- Page 1 MANUAL INSTALLATION P U S H B U T T O N ELBOW SWITCH...
- Page 2 PREPARATION • Cable outlet 599 mm or 680 mm from the the lower edge, with the bottom lid mounted • Recommended height: about 120 mm from the floor to the lower edge • Cable: H05V-U (EK) H05V-K (RK) is ok with the use of wire end ferrules Minimum cross section area according to cable standard HD21 is 0.5 mm for EK and RK...
- Page 3 Dismantling top and bottom lid Top lid Screw hole Cable outlet Circuit board Outer profile Push front (front) Push front (back with electronics) Screw holes Bottom lid Connection diagram 24 V Relay 2 Pole 2 Relay 1 Relay 2 Pole 1...
- Page 4 Extended push 1.5s: Relay 1+2 1 2 3 4 5 6 7 8 P . O. Box 7, SE-54321 Tibro POSTAL Mariestadsvægen 28, SE-54330 Tibro VISIT & DELIVERY +46 504 400 40 · +46 504 141 41 SWITCHBOARD prismatibro.se · contact@prismatibro.se E-MAIL...
