SCALANCE W788-x / W748-1
SIMATIC NET
Industrial Wireless LAN
SCALANCE W788-x / W748-1
Operating Instructions
06/2016
A5E03678333-10
___________________
Information on the Internet
___________________
Introduction
___________________
Security recommendations
___________________
Description
___________________
Mounting
___________________
Connecting up
___________________
Technical specifications
___________________
Dimension drawings
___________________
Certification
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents
loading

Related Manuals for Siemens SCALANCE W788-1

Summary of Contents for Siemens SCALANCE W788-1

  • Page 1 ___________________ SCALANCE W788-x / W748-1 Information on the Internet ___________________ Introduction ___________________ SIMATIC NET Security recommendations ___________________ Description Industrial Wireless LAN SCALANCE W788-x / W748-1 ___________________ Mounting ___________________ Connecting up Operating Instructions ___________________ Technical specifications ___________________ Dimension drawings ___________________ Certification 06/2016 A5E03678333-10...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Contents Information on the Internet ........................5 Introduction ............................. 7 Information on the Operating Instructions ................7 Structure of the type designations .................... 8 Security recommendations ........................9 Description ............................13 Components of the product ....................13 Description of the device ......................14 LED display ..........................
  • Page 4 Contents SCALANCE W788-x / W748-1 Operating Instructions, 06/2016, A5E03678333-10...

  • Page 5: Information On The Internet

    Information on the Internet Bitte beachten Sie die Warnhinweise und zusätzlichen Informationen in der Kompaktbetriebsanleitung in Ihrer Sprache im Internet: http://support.automation.siemens.com/ww/view/at/10806097 http://support.automation.siemens.com/ww/view/ch/10806097 http://support.automation.siemens.com/ww/view/de/10806097 http://support.automation.siemens.com/ww/view/li/10806097 http://support.automation.siemens.com/ww/view/lu/10806097 Please observe the warnings and additional information in the compact operating instructions in your language in the Internet: http://support.automation.siemens.com/ww/view/au/10806097...
  • Page 6 Information on the Internet http://support.automation.siemens.com/ww/view/hk/10806097 http://support.automation.siemens.com/ww/view/sg/10806097 Kérjük, vegye figyelembe az interneten található, az Ön anyanyelvén íródott kompakt használati útmutatóban található figyelmeztetéseket és további információkat: http://support.automation.siemens.com/ww/view/hu/10806097 Skoðið vel viðvaranir og aðrar upplýsingar í notkunarleiðbeiningunum á ykkar tungumáli á internetinu: http://support.automation.siemens.com/ww/view/is/10806097 インターネットサイトにある各言語の注意事項および追加情報を参照してください: http://support.automation.siemens.com/ww/view/jp/10806097...

  • Page 7: Introduction

    Information on the Operating Instructions Validity of the Operating Instructions These operating instructions cover the following products: Article no. of the RoW version Article no. of the US version Access points SCALANCE W788-1 RJ-45 6GK5788-1FC00-0AA0 6GK5788-1FC00-0AB0 SCALANCE W788-1 M12 6GK5788-1GD00-0AA0 6GK5788-1GD00-0AB0...

  • Page 8: Structure Of The Type Designations

    In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial security concept. Siemens’ products and solutions only form one element of such a concept. Customer is responsible to prevent unauthorized access to its plants, systems, machines and networks.

  • Page 9: Security Recommendations

    ● Keep the software up to date. Check regularly for security updates of the product. You will find information on this on the Internet pages "Industrial Security (http://www.siemens.com/industrialsecurity) " ● Inform yourself regularly about security advisories and bulletins published by Siemens ProductCERT. ● Only activate protocols that you really require to use the device.
  • Page 10 Security recommendations ● If RADIUS authentication is via remote access, make sure that the communication is within the secured network area or is via a secure channel. ● The option of VLAN structuring provides good protection against DoS attacks and unauthorized access.
  • Page 11 Security recommendations Secure/non-secure protocols ● For the DCP function, enable the "DCP read-only" mode after commissioning. ● Avoid and disable non-secure protocols, for example Telnet and TFTP. For historical reasons, these protocols are still available, however not intended for secure applications. Use non-secure protocols on the device with caution.
  • Page 12 Security recommendations ● Port status – Open The port is always open and cannot be closed. – Open (when configured) The port is open if it has been configured. Note With some protocols the port may be open although the corresponding protocol is disabled, for example TFTP.

  • Page 13: Description

    ● SIMATIC NET Industrial Wireless LAN CD Please check that the consignment you have received is complete. If the consignment is incomplete, contact your supplier or your local Siemens office. Note The bracket for installation on a DIN rail does not ship with the product. You obtain a set of 3 under the following order number: 6GK5 798-8ML00-0AB3.

