pressure may be checked on a semi-rapid hob burner. Remove the appropriate injector and attach a test nipple. -
Page 24: Minimum Flow Adjustment For Hob Gas Taps
GENERAL INJECTORS TABLE Kind of gas Ø injectors Burners Power (MJ/h) MIN-MAX Natural 1.55 Rapid 3.6-12.0 0.90 Auxiliary 1.48-4.0 1.18 Semi-rapid 2.0-7.0 1.60 Wok (3.60 kW) 6.0-13.2 1.75 Wok (4.20 kW) 6.0-15.2 L.P.G. 0.90 Rapid 3.33-11.1 Butane 0.53 Auxiliary 1.37-3.7 Propane 0.69 Semi-rapid... -
Page 25: Gas Tap Maintenance
o For butane/propane gas, the adjusting screw must be tightly screwed in. o Refit the control knob. o Make sure that the flame does not go out by quickly turning from maximum flow to minimum flow. If it does then remove the control knob and make further adjustments to the gas flow, testing it again once the adjustment has been made. -
Page 26: Electrical Connection
Electrical connection This appliance must be installed by a qualified person in accordance with Applico’s instructions. Before connecting the appliance, make sure that the supply voltage marked on the rating plate corresponds with your mains supply volt age. -
Page 27: My Appliance Isn't Working Correctly
Or any installation other than the one specified by Applico Ltd. has been completed. Please refer to the conditions of guarantee that appear on the warranty card that you receive with the appliance.
