Page 1: User Manual
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Full-Color LED Multi-Window Video Processor User Manual... -
Page 2: Safety Precautions
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Safety precautions Danger ● High voltage exists in the device and non-professional maintenance personnel shall never open its back cover, lest risks happen. Warning ● This is not a waterproof device, so appropriate waterproof measures shall be taken in a damp environment;... -
Page 3: Table Of Contents
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Table of Contents I. Product descriptions ..........................4 II. Product features ............................5 III. Technical specifications ........................6 IV Work schematic diagram ........................8 V. Panel structure ............................9 Front panel ............................9 Back panel ............................10 VI. -
Page 4: Product Descriptions
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor I. Product descriptions With the rapid development of the LED display industry and the growing demands for applications, all control requirements arise at the right moment for controlling of the large-screen control system. However, due to the limitations to the large-screen control system in image processing, frame control and signal format conversion, the LED large-screen control system is somewhat weak and can not meet users’... -
Page 5: Product Features
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor II. Product features 1. Support independent operation on the control panel; the knob and number key design offers more convenience for device use; 2. Support host PC software control to realize visual and quick operation by virtue of the software operation and display synchronization;... -
Page 6: Technical Specifications
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor III. Technical specifications The video processor has integrated the latest patented video processing technology, able to manage the video conversion of arbitrary format input and corresponding format output as well as process and enhance such video signals as CVBS (composite video), HDMI, VGA (RGB) and DVI-D to meet customers’... - Page 7 Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor DVI Output Number of Outputs Interface form Standard DVI-D interface 1024× 768@60Hz,1280× 1024@60Hz 1366× 768@60Hz,1440× 900@60Hz Supported output resolution 1600× 1200@60Hz，1680× 1050@60Hz 1920× 1080@60Hz,1920× 1200@60Hz 1536× 1536@60Hz，2560× 1536@60Hz Signal level...
-
Page 8: Work Schematic Diagram
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor IV Work schematic diagram LED led screen Transmitter card Video processor Desktop Laptop Camera... -
Page 9: Panel Structure
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor V. Panel structure Front panel POWER - Device switch, OFF (Power OFF), ON (Power ON) LCD - Text display screen, able to display the menu, parameters and other information WIN1, WIN2 –... -
Page 10: Back Panel
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Back panel COM -1-------------------------------------------- Host PC software interface SDI--------------------------------------- SDI signal input interface for high-definition cameras, etc. HDMI------------------------------------ HDMI signal input interface for laptops, etc. DVI-------------------------------------- DVI signal input interface for desktops, etc. -
Page 11: Wiring And Installation
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor VI. Wiring and installation Wiring diagram Install DVI line Signal source LED screen Installation steps 1. First of all, it should be ensured that the graphics card can directly control the transmitter card and the led screen can display images normally when the video processor is not used;... -
Page 12: Settings
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor VII. Settings Full-screen The setting method depends on the following four kinds of circumstances: 1. A transmitter card has one frame enabled; 2. A transmitter card has two frames enabled;... - Page 13 Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Out Format Current Format 1920×1080 ★【Not Change】 Change Press OK to next Step 4: Click “OK” to enter the “Panel Para” interface and input the actual on-screen pixels of the screen width and height respectively.
-
Page 14: One Transmitter Card Has Two Frames Enabled
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor 2. One transmitter card has two frames enabled; Step 1: Click on “MENU” to enter the “Main MENU” interface. Note: Turn the knob and you can select different functions; click “OK” to confirm the selected function. - Page 15 Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Panel Para H Size 1920 Step×1 V Size 1080 Press OK to next Note: The numerical value can be changed as follows: 1) You can use the knob to adjust it (leftward to decrease while rightward to increase) with the adjustment step...
- Page 16 Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Image 1 Para H Pos V Pos H Size V Size Step 7: Click the “WIN2” button on the front panel to enter the “Image 2 Para” interface and you can enter the location and size respectively of the second image.