  • Page 14: Description Of The Device

    Description 4.2 Description of the device Description of the device W7x8x-x RJ-45 - degree of protection IP30 ① LEDs ② Connecting connectors, R-SMA type female Devices with one IWLAN interface: 3 connectors on the top (covered in the figure). • Devices with two IWLAN interfaces: 3 connectors on the top and 3 on the underside.
  • Page 15 Description 4.2 Description of the device W7x8x-x M12 - degree of protection IP65 ① Connecting connectors, N-Connect type female Devices with one IWLAN interface: 3 connectors on the top (covered in the figure). • Devices with two IWLAN interfaces: 3 connectors on the top and 3 on the underside. •...

  • Page 16: Led Display

    Description 4.3 LED display LED display Information on operating status and data transfer On the front of the housing, several LEDs provide information on the operating status of the SCALANCE W7x8: LEDs with RJ-45 variants LEDs with M12 variants Note The "R2"...
  • Page 17 Description 4.3 LED display Color Meaning SCALANCE W7x8 in access point mode: Flashing fast yellow With 802.11h, the channel is scanned for one minute for primary users before the channel can be used for data traffic. SCALANCE W7x8 in client mode: The client waits for the MAC address due to the setting "Automatic"...

  • Page 18: Reset Button

    Description 4.4 Reset button Reset button The Reset button is located behind the screw-down cover on the underside of the housing. The button has several functions: ● Restart of the device To restart the device, press the Reset button briefly. Note If you make changes to the configuration and restart immediately afterwards with the reset button, the changes may be lost.

  • Page 19: Mounting

    Mounting CAUTION Minimum distance to antennas Fit the device so that there is a minimum clearance of 20 cm between antennas and persons. WARNING If a device is operated in an ambient temperature of more than 50 °C, the temperature of the device housing may be higher than 70 °C.

  • Page 20: Securing The Housing

    Mounting 5.1 Securing the housing Securing the housing Grounding connector WARNING Operation of the W7x8 only with connected grounding cable To operate the SCALANCE W7x8 safely, the housing must make contact with a grounding cable. Do not use the SCALANCE W7x8 without a grounding cable connected. The grounding cable is fixed to the housing with a screw.
  • Page 21 Mounting 5.1 Securing the housing Installation location There are no restrictions regarding the installation location for the device. Antennas, in particular directional antennas, must be mounted according to their characteristics. Note - If you are installing outdoors, use the SCALANCE W786. - The minimum distance to fluorescent lamps should be 0.5 m.

  • Page 22: Wall Mounting

    Mounting 5.2 Wall mounting Wall mounting Use the holes in the housing to screw the device to the wall or on a horizontal surface. The location of the holes can be seen in the following figure: Figure 5-1 Drilling pattern (dimensions in mm) SCALANCE W788-x / W748-1 Operating Instructions, 06/2016, A5E03678333-10...

  • Page 23: Installing On The S7-300 Standard Rail

    Mounting 5.3 Installing on the S7-300 standard rail Installing on the S7-300 standard rail Follow the steps below to install the SCALANCE W7x8 on a vertical S7-300 rail: 1. Place the device on the upper edge of the S7-300 standard rail (position A). 2.

  • Page 24: Installing On A Din Rail

    Mounting 5.4 Installing on a DIN rail Installing on a DIN rail The SCALANCE W7x8 is suitable for rail mounting on 35 mm DIN EN 50022 rails. Bracket for DIN rail mounting Note The bracket for installation on a DIN rail does not ship with the product. You obtain a set of 3 under the following order number: 6GK5 798-8ML00-0AB3.
  • Page 25 Mounting 5.4 Installing on a DIN rail Installing on the DIN rail The following figure shows the W7x8 mounted on a DIN rail. Follow the steps outlined below: 1. Place the device on the upper edge of the DIN rail (position A). 2.
  • Page 26 Mounting 5.4 Installing on a DIN rail SCALANCE W788-x / W748-1 Operating Instructions, 06/2016, A5E03678333-10...

