Using the Reset Button

Types of LAN Connections

Types of WAN Connections

90453-02 Rev A0
With the NetBlazer's power on and a diskette in the floppy diskette drive,
you can reset the NetBlazer by pressing the reset button on the front panel
instead of using the power switch on the back panel.
The NetBlazer Combo Board connects to an Ethernet LAN through one of
three interface types: the 10Base2 BNC connector, the 10Base5 DB-15 AUI
connector, or the 10Base-T RJ-45 connector.
The NTR Token Ring Board connects to the LAN using either the RJ-45
UTP connector or the DB-9 STP connector.
The NS1 single-port synchronous board supports RS-232, RS-449, and
V.35 interfaces at speeds up to 57.6 Kbps.
The SYNxxx dual-port synchronous board supports RS-232, RS-449,
RS-530, V.35, and X.21 interfaces. On each card, both ports are rated up to
2.048 Mbps.
The NM8 multiport asynchronous board supports RS-232 interfaces at
speeds up to 57.6 Kbps.
The ASYN8 multiport asynchronous board supports RS-232 interfaces at
speeds up to 115.2 Kbps.
The NI2B Dual-Port ISDN BRI board supports four ISDN B channel
connections at speeds of 56Kbps or 64Kbps.
The NI1P ISDN PRI board supports 23 T1 (or 30 E1) ISDN B channel
connections at speeds of 56Kbps or 64Kbps.
NetBlazer Installation 2-5