-
Page 17: Two Transmitter Cards Have One Frame Enabled
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor 3. Two transmitter cards have one frame enabled; Step 1: Click on “MENU” to enter the “Main MENU” interface. Note: Turn the knob and you can select different functions; click “OK” to confirm the selected function. - Page 18 Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Out 1 Setup H Size 1024 Step×1 V Size 1080 Press OK to next Note: The numerical value can be changed as follows: 1) You can use the knob to adjust it (leftward to decrease while rightward to increase) with the adjustment step...
-
Page 19: Two Transmitter Cards Have Two Frames Enabled
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor 4. Two transmitter cards have two frames enabled; Step 1: Click on “MENU” to enter the “Main MENU” interface. Note: Turn the knob and you can select different functions; click “OK” to confirm the selected function. - Page 20 Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Out 1 Setup H Size 1024 Step×1 V Size 1080 Press OK to next Note: The numerical value can be changed as follows: 1) You can use the knob to adjust it (leftward to decrease while rightward to increase) with the adjustment step...
- Page 21 Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Note: Select “PIP”, click “OK” and a red square will appear behind “PIP”, which indicates that it has been successfully selected; after selected, it will not jump to the “Main Menu” interface automatically and you need to click on “MENU”...
-
Page 22: Partial Debugging
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Partial debugging For “Zoom”, we often have the LED studio displayed on a full screen and it can be switched to the full display on the computer desk at any time. - Page 23 Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Zoom Para H Pos V Pos Step×1 H Size V Size Note: The numerical value can be changed as follows: 1) You can use the knob to adjust it (leftward to decrease while rightward to increase) with the adjustment step...
-
Page 24: Double-Window Partial Display
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor 2. Double-window partial display Step 1: click on “MENU” to enter the “Main Menu” interface and select “Zoom”. Step 2: Click the “WIN1” button on the front panel, select “Zoom” in “MENU” to enter the “Zoom Para”... - Page 25 Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Zoom Para H Pos V Pos H Size V Size Note: 1. Click “WIN2”, then click “Partial Display” and it will pop up the setup interface for partial display of the second window;...
-
Page 26: Control Menu
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor quickly via the “MODE” button on the front panel. Thank you again for your purchase of our company's video processor; please refer to the following parts for other settings. - Page 27 Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Chinese (II) Factory settings (III) Technical support Please contact the sales staff. 1024× 768@60Hz，1280× 1024@60Hz 1366× 768@60Hz，1440× 900@60Hz (IV) Output resolution 1600× 1200@60Hz，1680× 1050@60Hz 1920× 1080@60Hz ， 1920x1200@60Hz 2560× 1152@60Hz customizable...
-
Page 28: Language Options
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Enabled (II) Keyboard lock Disabled Contrast (III) Contrast settings Green Blue Direct switching (IV) Switching effects Special effects Enabled (V) Scheduled task Disabled Enabled (VI) Compatibility mode Disabled The functions of the first five major options have been previously clarified, so no repetition is needed any more and here importance is attached to the meaning of each option in “Advance Menu”:... -
Page 29: Technical Support
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor (3) Technical support Good after-sales services can be provided to our customers. (4) Output resolution It will change automatically when you are setting the screen parameters in the navigation bar and you can also select a resolution manually. -
Page 30: Faq
Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor IX. FAQ Q1. DVI, HDMI, VGA, CV port definitions A: DVI: Digital (HD) Video Signal Interface – As an interface standard launched in 1999 by DDWG (Digital Display Working Group) founded by Silicon Image, Intel and other relevant companies, it has offered sufficient optimization in terms of speed, definition and HDCP protocol, etc. - Page 31 Kystar KS800 2K HD Big LED Display Video Processor Multi-Window Processor Q6: What is the administrator password in the host PC software settings? A: No password is provided and you can just click “OK” to enter directly. Q7: What possible reasons if the processor software shows that a serial port can not be connected? What can indicate normal connection? A: To have your computer control the video processor, you need to connect its instruction transmission line (i.e.,...