  • Page 27: Connecting Up

    Connecting up Lightning protection, power supply and grounding Lightning protection WARNING Danger due to lightning strikes Antennas installed outdoors must be within the area covered by a lightning protection system. Make sure that all conducting systems entering from outdoors can be protected by a lightning protection potential equalization system.
  • Page 28 Connecting up 6.1 Lightning protection, power supply and grounding Note We recommend that you use the maintenance-free lightning protector LP798-2N. Exception: When there is also DC power supplied via the antenna cable. In this case, only the lightning protector LP798-1N can be used. WARNING Danger due to lightning strikes Installing this lightning protector between an antenna and a SCALANCE W700 is not...
  • Page 29 Connecting up 6.1 Lightning protection, power supply and grounding Grounding WARNING Danger to life from overvoltage, fire hazard When using outdoor antennas, the shared or even grounded pin of the circuit must be connected to the shield of the coaxial cable and with all touchable conductive parts and circuits.
  • Page 30 Connecting up 6.1 Lightning protection, power supply and grounding General notes on use according to ATEX and IECEx WARNING Take measures to prevent transient voltage surges of more than 40% of the rated voltage. This is the case if you only operate devices with SELV (safety extra-low voltage). General notes on use in hazardous areas according to UL-HazLoc WARNING EXPLOSION HAZARD...

  • Page 31: Power Supply And Ethernet

    Connecting up 6.2 Power supply and Ethernet Power supply and Ethernet Connecting the power supply Models RJ-45 / degree of protection IP30 The four-pin connecting socket has the following pin assignment: Signal Description 24 VDC Ground Ground 24 VDC The M12 socket for the power supply has the following pin assignment: Signal Description 24 VDC...
  • Page 32 Connecting up 6.2 Power supply and Ethernet Note Grounding connector The device has a grounding connector on the back of the device (screw M4). Connect the grounding cable before you mount the device. Refer to the information in the section Mounting (Page 19).

  • Page 33: Antenna Connectors

    Connecting up 6.3 Antenna connectors Antenna connectors R-SMA for degree of protection IP30 The variants of the SCALANCE W7x8 RJ-45 have antenna sockets of the type R-SMA: ● Variants with an IWLAN interface (W7x8-1) have 3 antenna sockets on the top of the device.
  • Page 34 Connecting up 6.3 Antenna connectors N-Connect for degree of protection IP65 The variants of the SCALANCE W7x8 M12 have antenna sockets of the type N-Connect: ● Variants with an IWLAN interface (W7x8-1) have 3 antenna sockets on the top of the device.
  • Page 35 Connecting up 6.3 Antenna connectors ① R1A1 ② R1A2 ③ R1A3 ④ R2A1 ⑤ R2A2 ⑥ R2A3 Figure 6-2 Antenna connector IP65 SCALANCE W788-x / W748-1 Operating Instructions, 06/2016, A5E03678333-10...

  • Page 36: Suitable Antenna Cables And Antennas

    Connecting up 6.4 Suitable antenna cables and antennas Suitable antenna cables and antennas N-Connect/R-SMA connecting cable for RJ-45 The N-Connect/R-SMA male/male flexible connecting cable is available as an accessory for connecting to a SCALANCE W700 with R-SMA connectors. Length Order number 0.3 m 6XV1875-5CE30 6XV1875-5CH10...
  • Page 37 Connecting up 6.4 Suitable antenna cables and antennas Connecting cable IWLAN QMA/N-Connect male/female Flexible adapter cable of antennas with QMA socket for antenna connecting cable. pack of 3 Length Order number 6XV1875-5JH10 For railway applications, the following cables are available: Scope of delivery: Pack of 1 Length Order number 6XV1875-5VH10...
  • Page 38 Connecting up 6.4 Suitable antenna cables and antennas Type Properties Order number ANT795-4MA Omni antenna, directly on the de- 6GK5 795-4MA00-0AA3 vice, 3/5 dBi 2.4 GHz and 5 GHz, IP30, R-SMA connector male for direct mounting on the device, connector angle adjustable 0° to 180°.
  • Page 39 Connecting up 6.4 Suitable antenna cables and antennas NOTICE ANT795-4MA The ANT795-4MA antenna has degree of protection IP30 and is therefore only suitable for dry environments. Note ANT793-8DJ The antenna ANT793-8DJ may only be used with the antenna cable 6XV1875-5CH50 (5 m length) or 6XV1875-5CN10 (10 m length).

  • Page 40: Digital Input/Output

    Connecting up 6.5 Digital input/output Digital input/output A digital input/output is only available with the RJ-45 variants. The digital input/output (relay contact) is a floating switch with which error/fault states can be signaled by breaking the contact. NOTICE Damage due to voltage being too high or too low The voltage at the digital input/output must not exceed 30 VDC and not fall below -30 VDC, otherwise the digital input/output will be destroyed.

