F009RT/WT Professional Weather Station User Manual
1 Introduction
Thank you for your purchase of the F009RT/WT Weather Station. The following user guide
provides step by step instructions for installation, operation and troubleshooting.
2 Warnings and Cautions
Warning: Any metal object may attract a lightning strike, including your weather station
mounting pole. Never install the weather station in a storm.
Warning: Installing your weather station in a high location may result in injury or death.
Perform as much of the initial check out and operation
3. Quick Start Guide
Although the manual is comprehensive, much of the information contained may be intuitive. In
addition, the manual may not flow properly because the sections are organized by components.
The following Quick Start Guide provides only the necessary steps to install, operate the weather
station, along with references to the pertinent sections.
Step
1 Assemble and power up the sensors
2 Power up the display console and synchronize with wind sensor, rain
sensor and thermo-hygrometer sensor
Mount the sensor array
3
4 Set date and time on console
4 Getting Started
The FT0200 weather station consists of a display console (receiver), a sensor array with
thermo-hygrometer, rain gauge, wind sensor, and mounting hardware.
4.1 Parts List
The FT0200 weather station consists of the following parts (as referenced in Figure 1 and Figure 2).
QTY
Required
Description
Item
4.3
4.4.2
6
8.2
4.3
