- Page 1 360, T32 & T56 NOMAD ® 200-900 | 200-900-TC | 200-9T32 | 200-9T56 PRODUCT MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Reference Guide Overview Physical Characteristics BATTERY Charging the Battery System Charging from a 12VDC Vehicle Adaptor Charge Indicator OPERATION AC-DC Adaptor and International Use Operational Modes Battery Life Battery Life Indicator Using the Nomad while Plugged in ®... -
Page 3: Reference Guide
360 REFERENCE GUIDE DEPLOYED VIEW SLIDING DIFFUSER LENS (3) (AREA-SPOT) LIGHT HEAD TIL T ADJUSTMENT KNOB SWIVEL ADJUSTMENT KNOB (340º) TRIPO-SCOPE ® TIGHTENING RINGS TRIPO-SCOPE ® POLES LEVEL BUBBLE PROTECTIVE LIGHT CAP LOCKING SLEEVE CARRY STRAP BATTERY SYSTEM/ CLIP BATTERY LIFE/ NOMAD BODY ®... -
Page 4: Overview
OVERVIEW The Nomad 360 ultimate scene light can provide up to 7,000 lumens on HIGH ® Power. Its portable, submersible and self-contained design allows it to travel to (and be used in) places that standard scene lights and vehicle mounted lights cannot reach. -
Page 5: Charging The Battery System
CHARGING THE BATTERIES Start with the AC Cable. Connect it to the AC-DC Adaptor. The AC Cable is Universal to NEMA 5-15P , 3 prong for USA and will work with a power range of 100VAC–240VAC 50/60 Hz. Then, plug the Barrel Connector (part of the AC-DC Adaptor) into the Charging Port of the Nomad ®... -
Page 6: Ac-Dc Adaptor And International Use
AC-DC ADAPTOR AND INTERNATIONAL USE The Nomad Series has a AC-DC Adaptor which uses AC Cables like those ® used in desktop computers or monitors. With every Nomad , FoxFury supplies ® a cable that terminates in the USA standard 110 VAC plug. BARREL CONNECTOR CONNECTOR (FEMALE) (C13 IEC) -
Page 7: Battery Life
BATTERY LIFE BATTERY MODE LIFE LUMENS LUMENS LUMENS HIGH POWER 3 hrs 7,000 7,000 8,200 MEDIUM POWER 9 hrs 2,100 2,800 3,200 LOW POWER 24 hrs FLASHING 10 hrs 7,000 *Battery life may vary according to age and ambient conditions. **Flashing Mode not available on the Nomad®... -
Page 8: Features
FEATURES LIGHT HEAD CONFIGURATION The Nomad Light Head has the versatility to be used in a 360 or Directional ® configuration. DIRECTIONAL SLIDING DIFFUSER LENS (AREA-SPOT) Using the Sliding Diffuser Lens on the Nomad provides two types of lights ® in one. -
Page 9: Swivel And Tilt Light Head
SWIVEL AND TIL T LIGHT HEAD The Nomad Light Head has the versatility to swivel (via the Swivel ® Adjustment Knob) and tilt (via the Tilt Adjustment Knob). LEVELING LEG EXTENSIONS AND LEVEL BUBBLE On uneven ground, fine adjustments can be made by releasing the Leveling Leg Extensions. -
Page 10: Deploying The Nomad
DEPLOYING THE NOMAD ® LEGS LOCKED LEGS RELEASED TIL T HINGE ADJUSTMENT SCREW KNOB LIGHT HEAD (SIDE VIEW) LEVELING LEG EXTENSION RELEASED... - Page 11 Set the Nomad down vertically , on a flat surface, as shown. Open the ® Protective Light Cap and twist the Locking Sleeve to the right ( ) and slide upwards ( ). While still holding the Locking Sleeve up, twist it back to the left ( ).
-
Page 12: Accessories (Not Included)
NOMAD ACCESSORIES ® MOUNT CLAMPS (SET OF TWO (2) P/N 850-800) These allow the Nomad to be mounted to any hard surface such as a tailgate ® or wall via #10 Bolts (not included). MAINTENANCE REMOVING THE BATTERY TUBES | 15 MINS (APPROX) The Nomad uses 12 Battery Tubes. - Page 13 Make sure the Nomad is OFF and UNPLUGGED before starting. ® Open the Folding Tripo-Scope Legs so they are locked and deployed. ® Then, locate a Battery Cover. Use a Phillips Head ( + ) Screwdriver to remove the four (4) screws that hold the Battery Cover.
- Page 14 INSTALLING THE BATTERY TUBES | 15 MINS (APPROX) Installing the Nomad Battery Tubes follows the same procedures as removing ® them but in reverse order. RED CAP (POSITIVE + ) LOWER BATTERY TUBE UPPER BATTERY TUBE BATTERY TUBE PLACEMENT WHILE INSTALLED (HORIZONTAL VIEW) WARNINGS Be sure to check polarity (positive ( + ) and negative ( –...
- Page 15 REMOVING THE SLIDING DIFFUSER LENS | 3 MINS (APPROX) Slide the Sliding Diffuser Lens back into the 'Area' setting. Locate and remove the four (4) screws located on each side of it. Then, tilt the Sliding Diffuser Lens forward. Pull the Sliding Diffuser Lens out and free from the Light Head. NOTE: Repeat the steps above three (3) times with all three (3) Light Panels (the Nomad has three (3) Sliding Diffuser Lens').
- Page 16 GENERAL MAINTENANCE TIPS The Nomad reaches a full charge in approximately 7 hours. (Charge time ® may depend on ambient conditions and battery health). Maintain the light fully charged at all times, so that it is ready for use in the event of an emergency .
- Page 17 MODULARIZED REPLACEMENTS The Nomad Light Head is can be replaced if another color temperature is ® needed, or if the unit is damaged or requires service. Please contact FoxFury Customer Service (see pg. 19) for more information. NOTE: Replace Nomad Prime Heads only with other Nomad Prime Heads.
-
Page 18: Warranty
WARRANTY AND OTHER INFORMATION PRODUCT DURABILITY Lights are strong enough to cause damage to the human eye. Do not stare into LEDs for long periods of time or from a close range (less than 2 ft). IPX7 FoxFury, LLC is not responsible for any injury or damage caused CARE/CLEANING during the use of this product. -
Page 19: Contact Foxfury
OR FITNESS FOR A PARTICULAR EXTENT THAT THIS LIMITED PURPOSE. WARRANTY IS INCONSISTENT WITH APPLICABLE LAW, THIS STATEMENT THIS LIMITED WARRANTY SHALL SHALL BE DEEMED MODIFIED NOT APPL Y IF THIS PRODUCT IS TO BE CONSISTENT WITH SUCH NOT STORED, HANDLED, INSTALLED APPLICABLE LAW. - Page 20 FOXFURY .COM 1/2018...