  • Page 41: Replacing The Plug (C-Plug Or Key-Plug)

    Connecting up 6.6 Replacing the PLUG (C-PLUG or KEY-PLUG) Replacing the PLUG (C-PLUG or KEY-PLUG) How it works If a new C-PLUG or KEY-PLUG with a valid license is inserted in a SCALANCE W7x8, the configuration stored locally on the device is saved on the PLUG. If an incorrect PLUG, for example from another product or a damaged plug is inserted, the device signals an error with the red LED.
  • Page 42 Connecting up 6.6 Replacing the PLUG (C-PLUG or KEY-PLUG) Removing the PLUG Follow the steps below to remove a PLUG from the device: 1. Turn off the power to the device. 2. Remove the cover of the PLUG on the underside of the device. 3.

  • Page 43: Technical Specifications

    Technical specifications Technical specifications of the SCALANCE W7x8-1) The following technical specifications apply to the following devices: ● SCALANCE W788-1 RJ45 ● SCALANCE W788-1 M12 ● SCALANCE W748-1 RJ45 ● SCALANCE W748-1 M12 Note Bridging a power outage is possible only with an input voltage of 24 VDC (-15% to +20%).
  • Page 44 Technical specifications 7.1 Technical specifications of the SCALANCE W7x8-1) Technical specifications Permitted cable lengths (Ethernet) (Alternative combinations per length range) 0 ... 55 m Max. 55 m IE TP Torsion Cable with IE FC RJ45 Plug 180 • Max. 45 m IE TP Torsion Cable with IE FC RJ45 + 10 m TP Cord via •...
  • Page 45 Technical specifications 7.1 Technical specifications of the SCALANCE W7x8-1) Technical specifications Current consumption At 24 VDC / max. 650 mA Effective power loss At 24 VDC / max. 15.6 W At 24 VDC / typical 10.7 W Digital input Quantity Design Terminal block, 2 terminals Status "0"...

  • Page 46: Technical Specifications Of The Scalance W7X8-2)

    Technical specifications 7.2 Technical specifications of the SCALANCE W7x8-2) Technical specifications of the SCALANCE W7x8-2) The following technical specifications apply to the following devices: ● SCALANCE W788-2 RJ45 ● SCALANCE W788-2 M12 ● SCALANCE W788-2 M12 EEC Note Bridging a power outage is possible only with an input voltage of 24 VDC (-15% to +20%). Note You will find detailed information on the transmit power and receiver sensitivity in the document "Leistungsdaten 802.11abgn PCIe Minicard / Characteristics 802.11abgn PCIe...
  • Page 47 Technical specifications 7.2 Technical specifications of the SCALANCE W7x8-2) Technical specifications Permitted cable lengths (Ethernet) (Alternative combinations per length range) 0 ... 55 m Max. 55 m IE TP Torsion Cable with IE FC RJ45 Plug 180 • Max. 45 m IE TP Torsion Cable with IE FC RJ45 + 10 m TP Cord via •...
  • Page 48 Technical specifications 7.2 Technical specifications of the SCALANCE W7x8-2) Technical specifications Fusing 2.5 A / 24 VDC 1 A / 48 VDC PoE Current consumption At 24 VDC / max. 650 mA Effective power loss At 24 VDC / max. 15.6 W At 24 VDC / typical 15 W...

  • Page 49: Dimension Drawings

    Dimension drawings The following dimensions are specified in mm. Dimension drawing of the SCALANCE W7x8-2 RJ45 (degree of protection IP30) Figure 8-1 Front view RJ-45 Figure 8-2 View from above RJ-45 SCALANCE W788-x / W748-1 Operating Instructions, 06/2016, A5E03678333-10...
  • Page 50 Dimension drawings Dimension drawing of the SCALANCE W7x8-2 M12 (degree of protection IP65) Figure 8-3 Front view M12 Figure 8-4 View from above M12 SCALANCE W788-x / W748-1 Operating Instructions, 06/2016, A5E03678333-10...

  • Page 51: Certification

    Certification You will find the approvals of the products in the reference work "Approvals SCALANCE W700 802.11n" on the Internet pages of Siemens Industry Online Support: ● Using the search function: support.automation.siemens.com (http://support.automation.siemens.com/WW/view/en) Enter the entry ID of the relevant manual as the search item.
  • Page 52 Certification SCALANCE W788-x / W748-1 Operating Instructions, 06/2016, A5E03678333-10...

  • Page 53: Index

    Index Protective caps, 13 Antenna cables, 36 Antennas, 36 Reset button, 18 Article numbers, 7 Resetting the device, 18 Restart of the device, 18 Cables Permitted lengths, 43, 46 Safety extra low voltage, 27, 28 Connectors, 13 Scope of delivery, 13 SELV, 27 Supply voltage, 28 Dimension drawings, 49...
  • Page 54 Index SCALANCE W788-x / W748-1 Operating Instructions, 06/2016, A5E03678333-10...
