Summary of Contents for Itouchless RV003A
- Page 1 RV003A USER MANUAL...
-
Page 2: Table Of Contents
Warnings Instructions for use shall be provided with the appliance so that appliance can be used safely. The plug must be removed from the socket-outlet before cleaning or maintaining the appliance. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the... -
Page 3: Safety Instruction
Thank you for your purchase! We’re sure you will love your new Robot Vacuum Cleaner with Remote Control (RV003A) If you have any questions, contact iTouchless Customer Support at (844) 660-7978 or customersupport@itouchless.net 1.Safety Instructions 1.1 Use Notes Before using the product, please observe the following safety precautions:... - Page 4 Do not remove the adapter from the electric socket by pulling on the wire, and do not bend the wire or place any object on top of it. Do not place the cleaner near fire, flammable items, explosive items, or corrosive materials. Do not place any part of your clothing or body (hair, fingers, etc.) near the main brush or wheels, as this may cause personal injury Attention...
-
Page 5: Child Safety
1.3 Child Safety 1.4 About Battery 1. Only the original battery must be used. 2. The battery must be removed before discarding the cleaner. 3. If you wish to replace the battery, contact our Customer Support team for detailed instructions. * The cleaner should not be used by children. -
Page 6: Product Formation
2. Product Formation 2.1 Main Body and Accessories Battery Remote Control Main Body *1pc *1pc Adaptor Filter Side Brush Cleaning Brush *1pc *2pcs *2pcs *1pc Screwdriver *1pc Tip: * The battery, side brush, and filter are pre-installed. A replacement side brush and filter are included in the packaging. -
Page 7: Accessories Introduction
2.2 Accessories Introduction Top View Dustbin Control Buttons Top Cover Charging Electrodes Wall Detection Sensors Bottom View Battery Pack Left Side Brush Left Wheel Front Ground Wheel Detection Sensors Middle Rubber Brush Right Middle Bristle Side Brush Brush Front Shell Dust Chamber Right Wheel Dustbin... -
Page 8: Product Installation
3.Product Installation 3.1 Installing the Battery Installation: Removal: 1. Place the cleaner on the ground so that the 1. Push the side tabs in and pull up on bottom is facing up. the battery. 2. Place the battery into the battery compartment until the side tabs click into place. -
Page 9: Product Usage
4.Product Usage 4.1 How to use the robot 4.1.1 Introduction to Control Buttons Control Buttons Button instructions: Timed Cleaning Mode button: 1. In Standby Mode, the indicator light While in Standby Mode, press the "II" will remain solid. When the cleaner is in button to begin the Timed Cleaning one of the three cleaning modes, the Mode. -
Page 10: Remote Control
4.2 Remote Control Power Button When the cleaner is in Standby Mode, press the 局部清扫/星期六 Power Button to power the cleaner off. SPOT CLEAN Power When a button is pressed on the Remote Control, Indicator the Power Indicator will light up. FORWAED While in Standy Mode, press the "SPOT"... -
Page 11: Product Maintenance
5. Product Maintenance Tip: Clean the vacuum routinely to maintain optimal performance. 5.1 Daily Storage When the cleaner is not in use, power the cleaner off to preserve battery effectiveness. ON/OFF If the cleaner has not been used for an extended period of time, charge the battery fully and clean the bottom of the vacuum. -
Page 12: Cleaning The Filter
5.4 Cleaning the Filter 1. Press the tab in to release the filter 2. Push the tabs out to remove the filter from compartment and remove it from the dustbin. the filter compartment. 3. Use the Cleaning Brush to gently brush away dust. You may also run the filter under cold water. If you washed the filter, allow it to try completely. -
Page 13: Cleaning The Side Brush
3. Remove the Main Brush from the 4. To return the Main Brush, set it back into the compartment. compartment and push the arm down until the tab clicks. 5.5.2 Cleaning the Middle Bristle Brush or Middle Rubber Brush 1. To clean the Middle Bristle Brush or 2. -
Page 14: Clean The Wheels
5.7 Cleaning the Dust Chamber 1.Turn the cleaner upside down 2. Gently brush dust out of the 3. Put the plate cover back in and press the tabs of the plate chamber using the Cleaning place and push in until the tabs cover in to release the plate Brush. -
Page 15: Troubleshooting Guide
2. Check to see if the dustbin is full and needs to be emptied. are flashing Tip: If you cleaner is still experiencing problems after following the above suggestions, please contact iTouchless Customer Support. - 14 -... -
Page 16: Technical Specifications
7.Technical Specifications Main Body Parameters Accessories Parameters Adaptor Working Voltage DC14.4 V Output Voltage DC24V Rated Power 23 W Battery Output Current 600mA Ni-MH Battery Capacity 1700mAh Remote Control Remote Distance Charging Time About 4-5 Hours Battery AAA alkaline Batteries *2 Working Time About 60 min Work Temp Range... - Page 17 ™ Robot Vacuum Cleaner (Cleaner $19.95 and 23783 Eichler Street, Units A - C, Hayward, CA 94545 © 2017...
